Summary of Contents for Brunner BKH
- Page 1 Bedienungs A N L EI T UNG User M A NUA L...
- Page 3 english green User GUI DE...
- Page 4 Hubertus Brunner, Ulrich Brunner EN | 40...
- Page 5 FOREWORD As a family business, we at BRUNNER can look back on a history rich in tradition of more than 70 years. For three generations, we have been manufacturing firing systems in Eggenfelden, Lower Bavaria, which are among the best in the industry. The quality seal “Made in Germany” is not an advertising term for us, but a binding promise.
- Page 6 BKH flat 4266 with lifting door EN | 42...
-
Page 7: Table Of Contents
Components of BKH flat • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 55 The nonobservance of installation and operating instructions will void Components of BKH flat tunnel •... - Page 8 EN | 44...
-
Page 9: Guarantee Bond
BRUNNER devices are high quality products that have proven themselves a thousand times this fact and our wealth of experience have led us to provide this unique guarantee. We wish you a lot of joy with your BRUNNER device, the friend for a life time. Hubertus Brunner ... -
Page 10: Safety Precautions
Risk of fire! Do not leave any objects from flammable The combustion chamber door materials in front of the fireplace door/glass pane. BRUNNER fireplaces are only intended for operation with the combustion chamber door closed. In the case of open operation or opening during Tunnel variants combustion, there is a risk of heating gases escaping into the living area. -
Page 11: Basic Rules For Operation Basic
BRUNNER heating inserts are designed and optimized for closed opera tion. Stoves and fireplaces from Ulrich Brunner GmbH are designed for periodic burning. It means that always a minimal amount of firewood has to be loaded and the combustion air must be adjusted according to the follow... - Page 12 Heating between seasons devices cannot be modified. Structural changes to the building If changes are planned and made in or on the building, the conditions for safe and proper operation of the fireplace can be significantly disrupted. The prerequisites for safe operation of the fireplace must therefore be checked by a specialist in the event of changes.
- Page 13 • Do not clean the surfaces with steel/wire brushes or cleaning agents. Door sealing ropes BRUNNER is using only highquality door sealing ropes, which are exactly adapted to the requirements of our heating devices. Yet the door sealings are wear parts, and therefore are not covered by our product warranty.
-
Page 14: Fuel And Heating Power
05 FUEL AND HEATING POWER The standard combustion process "green"has been optimized to enhance their performance and reduce emissions. You can support our efforts to protect our environment by respecting the following recommendations for lowemission heating: Use only dry, natural wood with a residual humidity factor below 20 %, or wood briquettes according to DIN EN 172253. - Page 15 What amount of heat will I get when buying wood per weight What amount of heat will I get when buying wood per volume (1 cubic meter = 1 m RM = cubic metre 500 kg Water content 500 kg x 2,0 kWh/kg = 1000 kWh 1 cubic meter freshly cut wood Water content 50 % 1286 kWh...
- Page 16 Most suitable for use in open fireplaces are all types of hardwood, like beech or birch. Softwood species (conifers) have a closedcell structure which is bursting during combustion, causing glowing embers to be thrown out of the fireplace. Hardwood is burning more calm and evenly. You can control the heat radiation intensity by volume of wood and the intervals for stoking up.
- Page 17 Fireplace Recommended load volume Log length BKH Flat 42-50 1,5 - 3 kg 25 - 33 cm BKH Flat 42-66 2 - 4 kg 25 - 33 cm BKH Flat 42-98 2 - 5 kg 25 - 33 cm BKH Flat 50-82...
- Page 18 BKH flat 4266 with lifting door Combustion chamber lining cast iron EN | 54...
-
Page 19: Components Of Bkh Flat
06 COMPONENTS OF BKH FLAT Image 1: BKH Flat with side opening door Image 2: BKH Flat with lifting door 1 Cast iron dome with connecting piece 2 Body 3 Door with ceramic glass pane 4 Door handle (side opening door)/Plugin handle (lifting door) 5 Combustion air... - Page 20 BKH Tunnel 4266 lifting door side opening door Combustion chamber lining cast iron EN 56 EN | 56...
-
Page 21: Components Of Bkh Flat Tunnel
07 COMPONENTS OF BKH FLAT TUNNEL Image 1: BKH Tunnel with side opening door Image 2: BKH Tunnel with lifting door 1 Cast iron dome with connecting piece 2 Body 3 Door with ceramic glass pane 4 Door handle (side opening door)/Plugin handle (lifting door) 5 Combustion air... - Page 22 BKH Corner 426642 l Combustion chamber lining chamotte EN | 58...
-
Page 23: Components Of Bkh Corner
08 COMPONENTS OF BKH CORNER Image 1: BKH Corner with side opening door Image 2: BKH Corner with lifting door 1 Cast iron dome with connecting piece 2 Body 3 Door with ceramic glass pane 4 Door handle (side opening door)/railing (lifting door) 5 Combustion air adjusting... -
Page 24: Adjusting Of Combustion Air
09 ADJUSTING OF COMBUSTION AIR Fireplace inserts have an opening in the floor area through which the required combustion air flows in. The air is either supplied via an outside air connection (air connection box) or directly from the room. During combustion, the combustion air volume is adjusted by a control air lever on the fireplace. -
Page 25: The Heating Process
10 THE HEATING PROCESS green The new standard of BRUNNER fireplaces is called “green”. With the right fuel and the right operation, a BRUNNER fireplace can be operated with the lowest possible emissions. The combustion chamber is designed as a trough firebox without a grate or ash box. - Page 26 Arrangement of logs inside the combustion chamber and placement of fire starters and small pieces of wood. Firestarter (e.g. BRUNNER Fidibuss) and small wood chips are lit among the pieces of wood in the upper layer. Remember: The quicker the fire is lit, the lower the emissions!
- Page 27 We recommend position 2 for maximum load of wood and position If no wood is added, the combustion air can be shut off – Position 3. in case of smaller loads. Combustion air adjusting lever „OFF“: Position 3 Combustion air adjusting lever „ Main burning phase“: For maximum load of wood and The combustion air must not be closed during burning (danger of position 2 in case of smaller loads.
- Page 28 10.2 STOKING FIRE IN A WARM FIREPLACE 1. Set the combustion air adjusting lever to “lighting up” (Position 1 = 3. We recommend position 2 for maximum load of wood and position 100 % OPEN).(Position 1 = 100 % Open) in case of smaller loads.
- Page 29 5. If no wood is added, the combustion air can be shut off – Position 3. Combustion air adjusting lever „OFF“: Position 3 The combustion air must not be closed during burning (danger of deflagration)! EN | 65...
-
Page 30: Cleaning
11 CLEANING Damage of sealing ropes arising from inappropriate operation or cleaning are excluded from warranty. Once in a year, when the heating season begins, make sure to inspect the Please follow the safety precautions regarding the handling of ashes smoke pipe and/or additional reheating systems for ashes and residues. -
Page 31: Cleaning Of Catalytic Converter (Optional)
12 CLEANING OF CATALY TIC CONVERTER 1. Removal of deflector plates Deflector plates are installed above the combustion chamber and can (OPTIONAL) be removed without any tools through the open fireplace door. Remove the ash deposits from deflector plates with a vacuum cleaner. A coat of dry, powderlike deposits will build up with time on the inflow The lower deflector consists of two plates which are placed close to side of the catalytic converter modules. - Page 32 2. Catalytic converter cleaning The catalytic converter inserts are placed in their mounting frames. Pay attention to avoid damage of the inserts during cleaning. We recommend cleaning with a vacuum/ash cleaner with brush attach ment. Doing so, it is possible to remove and evacuate the adhering CAUTION: The catalytic converter unit can be cleaned only in dry particles sufficiently.
-
Page 33: Note
13 NOTE In case of damage to the fireplace or other parts of the system, please contact your stove fitter immediately. In case of severe damage of door sealing ropes do not use the fireplace. To ensure safe operation of the system, remember to use only genuine replacement parts. -
Page 34: Troubleshooting
A room ventilator (e.g. extractor hood) or mechanical ventilation Turn off the room ventilator or mechanical ventilation system. system is causing negative pressure in the room, which is Install a negative pressure monitoring device (e.g. Brunner USA). stronger than the chimney draft. Combustion air supply is blocked. - Page 35 Problem Cause Solution Glass panes are often dirty Unsuitable fuel. Wood is damp or too big pieces of firewood are used. Please use the recommended fuel as indicated in these instructions. Insufficient combustion air supply. Set the combustion air lever in position 1 or position 2. Check the combustion air supply and smoke outlet.
-
Page 36: Disposal
15 DISPOSAL Recycling of catalytic converters containing precious Fireplace inserts contain valuable materials that must be recycled. Observe metals the applicable national legal regulations for disposal. Oxidative catalytic converters, as installed in modern wood stoves, are very effective at reducing emissions of carbon monoxide and hydrocarbons. Danger of electrocution This is possible, because precious metals like platinum, palladium and Electrical connections of the fireplace insert are under mains voltage. - Page 37 3. Glow position 2. Main combustion phase for min. and max. filling quantity 1. Lighting up max. heating power "Combustion air setting" template for placing on the operating side of the fireplace EN | 73...
- Page 38 +49 8721 771-100 info@brunner.eu brunner.eu BRUNNER products are offered and sold exclusively by qualified dealers. Techni cal and rangerelated changes as well as errors reserved. All images may contain additional functions or special equipment that are subject to a surcharge. Reprint...
- Page 40 +49 8721 771-100 info@brunner.de brunner.de BRUNNER products are offered and sold exclusively by qualified dealers. Technical and rangerelated changes as well as errors reserved. All images may contain additional functions or special equipment that are subject to a surcharge. Reprint...
