- Page 1 THE PROFESSIONAL VENT HOODS Use and Installation Guide Models: DCS-VH-48HS DCS-VH-48S DCS-VH12-36HS DCS-VH12-36S DCS-VH-36HS DCS-VH-36S DCS-VH-30HS DCS-VH-30S...
- Page 2 To help serve you better, please fill out and return the Ownership Registration Card and keep this guide handy, as it will help answer questions that may arise as you use your New Vent Hood. For your convenience, product questions can be answered by a DCS Customer Service Representative by phone: 1-888-281-5698, or Fax: 714-372-7003, or by mail: Dynamic Cooking Systems, Inc.
-
Page 3: Table Of Contents
Before proceeding with installation, please read this installation guide and observe all safety precautions and warnings. NOTE: Installation of this DCS Vent Hood must comply with all local codes. IMPORTANT - Save these instructions for the Local Electrical Inspector’s use. - Page 4 Ventilator Use: TABLE A: Vent Hood Model use with Ventilator Model DCS-VH-48HS DCS-IB12 (1200 CFM) DCS-VH-48S DCS-IB12 (1200 CFM) DCS-VH12-36HS DCS-IB12 (1200 CFM) DCS-VH12-36S DCS-IB12 (1200 CFM) DCS-VH-36HS DCS-IB6 (600 CFM) DCS-VH-36S DCS-IB6 (600 CFM) DCS-VH-30HS...
-
Page 5: Backdraft Damper
Vent Hood to avoid personal injury or damage to the Hood. INNER LINER REMOVAL: The DCS Professional Vent Hood has been designed into (2) major assemblies to accommodate easy and safe installation. The following procedure is best done with the Hood on its back on a padded sur- face. - Page 6 Hood Inner Liner (Remove) ( 48" Model Liner Shown) control panel FIG.07 L. Heat Lamp (not all models) DCS Duct Cover (6" or 12" Height) Rough-In Kit junction box Model DCS-IB12 Blower DCS VH 48 DCS VH12 36 Model DCS-IB6 Blower...
-
Page 7: Site Preparation
SITE PREPARATION This DCS Professional Vent Hood has been designed to accommodate installation into a 1) soffit structure (ceiling mount), or, for sites without a soffit structure. 2) directly into the wall through holes provided in the rear panel of the vent hood (wall mount). When mounting the hood to a soffit, it is recommended to also utilize the rear panel holes to gain addi- tional stability and minimize any vibration noise. -
Page 8: Vent Hood Assembly
INSTALL VENT HOOD INTO SOFFIT At this point in the installation process, the inner liner should be removed from the Hood and set aside (see-Pgs 5 & 6).With the liner set aside, there is clear access to the Soffit mounting holes and wall mounting holes in the rear panel of the unit. -
Page 9: Wall Mounting
NOTE- The DCS Duct Cover should be ordered and installed when installing the vent hood in a site without a soffit. DCS offers both a 6” and 12” height Duct Covers. Keep the 6 or 12 inch dimension in mind when allow- ing for clearance between the top of the Vent Hood and the ceiling. -
Page 10: To Finish The Installation
TO FINISH THE INSTALLATION Once the ventilation hood has been mounted in place it will be necessary to install the electrical service. All electrical work should be done by a qualified electrician and must conform to all local standards. Refer to the wiring diagrams on Pgs. - Page 11 DCS VH 48 / DCS VH12 36 REQUIREMENTS - DCS recommends the use of 10” round ducting which provides 78.6 sq. In. of surface area. - Alternate duct sizes in rectangular style may be used. If a rectangular duct style is used, the duct must equal at least 78.6 sq.
- Page 12 23-1/2" 10-1/4" 18-1/4" 10-1/4" MODEL DCS IB12 BLOWER AND ROUGH IN KIT MODEL DCS IB6 BLOWER MODEL DCS IB12 BLOWER DCS VH SERIES SOFFIT CHIMNEY 7-1/4" 3/4" 3" 10-1/4" MODEL DCS IB6 BLOWER AND ROUGH IN KIT VOLTS HZ AMPS CFM DUCT 7”...
-
Page 13: How To Obtain Service
2) Is there a power outage in the area? For warranty service, contact your local DCS authorized service agency. Provide him with the Model Number, Serial Number, and date of installation, and a brief description of the problem. If you need assistance in locating the authorized service agency in your area please contact our DCS Customer Service Department for an authorized service agent near you, our number is (888) 281-5698. -
Page 14: Warranty
DCS WILL NOT PAY FOR • Installation or start-up. - Page 15 48" VENT HOOD WIRING DIAGRAM JUNCTION BOX (L1) (GROUND) WN-3 MOTOR PLUG CONNECTORS: 1 2 3 4 5 6 FEMALE 1 2 3 4 5 6 MALE USED ON LEFT HEAT HS MODELS LIGHT ONLY brass zinc LEFT LIGHT LEFT HEAT LIGHT SWITCH 1200 CFM MOTOR...
- Page 16 36" / 30" VENT HOOD WIRING DIAGRAM 600 CFM MOTOR USED ON HEAT HS MODELS LIGHT ONLY brass zinc LEFT LIGHT HEAT LIGHT SWITCH SWITCH WN-3 BLOWER MOTOR SPEED CONTROL WN-2 WN-1 JUNCTION BOX (L1) (GROUND) CONNECTORS: 1 2 3 4 5 6 FEMALE 1 2 3 4 5 6 MALE RIGHT LIGHT...
- Page 18 5800 Skylab Road, Huntington Beach, CA 92647 Tel: (714) 372-7000 Fax: (714) 372-7001 Parts/Customer Service (888) 281-5698 www.dcsappliances.com As product improvement is an ongo- ing process at DCS, we reserve the right to change specifications or design without notice. Part No. 10607r4...
