Checklist: Shipped Items

Make sure you received the following items in the shipped box:
Power cable

Network cable

1.3

Positioning

Position RX-PAD on the table for optimal management. Use this figure as reference.
1.4

Cabling

The figure below shows RX-PAD connector ports.
L-R Description
Power cable
1
2
Currently inapplicable. USB Type C.
3
Currently inapplicable. USB Type A Super Speed.
4
Currently inapplicable. HDMI for external video ingest.
5
Network port (PoE)
Access the connector ports by unscrewing the two screws to remove their cover.
1.5

Powering up

After connecting the power cable -OR- the network port (PoE), RX-PAD powers up.
