C
ONTENTS
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Fastener List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Note: Please read and understand these instructions before assembly or use.
Note: Remove all items from the shipping cartons and arrange them in a convenient location.
Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2016
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Printed in USA 01/16
Assembly and Owner's Manual
OnBoard
®
Percussion Cart
Part #210C291-02
Advertisement
Table of Contents
Related Manuals for Wenger OnBoard Percussion Cart
Summary of Contents for Wenger OnBoard Percussion Cart
-
Page 1: Table Of Contents
Refer to the illustrations on the following pages. If you need additional information, contact the Wenger Corporation using the information below. ©Wenger Corporation 2016 Printed in USA 01/16 Part #210C291-02 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: (800) 4WENGER (493-6437) • Worldwide: +1(507) 455-4100 • www.wengercorp.com... -
Page 2: Important User Information
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual. -
Page 3: Safety
AFETY RECAUTIONS Throughout this manual you will find CAUTIONS and WARNINGS. They are defined as follows: • WARNING; failure to follow the instruction may result in serious injury or death. • CAUTION; failure to follow the instruction may result in serious injury or damage to property. CAUTION CAUTION CAUTION... -
Page 4: Tools Required
OOLS EQUIRED • 9/16" Wrench or 9/16" Socket with Ratchet • 1/2" Wrench or 1/2" Socket with Ratchet • 3/16" Allen Wrench (provided) ASTENER Note: Extra hardware can be discarded. Nylon Lock Nut, Carriage Bolt, 3/8-16 x 1 Lock Nut, 3/8-16 Socket Screw, 5/16-18 x 3 5/16-18... -
Page 5: Parts List
ARTS Item # Description Item # Description BASE ASSEMBLY MOUNT ASSEMBLY SWIVEL CASTER SUPPORT WELDMENT RIGID CASTER TUBE CLAMP EXTRUSION TOW BAR ACCESSORIES CLAMP EXTRUSION CURVED TUBE EXTRUSION... -
Page 6: Assembly
SSEMBLY ASSEMBLE CASTERS (#2 AND #3) TO THE BASE ASSEMBLY (#1) 1. Align the swivel casters (#2) with the bolt holes on the base assembly (#1). 2. Assemble the casters to the base assembly (#1) using two 3/8-16 x 1 carriage bolts (#10) and lock nuts (#11). - Page 7 SSEMBLY CONTINUED Note: Make sure the Percussion Cart is secure and doesn’t roll away while assembling the curved tube extrusion (#5) ASSEMBLE THE CURVED TUBE EXTRUSION (#5) ONTO THE PERCUSSION CART BASE. 8. Place the curved tube extrusion onto the clamps located at the top of the base assemblies (#1). Be sure to center the curved tube extrusion so it is evenly positioned on the base units.
- Page 8 SSEMBLY CONTINUED ATTACHMENT OF PERCUSSION MOUNT ASSEMBLY The percussion mount assembly may be attached in the up, down, front or back position to receive universal instrument mounts. Determine the direction in which the instruments are to be located on the Percussion Cart.
-
Page 9: Operation
PERATION LOADING THE PERCUSSION CART 1. Always distribute loads evenly. 2. Avoid off-center loads. MOVING THE PERCUSSION CART 1. When the cart is left unattended, it must be placed in a secure position to avoid moving or rolling into vehicles, structures or people. 2. - Page 10 PERATION CONTINUED 4. A separate tow bar (#4) is provided that inserts into two holes in the percussion cart base (#1). The tow bar (#4) may also be used as a handle to pull the Percussion Cart manually or can be attached horizontally to a lawn and garden tractor.
-
Page 11: Storage
TORAGE When leaving the Percussion Cart in a stationary position or in storage, block or secure casters to prevent the cart from moving and possibly causing damage. AINTENANCE 1. Clean the Percussion Cart with a mild detergent and warm water. Avoid using harsh or abrasive cleaning products. -
Page 12: Replacement Parts List
SELF TAP SCREW, 1/4-20x3/4, TORX TOW BAR EXTRUSION CAP CURVED TUBE EXTRUSION UPRIGHT EXTRUSION PERCUSSION MOUNT ASSEMBLY WENGER ONBOARD DECAL PERCUSSION CART SUPPORT PLUG, 2.00, BLACK TUBE CLAMP EXTRUSION LOCK WASHER, 1/4" SOCKET SCREW, 1/2-13x1 SELF TAP SCREW, 1/4-20x1 1/4...
