ZEF004781008
Toshiba Corporation
Unified Controller
nv
Series
ABSOCODER CONVERTER for TC-net I/O
AB935N
Specifications and Instruction Manual
Applicable sensor
VLS-8SM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABSOCODER AB935N and is the answer not in the manual?

Questions and answers

Related Manuals for NSD ABSOCODER AB935N

Summary of Contents for NSD ABSOCODER AB935N

  • Page 1 ZEF004781008 Toshiba Corporation Unified Controller Series ABSOCODER CONVERTER for TC-net I/O AB935N Specifications and Instruction Manual Applicable sensor VLS-8SM...

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ............................i RELATED MANUALS ..........................i COPYRIGHT ..............................i GENERAL SAFETY RULES ........................ii REVISION HISTORY ........................... v 1. OVERVIEW ............................... 1 1-1. Overview ......................................1 1-2. Features ......................................1 1-3. Terminology ....................................2 2. SYSTEM CONFIGURATION ........................4 2-1.
  • Page 4 CONTENTS 6. INSPECTIONS ............................28 7. TROUBLESHOOTING .......................... 29 7-1. Error List ......................................29 7-2. ABSOCODER Sensor Check List ............................. 31 8. SPECIFICATIONS ..........................33 8-1. AB935N Module Specifications ..............................33 8-1-1. General Specification ................................33 8-1-2. Performance Specification..............................34 8-1-3.

  • Page 5: Introduction

    INTRODUCTION Thank you very much for purchasing our product. Before operating this product, be sure to carefully read this manual so that you may fully understand the product, safety instructions and precautions. - Please submit this manual to the operators actually involved in operation. - Please keep this manual in a handy place.

  • Page 6: General Safety Rules

    NSD. This product is designed to be used under the industrial environments categorized in Class A device. The supplier and user may be required to take appropriate measures.

  • Page 7: Installation

    - Do not store the module in a place exposed to water, or toxic gas and liquid. - Be sure to store the module in designed temperature and humidity range, and do not exposed to direct sunlight. - Be sure to consult with NSD when any module is stored for long periods. 3. Transport CAUTION - Do not hold the cable or shaft of the ABSOCODER sensor during transport;...

  • Page 8: Operation

    6. Operation CAUTION - Do not change the module's function switch settings during the operation; otherwise, it will cause injury. - Do not approach the machine after instantaneous power failure has been recovered. Doing so may result in injury if the machine starts abruptly - Be sure to check that the power supply specifications are correct;...

  • Page 9: Revision History

    REVISION HISTORY The Document No. appears at the upper right of this manual's cover page. Document No. Date Revision Description ZEF004781000 20, Nov., 2009 1st Edition Japanese document: ZEF004780600 ZEF004781001 8, Jan., 2010 2nd Edition Japanese document: ZEF004780601 ZEF004781002 27, Jul., 2010 3rd Edition Japanese document: ZEF004780602 ZEF004781003 12, May., 2011 4th Edition...

  • Page 10: Overview

    1. OVERVIEW 1. OVERVIEW 1-1. Overview The AB935N module is an ABSOCODER converter for the TC-net I/O System of the Toshiba Corporation Unified Controller nv Series. Combine the module with a linear type ABSOCODER sensor (VLS-8SM) to have the detected position data converted into binary codes.

  • Page 11: Terminology

    1. OVERVIEW 1-3. Terminology (1) ABSOCODER "ABSOCODER" is a generic name referring to the type of sensing device that detects rotational and linear displacement as well as speed and acceleration in an absolute format and outputs them digitally (or analogously). "ABSOCODER" comprises a detection unit that converts displacement into a variation in magnetic resistance and a conversion unit that inputs an alternating-current energization signal into the detection unit and then issues an absolute-format data according to the output signal returned from the detection unit.
  • Page 12 1. OVERVIEW (3) Semi-absolute format The AB935N module detects the machine position in a semi-absolute format. In the semi-absolute format, “standard pitch” of the sensor rod is detected in absolute value. (Absolute detection range) Furthermore, the pitch is counted by the software. 1 pitch 2 pitches 3 pitches...

  • Page 13: System Configuration

    Error cancel AB935N AB935N signal signal *1: SA911 can be replaced with SA912. For more details, contact your NSD representative. NOTES Use the general I/O base unit BU902 for the AB935N module. Do not use any other types of base units.

  • Page 14: Connection Configuration

    2. SYSTEM CONFIGURATION 2-2. Connection Configuration The following figure indicates connecttion configuration of the AB935N module. ●Connection configuration TC-net I/O bus BU902 ③ Extension sensor cable ② ABSOCODER sensor TC-net I/O bus connector Connector ① AB935N VLS-8SM20 type External input ・Error cancel ・Origin setting VLS-8SM14...
  • Page 15 VLS-8SM14(S) : 50, 100, 150, 200 ② [2]: Connector type B: Standard connector (NJW-2012PM8, manufacturer: Nanaboshi Electric Mfg.Co,Ltd.) Contact your NSD representative for VLS-8SM14 and VLS-8SM14S R: Crimping terminals (R1.25-4) Z: No connector [L]: Interconnecting sensor cable length (m): 2, 5,10, 20 ◆Extension sensor cable...

  • Page 16: Internal Block Diagram

    2. SYSTEM CONFIGURATION 2-3. Internal Block Diagram Shown below is the internal block diagram of an AB935N module. Figure 2.2 Internal block diagram Shield...

  • Page 17: Installation Conditions And Precautions

    3. INSTALLATION CONDITIONS and PRECAUTIONS 3. INSTALLATION CONDITIONS and PRECAUTIONS Installation procedures and precautions for AB935N modules and ABSOCODER sensors are described. For details about base unit installation, TC-net I/O bus cable connection and the startup and shutdown procedures, refer to the High-speed Serial I/O System TC-net I/O Instruction Manual (Toshiba Corporation). 3-1.

  • Page 18: Installing The Ab935N Module

    3. INSTALLATION CONDITIONS and PRECAUTIONS 3-2. Installing the AB935N Module This section explains about the installation of an AB935N module to the base unit (BU902). ●Installation (1) Hook the module to the slot on the bottom of the AB935N module in the lower part of the base unit, and rotate it to fit the connector.

  • Page 19: Absocoder Sensor Installation Conditions And Precautions

    3. INSTALLATION CONDITIONS and PRECAUTIONS 3-3. ABSOCODER Sensor Installation Conditions and Precautions The installation conditions and precautions for ABSOCODER sensor are described in this section. (1) Do not apply excessive forces to the cable port, and avoid damaging the cable. (2) The part of a machine mounted the sensor rod must travel in the same direction as the sensor rod extends and contracts.

  • Page 20: Replacing The Ab935N Module

    3. INSTALLATION CONDITIONS and PRECAUTIONS 3-4. Replacing the AB935N Module This section provides precautions when replacing an AB935N module. (1) AB935N modules can be replaced while the system is energized or not energized. When replacing them while the system is energized, set the maintenance switch to the up (MAINT) position for the AB935N module.

  • Page 21: External Wiring

    Power Connect the power for external inputs and the sensors. supply *1: A wire color indicates the color of the NSD extension sensor cable. *2: Both violet and gray wire aren't used. NOTES The power supply (P24, Z24) is intended for both external inputs and the sensors.

  • Page 22: Absocoder Sensor Connection

    4. EXTERNAL WIRING 4-1. ABSOCODER Sensor Connection This section explains about ABSOCODER sensor connection. 4-1-1. Sensor Cable Wiring Precautions ●Sensor cable length The length of the extendable cable has a limitation depending on the models of ABSOCODER sensor and sensor cable. For more details, refer to “8-2. ABSOCODER Sensor Specifications ". ●Wiring precautions (1) The sensor cable should be clamped as shown in the right figure to prevent excessive tension from...

  • Page 23: Connection Configure Example Of The Sensor Cable

    4. EXTERNAL WIRING 4-1-2. Connection Configure Example of the Sensor Cable The following are examples of sensor cable connection. ● Using connectors BU902 ABSOCODER sensor Extension sensor cable AB935N Terminal No. and wire color BU902 Signal Wire Color Terminal No. Names 1 [19] Brown...
  • Page 24 4. EXTERNAL WIRING ● Using crimping terminals BU902 Extension sensor cable ABSOCODER sensor AB935N Crimping terminal Crimping terminal Crimping terminal (R1.25-4) (R1.25-4) (R1.25-4) BU902 Signal Wire color Wire color Signal names Wire color Signal names Terminal No. names 1 [19] Brown Brown Brown...

  • Page 25: Input Signal Wiring

    4. EXTERNAL WIRING 4-2. Input Signal Wiring For input signal wiring, make sure to use a cable sized in the range of 0.75 to 2 mm 4-3. Power Supply Connection Describes about the power supply connection. (1) The power supply should be isolated from the commercial power supply. (2) Choose the power supply capacity which is more than twice the power consumption.

  • Page 26: Function

    5. FUNCTION 5. FUNCTION 5-1. Function List As shown in table 5.1, the AB935N module functions. Table 5.1 Function List Items Descriptions Position data The machine position will be detected using the ABSOCODER sensor. detection function The position data value will be corrected to "0" upon any of the following actions: Origin setting - Turning the external-input “origin setting"...

  • Page 27: Operation Sequence

    5. FUNCTION 5-2. Operation Sequence START -------- Refer to section 5-3-6 Parameter switch setting Set the parameter switches on the back of the AB935N module. -------- Refer to section 5-3-5 Slot address setting Set the slot address setting switch (SLT ADR). -------- Refer to section 3 Device installation (1) Install the AB935N module to the base unit BU902.

  • Page 28: Nomenclature

    5. FUNCTION 5-3. NOMENCLATURE This section explains about the AB935N module component names and functions. 5-3-1. Component Names Front of the panel Back Module state display LED Parameter switch Function switch Maintenance switch Slot address setting switch...

  • Page 29: Module State Display Led

    5. FUNCTION 5-3-2. Module State Display LED Shown below is the list of LEDs provided on the AB935N module panel and the description of what each LED indicates. Refer to 7-1 for the details of the errors indicated. LED name Description : Module is normal or in maintenance (maintenance switch in the upper position) Normal...

  • Page 30: Maintenance Switch (Maint)

    5. FUNCTION 5-3-4. Maintenance Switch (MAINT) This switch is used only when the module is inserted or removed online. Insertion or removal is performed when the switch is set to the up (MAINT) position to separate the module from the system. When insertion is complete, the switch is returned to the down (RUN) position for normal operation.

  • Page 31: Parameter Switch (Back Of The Panel)

    5. FUNCTION 5-3-6. Parameter Switch (back of the panel) This section explains about AB935N module parameter switches Parameter Name Switch setting Description : Disabled When this switch is set to the ON position, error will not occur even if Axis 1 disabled : Enabled Axis 1 sensor is not connected.

  • Page 32: Input And Output Data

    5. FUNCTION 5-4. Input and Output Data 5-4-1. I/O Word List Each of the input data and output data into the AB935N module are separately assigned to one of the I/O word numbers listed below. Input data Output data I/O word No. I/O word No.
  • Page 33 5. FUNCTION ●Status The "Status" bits store error information, Refer to 7-1 for the details of the errors indicated. Signal Name Indication Description (Status Name) 1: Unset The origin is unset. Origin unset 0: Set Reserved 0: Fixed 1: Origin setting possible Origin setting can be performed.

  • Page 34: Output Data

    5. FUNCTION 5-4-3. Output Data Axis 1 data I/O word No. I/O word No. OS1 RES Axis 1 command Axis 2 data I/O word No. I/O word No. OS2 RES Axis 2 command ●Command Commands can be used for origin setting or error cancelling. Signal Name Indication Description...

  • Page 35: Origin Setting Operation

    5. FUNCTION 5-5. Origin Setting Operation Completing the origin setting operation will change the position data value to "0". In the following situations, the origin will be unset and therefore origin setting needs to be performed. - Immediately after power-on - When the maintenance switch has been switched from "MAINT"...

  • Page 36: Error Cancelling Operation

    5. FUNCTION 5-6. Error Cancelling Operation Errors other than "Origin Unset" can be cancelled by performing one of the following actions after resolving the error cause: - Pressing the function switch "CLR" on the module panel. - Turning the external-input error cancelling signal ON. - Setting the RES command output to "1".

  • Page 37: Inspections

    6. INSPECTIONS 6. INSPECTIONS The inspection should be conducted once every 6 months to a year. Any inspected items which do not satisfy the criteria shown below should be repaired. Inspection Inspection description Criteria Remark item Power Measure the voltage fluctuation of the power supply to Within 20.4 to 26.4VDC Tester supply...

  • Page 38: Troubleshooting

    7. TROUBLESHOOTING 7. TROUBLESHOOTING Error causes and countermeasures are described below. 7-1. Error List When an error has occurred related to the AB935N module or the ABSOCODER sensor, the module state display LED “ER1” or “ER2” will come on (or blink) and the input data states will change. Refer to the following list to resolve the error.
  • Page 39 7. TROUBLESHOOTING NOTES The origin will become unset after an error is cancelled (BOS = 1). Be sure to perform origin setting after cancelling an error. About error cancelling and origin setting methods, refer to 5-6, "Error Cancelling Operation", and 5-5, "Origin Setting Operation".

  • Page 40: Absocoder Sensor Check List

    7. TROUBLESHOOTING 7-2. ABSOCODER Sensor Check List ●Applicable ABSOCODER sensor models VLS-8SM20 VLS-8SM14 VLS-8SM14S ●Connection configuration ABSOCODER sensor Module Extension sensor cable BU902 Input terminal block ●Connector appearance and pin position View ① A1, B1 ① ●Connector pin position and standard coil resistance ranges (at 25℃) Check position Standard coil resistance [Ω] Signal...
  • Page 41 *1: If a check is done at Point B, the measurement value wil be [Standard coil resistance + extension sensor cable resistance]. Extension sensor cable resistance value The resistance value of the NSD special cable is 0.2Ω/m (loop resistance). Consider resistance variations due to temperature, which, relative to the standard temperature (25 increases 0.4% when the temperature rises 1 C and decreases 0.4% when the temperature falls 1...

  • Page 42: Specifications

    8. SPECIFICATIONS 8. SPECIFICATIONS 8-1. AB935N Module Specifications 8-1-1. General Specification Items Specifications Power supply voltage 24VDC (＋10%, －15%) For TC-net I/O (supplied to SA911) Power consumption 0.1A or less (at 24VDC) For sensors and Power supply voltage 24VDC (＋10%, －15%) external inputs Power consumption 0.2A or less (at 24VDC)

  • Page 43: Performance Specification

    8. SPECIFICATIONS 8-1-2. Performance Specification Items Specifications Number of detection axes Position detection format Semi-absolute format Photo-coupler isolation Isolation format (between TC-net I/O circuit and sensor circuit) Resolution 1μm (8.192 mm / 8192 divisions) Standard pitch x number of pitches Total number of divisions [8192 divisions (2 ) x 2048 pitches = 16777216(2...

  • Page 44: External Input Specification

    8. SPECIFICATIONS 8-1-3. External Input Specification Items Specifications Number of input points 3 points (Origin setting: 2, Error cancel: 1) Isolation format Photo-coupler isolation Rated input voltage 24VDC (＋10%, －15%) Input voltage range 20.4 to 26.4VDC *1 Rated input current 5.2 mA ON voltage 16.8VDC or more...

  • Page 45: Absocoder Sensor Specifications

    8. SPECIFICATIONS 8-2. ABSOCODER Sensor Specifications (1) VLS-8SM20 Items Specifications Model VLS-8SM20 Max. detection stroke 350 mm Absolute detection range 8.192 mm Resolution 1μm(8.192mm/8192) Linearity error Customer's Special Specifications Head 4.5+0.15 x [cable length(m)] kg Mass 0.4+0.0025 x [stroke (mm)] kg Sliding resistance 69 N or less (7kgf or less) Permissible mechanical speed...
  • Page 46 8. SPECIFICATIONS (2) VLS-8SM14, VLS-8SM14S Items Specifications Model VLS-8SM14 VLS-8SM14S Max. detection stroke 200 mm Absolute detection range 8.192 mm Resolution 1μm(8.192mm/8192) Linearity error Customer's Special Specifications Head 1.1+0.07 x [cable length(m)] kg 0.8+0.07 x [cable length(m)] kg Mass 0.0012 x ([rod length (mm)] kg Sliding resistance 15 N or less (1.5kgf or less) Permissible mechanical speed...

  • Page 47: Sensor Cable Specification

    Color of sheath Dark brown Blue Black Heat treatment and Extensible for long Advantage Superior flexibility; ideal for moving place flexible; ideal for distances moving place REMARKS Contact your NSD representative when the extension cable combines different types of cables.

  • Page 48: Outer Dimensions

    9. OUTER DIMENSIONS 9. OUTER DIMENSIONS 9-1. AB935N Module Units: mm...

  • Page 49: Absocoder Sensor

    9. OUTER DIMENSIONS 9-2. ABSOCODER Sensor (1)VLS-8SM20-[ ]FA[ ] (Flange-mount type) Units: mm (2)VLS-8SM20-[ ]LA[ ] (Base-mount type)
  • Page 50 9. OUTER DIMENSIONS (3)VLS-8SM14-[ ]FB[ ] (Flange-mount type) Units: mm (4)VLS-8SM14S-[ ]LB[ ] (Flange-mount type)

  • Page 51: Extension Sensor Cable

    9. OUTER DIMENSIONS 9-3. Extension Sensor Cable (1) 3S-S-9044-[L] / 3S-RBT-9044-[L] /3S-URT-9044-[L] Units: mm NOTE: [L] is given in terms of meter. (2) 3S-S-4344-[L] / 3S-RBT-4344-[L] / 3S-URT-4344-[L] NOTE: [L] is given in terms of meter. (3) 3S-HRT-5152-[L] NOTE: [L] is given in terms of meter.
  • Page 52 9. OUTER DIMENSIONS (4) 3S-S-9090-[L] / 3S-RBT-9090-[L] / 3S-URT-9090-[L] Units: mm NOTE: [L] is given in terms of meter. (5) 3S-HRT-9090-[L] NOTE: [L] is given in terms of meter. (6) 3S-HRT-9052-[L] NOTE: [L] is given in terms of meter.
  • Page 53 9. OUTER DIMENSIONS - MEMO -...

  • Page 54: Appendix 1. Ce Marking

    APPENDIX APPENDIX 1. CE MARKING The AB935N module conforms to EMC directive. APPENDIX 1-1. EMC Directives It is necessary to do CE marking in the customer’s responsibility in the state of a final product. The customer should confirm EMC compliance of the machine and the entire device because EMC changes configuration of the control cabinet, wiring, and layout.

  • Page 55: Appendix 1-4. Measures For Emc Compliance And Restriction

    APPENDIX APPENDIX 1-4. Measures for EMC Compliance and Restriction In this section, restrictions are described for conforming the AB935N module to the EMC Directive. For conforming the Toshiba Corporation Unified Controller nv Series to the EMC Directive, contact Toshiba Corporation. ①Install the zippertubing around the cable when the sensor cable is used in 30m or more.
  • Page 56 Manufacturer NSD Corporation 3-31-28, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Distributor NSD Trading Corporation 3-31-23, OSU, NAKA-KU, NAGOYA, JAPAN 460-8302 Phone: +81-52-261-2352 Facsimile: +81-52-252-0522 URL: www.nsdcorp.com E-mail: foreign@nsdcorp.com Copyright©2020 NSD Corporation All rights reserved.
