Contents
Important User Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Safety Precautions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
General Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Visit the OnBoard Keyboard Cart web page at wengercorp.com for more information.
Note: Please read and understand these instructions before proceeding�
Note: If you need additional information, contact Wenger Corporation using the information below�
©Wenger Corporation 2024
Wenger Corporation, 555 Park Drive, P�O� Box 448, Owatonna, Minnesota 55060-0448
Questions? Call�����USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp�com
Assembly Instructions and Owner's Manual
OnBoard
Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Adjusting the Cart � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
Loading the Cart � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Moving the Cart � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Shelf Extension Accessory � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
Storage � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
Replacement Parts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
Printed in USA 2024-11
Keyboard Cart
®
Part #210C290-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger OnBoard Keyboard Cart
Summary of Contents for Wenger OnBoard Keyboard Cart
-
Page 1: Table Of Contents
Replacement Parts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16 Visit the OnBoard Keyboard Cart web page at wengercorp.com for more information. -
Page 2: Important User Information
Wenger Corporation� Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions� In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions�... -
Page 3: Safety Precautions
General Operation CAUTION • OnBoard Keyboard Cart maximum total load capacity is 40 lb (18 kg) uniformly distributed on the keyboard shelf, 120 lb (54 kg) uniformly distributed on the lower shelf and 40 lb (18 kg) on each shelf extension. -
Page 4: Required Tools
Required Tools • 9/16" Wrench or 9/16" socket with ratchet • 7/32" Allen wrench (provided) Supplied Hardware Hardware remaining after assembly can be discarded. 3/8-16 x 2-1/4" 3/8-16 x 1" 1/4-20 x 1/2" Carriage Bolt Carriage Bolt Carriage Bolt 3/8-16 3/8-16 x 2-3/4"... -
Page 5: Parts List
Parts List Item Description Item Description Base Assembly Rubber Grommet Swivel Caster 2�48" (63 mm) Dia Knob Rigid Caster Keyboard Clamp Bracket Tow Bar 10 Top Shelf 6" x 21" Black Rubber Pad 11 Bottom Shelf Keyboard Pivot Lock Plate 12 Cross Member... -
Page 6: Assembly
Assembly Assemble casters (2 and 3) to the base assembly (1)� 1� Align the swivel casters (2) with the bolt holes on the base assembly (1)� Detail A 2� Assemble the casters to the base assembly (1) using two 3/8-16 x 1" carriage bolts (16) and lock nuts (19)� At this point, only attach the casters using the outside holes (tow hole side) on the base assembly�... - Page 7 Assembly (continued) Assemble the bottom shelf onto the cart base� CAUTION Two people are recommended to complete the next steps. 1� Align the bottom shelf (11) on the inside of the base assemblies (1)� (Detail C) 2� Secure the bottom shelf, in the corners, to the base assemblies and casters using eight 3/8-16 x 1"...
- Page 8 Assembly (continued) Assemble the top shelf onto the cart� CAUTION Two people are recommended to complete the next steps. Vertically align the top shelf (10) at the top of the base assemblies (1) at desired location� (Detail D) NOTICE The vertical height of the shelf on the cart is adjustable. 1�...
-
Page 9: Operation
Operation Always observe the "Safety Precautions" in these instructions� Failure to comply with the "Safety Precautions" in these instructions can result in serious injury. 1� Make sure the cart is secure and does not roll away while loading, unloading, being stored, parked or during a performance�... -
Page 10: Adjusting The Cart
Operation (continued) Adjusting the Cart The top shelf (10) is adjustable vertically and also can be tilted up to 10º� Detail C To Adjust the Top Shelf Vertically (Detail C) 1� Remove the jam lock nut (25), carriage bolt (26), black knob (8), socket screw (18) and keyboard pivot lock plate (6) while holding the top shelf (10) on one end�... -
Page 11: Loading The Cart
Operation (continued) Loading the Cart 1� Always distribute loads evenly on the keyboard cart� - 40 lb (18 kg) max� on keyboard shelf - 120 lb (54 kg) max� on lower shelf - 40 lb (18 kg) max� on each shelf extension Moving the Cart 1�... - Page 12 Operation (continued) Moving the Cart (continued) 4� A separate tow bar (4) is provided which inserts into two holes in the base assembly (1)� The tow bar (4) may be used as a handle to pull the keyboard cart manually or can be attached horizontally to a lawn and garden tractor�...
-
Page 13: Shelf Extension Accessory
Shelf Extension Accessory 1� Support one end of the top shelf (10)� (Detail F) 2� Remove black knob (8) and socket screw (18)� (Detail F) CAUTION Two people are required. The top shelf (10) is now loose on one end and must be supported. Detail F... - Page 14 Shelf Extension Accessory (continued) 3� Tilt the shelf extension up and insert the two tabs into the two slots at the end of the top shelf� (Detail G and H) Shelf Extension Detail G Detail H Detail I 4� Lower the end of the shelf extension (Detail I) and re-insert the socket screw (18) through the shelf extension, top shelf (10), base assembly (1), pivot lock plate (6) and jam lock nut (25)�...
-
Page 15: Storage
Storage 1� When leaving the cart in a stationary position or in storage, always block or secure the casters to prevent the cart from moving and possibly causing damage� Maintenance 1� Clean the cart with a mild detergent and warm water� Avoid using harsh or abrasive cleaning products� 2�... -
Page 16: Replacement Parts
Replacement Parts Item Description Item Description Base Assembly 1/4" Lock Washer 9" (229 mm) Dia Swivel Caster 1/4-20 x 1/2" Carriage Bolt 9" (229 mm) Dia Rigid Caster 3/8-16 x 1" Carriage Bolt Tow Bar 3/8-16 x 2-1/4" Carriage Bolt 6 X 21 Rubber Pad 3/8-16 x 2-3/4"...
