- Page 1 User's Manual AudioCodes High Definition IP Phones Series RX-PAD Meeting Room Controller Version 2.0...
-
Page 3: Table Of Contents
Positioning ........................8 Cabling..........................8 Powering up ........................8 General Pairing Prerequisites ..................9 Managing the Device ...................... 9 Getting Started ......................11 Using RX-PAD ......................15 Using RX-PAD to Adjust RXV81 Camera Settings ............15 Version 1.19 RX-PAD Meeting Room Controller... - Page 4 RX-PAD Meeting Room Controller This page is intentionally left blank. User's Manual Document #: LTRT-18111...
- Page 5 Date Published: Mar-21-2023 Trademarks AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom, AudioCodes One Voice and CloudBond are trademarks or registered trademarks of AudioCodes Limited All other products or trademarks are property of their respective owners.
- Page 6 RX-PAD Meeting Room Controller This page is intentionally left blank. User's Manual Document #: LTRT-18111...
-
Page 7: Introduction
User's Manual 1. Introduction Introduction Available as a bundle with the RXV81, AudioCodes’ RX-PAD is a center-of-room intelligent touch controller that provides access to the RXV-81 meeting room. Note: Only applies to users who have the TEAMS-RXV81-B10 bundle. • •... -
Page 8: Checklist: Shipped Items
Make sure you received the following items in the shipped box: Power cable Network cable Positioning Position RX-PAD on the table for optimal management. Use this figure as reference. Cabling The figure below shows RX-PAD connector ports. Description Power cable Currently inapplicable. USB Type C. -
Page 9: General Pairing Prerequisites
For the initial pairing of the out-of-the-box set, make sure that the physical distance between them is less than 50 cm. Managing the Device RX-PAD MTR is managed by AudioCodes’ One Voice Operations Center | Device Manager. Management includes: Firmware management / upgrade ... - Page 10 RX-PAD Meeting Room Controller This page is intentionally left blank. User's Manual Document #: LTRT-18111...
-
Page 11: Getting Started
To get started: After powering up (see here), RX-PAD displays the 'Languages' page. Make sure both RX-PAD and RXV81 are connected to the network and then select a language; an RXV-PAIR process is automatically initiated; view the following on RX-PAD: Tap PAIR;... - Page 12 Enter your email or Teams username and select Next -OR- click the account to sign in with. After sign-in to RX-PAD is finished, use the Remote Keyboard application that pops up on RX- PAD to sign in to the RXV81.
- Page 13 Enter your Password. RXV81 RX-PAD After sign-in on both devices is complete, click Search again; the RXV81 (Serial Number) bundled with RX-PAD becomes available for selection. RXV81 RX-PAD After selecting RXV81, a pairing code is displayed on the RXV81 screen.
- Page 14 RX-PAD Meeting Room Controller RXV81 RX-PAD Enter the code using the keypad on RX-PAD. RXV81 RX-PAD After Microsoft’s pairing process finishes, view an All set! indication on each device. RXV81 RX-PAD After a few moments, the indication disappears and you’ll view the home page with controls of the RXV81 displayed on RX-PAD.
-
Page 15: Using Rx-Pad
RX-PAD can be used to control RXV81 camera settings. To adjust RXV81 camera settings: In RX-PAD, pull down the notification bar and select the Camera Settings icon -OR- on the physical interface of the RX-PAD, tap the camera icon (labeled 3 in the preceding figure). Version 1.19... - Page 16 RX-PAD Meeting Room Controller View the camera settings menu and a preview of the room the RXV81 is located in. In the Camera Settings page, adjust the Brightness, Contrast, Saturation, Zoom and Tilt. Optionally, save the current settings in the running preset, or save them in a separate preset using the Create New Preset button.
- Page 17 User's Manual 3. Using RX-PAD This page is intentionally left blank. Version 1.19 RX-PAD Meeting Room Controller...
- Page 18 Website: https://www.audiocodes.com/ ©2023 AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, User Management Pack, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom and AudioCodes One Voice are trademarks or registered trademarks of AudioCodes Limited.
- Page 19 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
