• Ironman 4x4 SS075 Side Steps to suit Ram DS.
• It will take approximately 1.5 hours to install.
• Read instructions fully before commencing fitment. Check hardware kit contents against
content list below. Do not use this product for any vehicle make or model, other than
specified in these instructions.
• Do not remove labels from this Raid product. It is good practice to record the batch
number on the customer's job card for future reference.
WARNING: This product has been tested for side air bag compatibility and therefore
the mounting system MUST NOT be modified. The operations of the side air bags are
not affected if installation is followed in accordance to these instructions.
IMPORTANT: Raid Accessory installations should only be done by a qualified person,
©Copyright 2022 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
and it is the responsibility of this person to ensure correct fitment.
INSTALLATION
RAID SIDE STEPS TO SUIT RAM DS
GUIDE
SS075
Advertisement
Table of Contents
Related Manuals for Ironman4x4 SS075
Summary of Contents for Ironman4x4 SS075
- Page 1 GUIDE SS075 RAID SIDE STEPS TO SUIT RAM DS • Ironman 4x4 SS075 Side Steps to suit Ram DS. • It will take approximately 1.5 hours to install. • Read instructions fully before commencing fitment. Check hardware kit contents against content list below.
- Page 2 Installation Guide SS075 Before Installation IMPORTANT: This product and or hardware must not be modified in any way. BULL BAR CARE INSTRUCTIONS: To maintain finish of the product, wash regularly using a PH neutral Car wash, hose off and chamois dry. Do not use acidic or alkaline cleaners. Plastic components can be maintained with a silicon spray or similar (non-acidic or alkaline based) The fitting instructions are correct at the time of publication date.
- Page 3 Installation Guide SS075 Side Step Parts List 1. Side Step LHS 2. Side Step RHS QTY-1 QTY-1 3. M10 Spring Holder 4. PVC Bolt Holder 5. Spacer 6. T-Bolt, flat/spring 7. T-Bolt, flat/spring Sheet Φ10 washers, nut washers, nut M10×1.5×35mm M8×1.25×35mm...
- Page 4 Installation Guide SS075 Before installation, check the Raid side steps application is compatible with your vehicle. If vehicle has factory fitted side steps remove now. Unwrap the hardware and sidesteps. It is good practice to lay out all hardware and cross reference against the parts list.
- Page 5 Installation Guide SS075 Start on the right-hand side of the vehicle. Locate the two holes on the front of the side of the chassis rail and the hole directly under the chassis rail. Feed the wire into the chassis and pull through the lower...
- Page 6 Installation Guide SS075 Using 2 x bolt plates, slide up into the factory chassis holes and hold into place with plastic holders. 10. Now move the rear. Locate the 2 x rear factory chassis holes, feed the bolt plate into place, and hold bolt plate in place with plastic holder.
- Page 7 Installation Guide SS075 11. Once steps are aligned and square tighten to torque specs on page 3. 12. Repeat steps 5-12 on the left side of vehicle. NOTE: pay attention to the handbrake cable on the left-hand side so not to damage cable.
- Page 8 Installation Guide SS075 Once the Raid Side Steps are Installed Ensure all bolts are tensioned correctly, it is good practice to do a vehicle pre trip check before heading away or every 10k kms. Visually inspect bull bar and hardware, retention bull bar hardware or when needed.
