• Ironman 4x4 SSR087 Side Steps to suit Chevrolet Silverado.
• It will take approximately 1.5 hours to install.
• Read instructions fully before commencing fitment. Check hardware kit contents against
content list below. Do not use this product for any vehicle make or model, other than
specified in these instructions.
• Do not remove labels from this Raid product. It is good practice to record the batch
number on the customer's job card for future reference.
WARNING: This product has been tested for side air bag compatibility and therefore
the mounting system MUST NOT be modified. The operations of the side air bags are
not affected if installation is followed in accordance to these instructions.
IMPORTANT: Raid Accessory installations should only be done by a qualified person,
©Copyright 2022 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
RAID SIDE STEPS TO SUIT CHEVROLET SILVERADO
and it is the responsibility of this person to ensure correct fitment.
INSTALLATION
GUIDE
SS087
