BlueAnt TalkX Manual

What's in the Box

Please read through this manual to get the most out of your TalkX headset.

Inside the box you will find these items included

Get to know your TalkX

Charging your TalkX

Before we get started, it is best to fully charge your TalkX. A full charge takes about 2hrs. A quick 10 minute charge will get you 5hrs of play.

Pairing your TalkX

Press and hold the MFB for 2 seconds to power on for the first time. The TalkX will automatically enter pairing mode.

On your phone go to your Bluetooth settings and select the "BlueAnt TalkX" to pair.

To pair the TalkX to another device please power off the TalkX. Then press and hold the MFB for 5 seconds to go into pairing mode.

The TalkX will announce "Bluetooth pairing". Please follow the steps above to pair with another device.

Pairing your TalkX to your computer

Windows™

On Windows to add the BlueAnt TalkX, please put the TalkX into pairing mode.

Then in Windows search for "Bluetooth"
select "Bluetooth and other devices settings"
select "Add Bluetooth or other device"
select "Bluetooth" choose the "BlueAnt TalkX" then click "Done"

To check everything is configured correctly please open Sound settings

Output

Choose your output device - should be set to Headphones (BlueAnt TalkX stereo)

Input

Choose your input device - should be set to Headset (BlueAnt TalkX Hands-free AG Audio)

Mac®

Put your TalkX into pairing mode.
On your Mac please go to System Preferences and then Bluetooth.

Select the BlueAnt TalkX from the list of devices by clicking "connect"

To check everything is configured correctly please go to Sound.
Output should be set to BlueAnt TalkX
Input should be set to BlueAnt TalkX.

Multipoint Connection - Maximum 2 Devices

The BlueAnt TalkX supports multipoint so you can connect two devices simultaneously.

1. Once your first device is connected, please turn off Bluetooth on that device. The TalkX will then go back into pairing mode.

2. On your second device, go to Bluetooth settings and select the "BlueAnt TaIkX" to pair.
   "
3. On your first device, go back fo your Bluetooth setting and turn Bluetooth on again and select the TalkX to connect.
   Both devices will not be connected.

   A call may come through from either device
   If it is call on your phone, you can answer it on the TalkX.
   If it is a call from your computer, you will need to answer on your computer and it will come through the TalkX.

Control your TalkX

To control calls and music on the TalkX, please see below

Listen

Click the MFB once to Play/Pause

Double click the Vol button to skip forward

Double click the Vol button to skip forward

Talk

Click the MFB to answer an incoming call

Click the MFB to end an ongoing call

Click and hold or double click the MFB to reject an incoming call

Siri/Google

Double click the MFB to activating/cancel Siri/Gcogle

Volume

Click the Vol + to increase the volume

Click the Vol + to decrease the volume

EQ

The TalkX features two EQ profiles built in
Standard - This EQ is designed for rich, crystal clear calls with a balanced treble, mid and bass profile.
Bass Boost - This EQ is designed to emphasize bass frequencies in your music.
Change EQ - Click volume and volume at the same time to change EQ.

Boom Microphone

Boom Microphone
To enhance the microphone quality for calls you can use the included Boom microphone by plugging it into the USB C charging port.

When you unplug the Boom microphone the TalkX will default back to the built-in microphone.

Factory Reset

Please ensure you delete the TalkX pairing from your phone and other devices.

1. With the TalkX powered off, press and hold, the MFB for 5 seconds until the light flashes blue and red.

2. To Factory Reset your TalkX, press and hold the Vol+ and Vol- for 10 seconds until you see the light flash red 3 times and then to solid red for 1 second. The TalkX will then power off.


Troubleshooting

If you are having problems with your TalkX in Windows, please check under Audio in the Bluetooth and other devices tab.

You should see the "BlueAnt TalkX" listed and underneath the BlueAnt TalkX it should say "Connected voice, music".
If it only says "Connected music" and does not mention "voice", then the microphone will not work. If this is the case please click select the "BlueAnt TalkX" and then click "Remove device.
When prompted if you "Are sure you want to remove this device?", click "Yes".

Please save anything you were doing and reboot your computer.

While this is happening, please perform a factory reset on your TalkX.
You can do this when not connected to any devices by pressing and holding Volume + and Volume - for 10 seconds.
The TalkX will announce that "Factory Reset is complete" and then power down.

Once your computer has rebooted please go back to the "Bluetooth and other devices" menu and click "Add bluetooth or other device" again. Click on "Bluetooth"

Power on the TalkX to go into pairing mode.

Please wait for the "BlueAnt TalkX" to appear on the computer and select it.
Please check it says it is "Connected for voice, music.
If so, click done, close the settings tab.

To check everything is configured correctly please open sound settings.

Output
Choose your output device - should be set to Headphones (BlueAnt TalkX stereo).

Input
Choose your input device should be set to Headset (BlueAnt TalkX Hands-free AG Audio).

Warranty

This product is covered by BlueAnt's limited global warranty for one (1) year from the date of purchase by the first consumer purchaser of the product.
Please refer to the warranty.blueantwireless.com for full terms and conditions.
Register your BlueAnt product for warranty and new product updates at register.blueantwireless.com

HELP & SUPPORT

Visit support.blueantwireless.com

Email: care@bIueantwireIess.com

Call: 1300 669 049

Important Safety Information

PLEASE READ THIS ENTIRE DOCUMENT CAREFULLY, BECAUSE IT CONTAINS IMPORTANT INFORMATION ABOUT THE SAFE USE OF BLUEANT DEVICES

PROLONGED USE AT HIGH VOLUMES MAY AFFECT YOUR HEARING CAPACITY AND MAY RESULT IN NOISE INDUCED HEARING LOSS (NIHL).
TURN OFF THE POWER TO YOUR DEVICE WHEN NOT IN USE.

Please ensure that the device and any associated components such as chargers, are stored safely and that any packaging or unwanted contents are disposed of thoughtfully. Do not place the product on the floor or leave it in a place, where young children could access it, or someone could trip over it.

Care and Handling

Your BlueAnt Bluetooth device is a precision engineered instrument. To ensure its ongoing performance, you should look after it as you would any quality consumer electronic product. and use it in accordance with the instructions.

BlueAnt recommends that you take the following precautions.

• Avoid leaving your device in direct sunlight, such as on the dashboard or console of a car or truck. Do not leave your device unattended in your vehicle.
• Do not leave your device, or use your device, in any area where the temperature may exceed 60 degrees Centigrade (140 degrees Fahrenheit), such as inside a closed car on a hat day. Remember that on a hot day, the temperature inside a closed car may be significantly higher than the outside air temperature.
• Do not leave your device, or use your device, in any area exposed to humidity, dust, soot other foreign objects. smoke, or steam as this may cause your device to malfunction.
• Do not use any household or industrial grade detergents or cleaners to clean your device. If your device becomes dirty or smeared, in most instances. a wipe with a dry or slightly damp cloth should be sufficient to clean it.
• Do not leave your Bluetooth device, plugged into a wall or car charger for long periods after it is fully charged. BlueAnt does not recommend long periods of continued charging.
• Before charging your BlueAnt device, make sure that the AC outlet, adaptor and cable are not damaged. If you notice any abnormalities, seek advice from a qualified professional.
• If traveling internationally, ensure that your BlueAnt wall or car power adapter is approved for use in the country where you plan to use it and that the adapter voltage is suited to the local power supply.
• Should a fault develop with your BlueAnt product, contact BlueAnt for advice on how to proceed. Do not attempt to repair or alter any BlueAnt product yourself.

Approved Accessories

The use of accessories not approved by BlueAnt, including but not limited to batteries. antennas. wall adapters, car charger, ear gels and foam tips and convertible covers, may cause your BlueAnt device to malfunction or in the case of non approved electrical accessories may cause the device to exceed RF energy.

Use of non approved accessories will void your device's warranty. For a list of approved BlueAnt accessories, visit our website www.blueantwireless.com

ONLY CHARGE WHEN DEVICE IS CLEAN AND DRY

PROTECT YOUR HEARING
BLUEANT DEVICES CAN REACH VOLUMES ABOVE 100 DECIBELS.

Nearly every electronic device is susceptible to electro-magnetic interference (EMI) if inadequately shielded, designed, or otherwise for electromagnetic compatibility.

Similiar to a mobile phone, your BlueAnt device is e low power transmitter/ receiver and is covered by regulations in any facility where posted notices instruct you to do 50. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

• When instructed to do so, turn off your BlueAnt device when you board an aircraft. Any use of a mobile device must be in accordance with applicable laws, regulations and airline crew instructions.
• Some Bluetooth devices may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.
• If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your doctor or physician may be able to assist you in obtaining this information.
• If you are in doubt whether your BueAnt device or mobile phone can be safely turned on or used please consult an authorised person in the location you want to use your BlueAnt device. If no authorised person is available, or you remain uncertain. BlueAnt recommends that you turn off your Bluetooth device and any mobile phones unless they are required in an emergency situation.

www.blueantwireless.com
