Wenger OnBoard Bass Drum/Gong Cart Assembly Instructions And Owner's Manual

Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Important User Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Safety Precautions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
General Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Visit the OnBoard Bass Drum/Gong Cart web page at wengercorp.com for more information.
Note: Please read and understand these instructions before proceeding�
Note: If you need additional information, contact Wenger Corporation using the information below�
©Wenger Corporation 2024
Wenger Corporation, 555 Park Drive, P�O� Box 448, Owatonna, Minnesota 55060-0448
Questions? Call�����USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp�com
Assembly Instructions and Owner's Manual
OnBoard
®
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
Operation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Printed in USA 2024-11
Bass Drum/Gong Cart
Part #210B326-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OnBoard Bass Drum/Gong Cart and is the answer not in the manual?

Questions and answers

Related Manuals for Wenger OnBoard Bass Drum/Gong Cart

Summary of Contents for Wenger OnBoard Bass Drum/Gong Cart

  • Page 1: Table Of Contents

    Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4 Visit the OnBoard Bass Drum/Gong Cart web page at wengercorp.com for more information.

  • Page 2: Important User Information

    Wenger Corporation� Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions� In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions�...

  • Page 3: Safety Precautions

    General Operation CAUTION • OnBoard Bass Drum/Gong Cart maximum total load capacity is 55 lb (25 kg). • The cart is only intended to hold either a bass drum or gong. • When moving the cart to and from performing areas the pivot loop assembly must be locked in the upright position and the speed is not to exceed 5 mph (8 kph).

  • Page 4: Required Tools

    Required Tools • 9/16" Wrench or 9/16" socket with ratchet • 3/16" Allen wrench (provided) • 3/8" Wrench • 5 mm Hex wrench (provided) • Small phillips screwdriver Supplied Hardware Hardware remaining after assembly can be discarded. 3/8"-16 x 1 3/8"...

  • Page 5: Assembly

    Assembly Assemble Casters to the Base Assembly 1� Align the swivel casters (2) with the bolt holes on the base assembly (1)� Detail A 2� Attach the casters to the base assembly using 3/8" carriage bolt (12) and lock nut (13)� (Detail A) NOTICE The same caster type (swivel or rigid) must be assembled to each base assemblies.
  • Page 6 Assembly (continued) 8� Position the cart upright on the casters� 9� Using #10-24 x 5/8" machine screws (14) and #10-24 nylon lock nuts (15), loosely attach the locking pull-pin (11) to the top extrusion of the base assembly (1)� Do not tighten the screws and lock nuts� (Detail C) 10�...
  • Page 7 Assembly (continued) Assembling the Drum/Gong Loop Onto the Cart 14� Slide spacer bearing (10) onto the bolt of the adjustable pivot weldment (5)� (Detail E) 15. Slide flange bearing (9) onto the bolt on the adjustable pivot weldment (5) with the flange side in, next to the spacer bearing (10). (Detail E) 16�...

  • Page 8: Operation

    Operation Always observe the “Safety Precautions” in these instructions� Failure to comply with the “Safety Precautions” in these instructions can result in serious injury. To mount the bass drum onto the cart: 1� Attach the hook to one end of the bungee cord� a�...
