Using RX-PAD

Use the figure and the table following as a reference to using RX-PAD.
L-R Description
1 Back option
2 Home button: tap to return to the home screen from any screen.
Long-press to open the device Settings screen.
3
Tap to access camera settings
4 Tap to open administrator-related menus including Settings
5 Calendar meetings
6
Hidden motion sensor that allows 'waking up' the device while in screensaver mode - when
someone enters the room
3.1

Using RX-PAD to Adjust RXV81 Camera Settings

RX-PAD can be used to control RXV81 camera settings.

To adjust RXV81 camera settings:
1. In RX-PAD, pull down the notification bar and select the Camera Settings icon -OR- on the
physical interface of the RX-PAD, tap the camera icon (labeled 3 in the preceding figure).
Version 1.19
7
5
2
1
3
6
15
3. Using RX-PAD
4
RX-PAD Meeting Room Controller
