- Page 1 FIRE ALARM CONTROL PANEL POLON 3000 POLON 3064, POLON 3128 and POLON 3256 variants _________________________________________________________________________________ QUICK START GUIDE IO-E388-101 Change II...
- Page 2 Directive (EU) 2014 / 30 / EU on electromagnetic compatibility. The POLON 3000 fire alarm control panel was issued a certificate of constancy of performance by JC CNBOP-PIB in Józefów, a notified body No. 1438 in the EU, confirming the compliance of the characteristics/technical parameters of the control panel with the requirements of PN-EN 54-2:2002+A1:2007 and EN 54-4:1997+ A1:2002+A2:2006.
-
Page 3: Table Of Contents
Inspections and maintenance ..........................22 10.1. Regulations for proper use ............................22 10.2. Periodic inspections and maintenance regulations ..................23 Packaging, storage, transportation .......................23 Appendix A – line elements of the POLON 4000/6000 system ............24 POLON 3000 FIRE ALARM CONTROL PANEL... -
Page 4: Safety Conditions
1.1. Safety of installation and equipment POLON 3000 fire alarm control panels are classified as Class I equipment and may be used only in the case of application of additional anti-shock protection, in the form of protective earthing. -
Page 5: Repairs And Maintenance
Maintenance work and periodic inspections must be performed by authorized personnel of companies authorized or trained by POLON-ALFA. All repairs must be carried out by the manufacturer. POLON-ALFA is not responsible for the operation of equipment maintained and repaired by unauthorized personnel. - Page 6 POLON 6000 protocol Detection line 2 POLON 4000 protocol POLON 6000 protocol Recommended or maximum numbers of inspection, control and signalling line elements on detection lines with POLON 6000 and POLON 4000 communication protocol POLON 3000 FIRE ALARM CONTROL PANEL...
-
Page 7: Construction Of The Control Panel
3. Construction of the control panel The POLON 3000 control panel housing consists of a metal housing in which the control panel components are mounted, and a removable front cover. The cover can be removed after unscrewing the screws in the upper part of the housing with a screwdriver and sliding it upwards in order to disconnect the side hooks - Fig. -
Page 8: Pso-30 Panel
In the case of more than one zone, zones can be grouped, in which case one indicator will show a group of zones (the information on the display specifies the location of the detected threat). POLON 3000 FIRE ALARM CONTROL PANEL... - Page 9 Continuous Signalling of efficient primary and backup power supply. / green Flashing Failure or absence of mains or backup power. LCD DISPLAY Display of messages related to the control panel status and configuration settings POLON 3000 FIRE ALARM CONTROL PANEL...
- Page 10 Readout for faulty alarm ALARM DEVICES FAULTY devices. STATUS OF Readout for disabled alarm DISABLED EQUIPMENT devices. Readout of the activated alarm transmission devices AL. TRANSMISSION DEV. Readout for faulty alarm FAULTY transmission devices. POLON 3000 FIRE ALARM CONTROL PANEL...
- Page 11 TIMERS T1, T2, T3, T4 Readout for timers delay values (T1, T2, T3, T4) Possibility to change LINE TYPE line type: CONFIGURATION loop/ open. DETECTION LINES Detection line 1 Readout of AUTO- elements CONFIGURATIO installed on Line1 POLON 3000 FIRE ALARM CONTROL PANEL...
- Page 12 INPUTS Reading the configuration of the inputs located in the control panel on the MSO-30 module CRITERIA - OUTPUTS Configuration readout for output groups activation ACTIVATION criterions MK-30 Configuration readout for MK-30 module parameters POLON 3000 FIRE ALARM CONTROL PANEL...
- Page 13 Readout for contamination Detection line 2 level of optical detectors on detection line 2 SERVICE Start of DOP-6001 automatic DOP-6001 TUNING adjustment (tuning) Sub-menu reserved for new TASKS RESERVE functions Sub-menu reserved for new RESERVE functions POLON 3000 FIRE ALARM CONTROL PANEL...
-
Page 14: Internal Modules Of The Control Panel
- module MSO-30, • user interface - in the form of a front panel with a keyboard and LCD display, • MLD-30 module for detection loops, • MK-30 digital communication module (optional). POLON 3000 FIRE ALARM CONTROL PANEL... - Page 15 The arrangement of the modules inside the control panel is shown Fig. 4-2 Rys. 4-3 Fig. 4-2 Control panel modules Rys. 4-3 Control panel with tilted panel PSO-30 POLON 3000 FIRE ALARM CONTROL PANEL...
-
Page 16: Power Supply
18 Ah. Capacity is limited by charging device power efficiency. The location of the batteries inside the control panel is shown at Rys. 5-2. POLON 3000 FIRE ALARM CONTROL PANEL... - Page 17 Reduction of the backup power voltage to about 22 V is indicated with sound. Further batteries voltage lowering and reaching the final discharge voltage below about 21 V will automatically shut down the control panel. POLON 3000 FIRE ALARM CONTROL PANEL...
-
Page 18: Service Functions
Line elements are all available devices, e.g. detectors, manual call points, sirens, etc., operating on any detection line of the POLON 3000 control panel. Detection lines of the POLON 3000 control panel have been adapted to support line elements of the 4000 and 6000 series produced by POLON-ALFA. - Page 19 Input/output device for addressable communication Devices MKA - module for communication via the containing the addressable line, compatible with 6000 protocol MKA module: IGNIS 2500, PZB 6000 CDG 6000, mCDG 6000 indirectly through AKC-6000 POLON 3000 FIRE ALARM CONTROL PANEL...
-
Page 20: Types Of Elements Of 4000 Series
POLON Studio application from the beginning of creating the project or after sending the configuration from the control panel to the computer. The configuration of detectors (or fire alarm receiving zones) is related to a place (partition) in the protected facility. Therefore, it is necessary to create detection POLON 3000 FIRE ALARM CONTROL PANEL... -
Page 21: System Configuration And Programming
8. System configuration and programming To configure the POLON 3000 system, it is necessary to download the POLON Studio application from the manufacturer's website and install it on the computer. The application enables convenient system design, configuration settings prepare and project archiving. -
Page 22: Connecting The Power Cables And Batteries
(auto-configuration). It is recommended to use shielded cables in the POLON 3000 system. When designing the installation, it is necessary to meet all the requirements of the technical data, especially pay attention to the capacity of the addressable supervision line. -
Page 23: Periodic Inspections And Maintenance Regulations
10.2. Periodic inspections and maintenance regulations Periodic tests of the POLON 3000 system should be carried out at least once a year, in accordance with CEN/TS 54-14. Every six months, check the condition of the protective, earthing or neutral connection with the control panel housing and clean the battery terminals. -
Page 24: Appendix A - Line Elements Of The Polon 4000/6000 System
IGNIS 2500 automatic fire extinguishing control panel 600 µA CDG 6000, mCDG 6000 gas detection control panel 150 µA the signalling device without additional power supply must have a guaranteed current from the line/loop for alarming POLON 3000 FIRE ALARM CONTROL PANEL... - Page 25 IO-E388-101-GB POLON 3000 FIRE ALARM CONTROL PANEL...
