Summary of Contents for Profile Design ASC
- Page 1 ASC Computer Mount ASC COMPUTER MOUNT REVISION 01-08-28-2024...
-
Page 2: Tools And Materials Required
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's warranty policy. If you are not familiar with installation of bicycle accessories, please seek the assistance of your local Profile design dealer by logging on to www.profile-design.com and using "dealer search"... -
Page 3: Component List
QTY. Ref.# Part.# Part Description Req. 796353 Computer Mount - PFD ASC COMPUTER MOUNT - Mount For Garmin/WAHOO 796355 Swivel Base - PFD ASC COMPUTER MOUNT - Base 796354 Computer Mount - PFD ASC COMPUTER MOUNT - Bracket 313607 Bolt - M4x12MM FHB SS... -
Page 4: Part Drawings
ASC Computer Mount PART DRAWINGS 34.8 mm 17.2 mm 39.2 mm 81.5 mm 63 mm... -
Page 5: Torque Settings
ASC Computer Mount TORQUE SETTINGS Ref.# Location Bolt Size Torque Mount For Garmin M4x8mm 0.8Nm Bracket M4x8mm 0.7Nm... -
Page 6: Installation Instructions
ASC Computer Mount INSTALLATION INSTRUCTIONS * Caution! Before riding, ensure that the bolts are tightened to the torque specified in the Instruction Sheet. 3. After finding a suitable position, use a 2.5mm Allen torque wrench to tighten the bolt until the upper and lower parts of the opening are securely fastened. - Page 7 ASC Computer Mount 5. Next, please sit on your bike in your usual riding position to see if any slight adjustments are needed. ASC Computer adjustment method: 6. If an adjustment is needed, please remove the computer. Tilt Left and Right 15°...
- Page 8 ASC Computer Mount WHAT SHOULD YOU DO IF THE COMPUTER IS IDLING DUE TO LOSE BOLT OR OTHER CONDITIONS? 1. Please take the 2.5mm allen torque wrench and insert it into the hole at the back to lock the upper plate.
-
Page 9: Warranty Policy
• Profile Design Worldwide Two Year Limited Warranty. • Profile Design, LLC (distributor) warrants to the original retail purchaser ("you") that the Profile Design product for which you received this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase. For more details on this warranty, its exclusions and/or how to make a claim under the warranty please call +1 310.747.0085 extension 161 or visit... - Page 10 ASC Computer Mount 2677 El Presidio Street Long Beach, CA 90810 Ph: 310-884-7756 www.profile-design.com © Profile Design LLC...
