Contents
Important User Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Safety Precautions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
General Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Visit the OnBoard Percussion Cart web page at wengercorp.com for more information.
Note: Please read and understand these instructions before proceeding�
Note: If you need additional information, contact Wenger Corporation using the information below�
©Wenger Corporation 2024
Wenger Corporation, 555 Park Drive, P�O� Box 448, Owatonna, Minnesota 55060-0448
Questions? Call�����USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp�com
Assembly Instructions and Owner's Manual
OnBoard
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
Storage � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
Replacement Parts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
Printed in USA 2024-11
Percussion Cart
®
Part #210C291-03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger OnBoard Percussion Cart
Summary of Contents for Wenger OnBoard Percussion Cart
-
Page 1: Table Of Contents
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5 Visit the OnBoard Percussion Cart web page at wengercorp.com for more information. -
Page 2: Important User Information
Wenger Corporation� Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions� In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions�... -
Page 3: Safety Precautions
General Operation CAUTION • OnBoard Percussion Cart maximum total load capacity is 150 lb (68 kg) uniformly distributed on the main support bar. • Each instrument support is limited to a maximum load of 20 lb (9 kg) if used in the vertical position and 10 lb (5 kg) in the horizontal position. -
Page 4: Required Tools
Required Tools • 9/16" Wrench or 9/16" socket with ratchet • 1/2" Wrench or 1/2" socket with ratchet • 3/16" Allen wrench (provided) Supplied Hardware Hardware remaining after assembly can be discarded. 3/8-16 x 1" 3/8-16 5/16-18 x 3" 5/16-18 Carriage Bolt Lock Nut Socket Screw... -
Page 5: Parts List
Parts List Item Description Item Description Base Assembly Mount Assembly Swivel Caster Support Weldment Rigid Caster Tube Clamp Extrusion Tow Bar Accessories Clamp Extrusion Curved Tube Extrusion... - Page 6 Assembly Assemble Casters to the Base Assembly 1� Align the swivel casters (2) with the bolt holes on the base assembly (1)� 2� Assemble the casters to the base assembly (1) using two 3/8-16 x 1" carriage bolts (10) and lock nuts (11)� (Detail A) NOTICE The same caster type (swivel or rigid) must be assembled to each base assembly.
- Page 7 Assembly (continued) Assemble the Curved Tube Extrusion Onto the Cart Base NOTICE Make sure the cart is secure and doesn't roll away while assembling the curved tube extrusion (5). 8� Place the curved tube extrusion onto the clamps located at the top of the base assemblies (1)� Be sure to center the curved tube extrusion so it is evenly positioned on the base units�...
- Page 8 Assembly (continued) Attachment of Percussion Mount Assembly The percussion mount assembly may be attached in the up, down, front or back position to receive universal instrument mounts� Determine the direction in which the instruments are to be located on the cart� To attach the percussion mount assembly;...
-
Page 9: Operation
Operation Always observe the "Safety Precautions" in these instructions� Failure to comply with the "Safety Precautions" in these instructions can result in serious injury. Loading the Percussion Cart 1� Always distribute loads evenly� 2. Avoid off-center loads. Moving the Percussion Cart 1�... - Page 10 Operation (continued) 4� A separate tow bar (4) is provided that inserts into two holes in the percussion cart base (1)� The tow bar (4) may also be used as a handle to pull the cart manually or can be attached horizontally to a lawn and garden tractor�...
-
Page 11: Maintenance
Storage When leaving the cart in a stationary position or in storage, block or secure casters to prevent the cart from moving and possibly causing damage� Maintenance 1� Clean the cart with a mild detergent and warm water� Avoid using harsh or abrasive cleaning products�... -
Page 12: Replacement Parts
14 1/4-20 x 3/4" Torx Self Tap Screw Tow Bar 15 Extrusion Cap Curved Tube Extrusion 16 Upright Extrusion Percussion Mount Assembly 17 Wenger Onboard Decal Percussion Cart Support 18 2�00 Plug Tube Clamp Extrusion 19 1/4" Lock Washer 1/2-13 x 1" Socket Screw 20 1/4-20 x 1-1/4"...
