VeloCore 22: How can I adjust the brake magnets to not touch the
flywheel?
Follow this troubleshooting guide to help resolve the brake magnets making contact with the flywheel on the VeloCore 22 bike.
Some common complaints may include:
Metallic grinding or scraping noises
Brake magnet making contact with flywheel
Brake magnet out of position
Brake and flywheel touching
Follow these steps to troubleshoot the issue
Check for updates on your machine. Verify you have a good Wi-Fi connection. Unplug your machine and plug it back
1.
in. When the BowFlex or JRNY page displaying serial numbers in the 4 corners appears, tap the upper right corner 10
times within 3 seconds (reference 1.1). If you are unable to reach this screen, log out and tap the upper right corner
10 times within 3 seconds from the Log In screen (reference 1.2).
The initial screen showing the BowFlex or JRNY logo appears with serial numbers in each corner. Tap the upper right corner 10 times within
about:blank
VeloCore 22: How can I adjust the brake magnets to not touch the flywheel?
(Reference 1.1)
3 seconds to access the menu to force an update.
(Reference 1.2)
ID: 11863.1
1/7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bowflex VeloCore 22
Summary of Contents for Bowflex VeloCore 22
- Page 1 10 times within 3 seconds from the Log In screen (reference 1.2). (Reference 1.1) The initial screen showing the BowFlex or JRNY logo appears with serial numbers in each corner. Tap the upper right corner 10 times within 3 seconds to access the menu to force an update.
- Page 2 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? The Log In screen appears after logging out or if you missed the opportunity to access the menu from the previous screen. Tap the upper right corner 10 times within 3 seconds to access the menu to force an update.
- Page 3 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? PLACEHOLDER IMAGE UNTIL BETTER RESOLUTION IS AVAILABLE. Select CHECK FOR UPDATES from the bottom of the menu once it appears. Retest your machine to determine if the original issue persists [FW.A]. If the issue persists, continue troubleshooting i the next section.
- Page 4 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? Remove the 3 screws circled in red to remove the center disc. (Reference 2) Remove the 8 screws from the left shroud and 1 screw from the right shroud. The group of screws circled in yellow should be removed first.
- Page 5 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? Unplug the resistance sensor cable (yellow) from the resistance sensor (red), then remove the left pair of screws attaching the sensor bracke to the frame (white arrows above resistance sensor cable).
- Page 6 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? (Bike pictured is the Schwinn IC4; your VeloCore should look similar) The magnet is located on the left side of this image. Remove the magnet to access the hardware to loosen and adjust the position of the brake assembly. ...
- Page 7 3/7/24, 11:49 AM VeloCore 22: How can I adjust the brake magnets to not touch the flywheel? (Bike pictured is the Schwinn IC4; your VeloCore should look similar) Loosen this bolt with a 6mm Allen wrench. Adjust the position of the brake assembly and retighten all hardware.
