Installation Instructions
Bored Lock
Attention Installer:
Please read these instructions carefully to prevent missing important steps.
Improper installations may result in damage to the lock and void the factory warranty.
The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For specific security information, please contact your local ASSA ABLOY
Door Security Solutions sales consultant or call 800-810-9473.
Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing
Company is prohibited.
Patent pending and/or patent - www.assaabloydss.com/patents.
HID, iCLASS, and Edge are trademarks or registered trademarks of HID Global Corporation.
IN
Series
IN100 with
Aperio
Technology
®
10X Line
A8357-2 05/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the SARGENT IN100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Assa Abloy SARGENT IN100 Series

Summary of Contents for Assa Abloy SARGENT IN100 Series

  • Page 1 For specific security information, please contact your local ASSA ABLOY Door Security Solutions sales consultant or call 800-810-9473. Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    IN100 10X Line Bored Lock Table of Contents Warning ........................3 Product & Technical Specifications ..............4 Parts Breakdown ....................5 Lock Installation ....................7 Operational Check ....................15 Communication Hub LED Indications ..............16 Lock LED Indications ...................17 Lock Self-Test LED Indications ................18 Lock Busy LED Indications ..................19 A8357-2 •...

  • Page 3: Warning

    Ce produit peut vous exposer au plomb qui, dans l’état de la Californie, est reconnu pour causer le cancer, des anomalies www.P65warnings.ca.gov congénitales ou d’autres problèmes de reproduction. Pour plus d’informations, visitez: Changes or modifications to this device not expressly approved by ASSA ABLOY could void the user’s authority to operate the equipment. FCC: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 4: Product & Technical Specifications

    IN100 10X Line Bored Lock Product & Technical Specifications Operating temperature: -13°F (-25°C) to 151°F (66°C) Humidity: < 85% non-condensing Input Power: DC 9V, 1.5A (6 AA alkaline batteries) Optional hard-power 12-24VDC, 1.0A Reader with multiCLASS SE technology offers support for the following credentials: ®...

  • Page 5: Parts Breakdown

    IN100 10X Line Bored Lock Parts Breakdown Tools Required: • #2 Phillips screwdriver • 1/8" Security Hex Key ITEM DESCRIPTION Outside Escutcheon Assembly Inside Mounting Plate Assembly WiFi Controller Assembly AA battery (alkaline only) Inside Escutcheon Assembly with Privacy Button *Consult catalog for electronic replacement part numbers.
  • Page 6 IN100 10X Line Bored Lock Parts Breakdown continued ITEM DESCRIPTION Outside Lever (Reference Catalog for Available Styles) Push Pin Cylinder Assembly (Reference Catalog for Available Cylinders) Rose (Reference Catalog for Available Styles) Outside Rose Spring Assembly Lockbody Assembly 10XG77 Adapter Plate/Spacer (Only Included With 1-Option) Latch Assembly Screws - Latch (2) #8-32 x 3/4”...

  • Page 7: Lock Installation

    IN100 10X Line Bored Lock Lock Installation 1. Prepare door. a. Verify hand and bevel of door. (Fig. 1) NOTE: Stand on outside of locked door when determining door hand. b. Prepare door according to appropriate template. (Fig. 2) See website LHRB www.intelligentopenings.com.
  • Page 8 IN100 10X Line Bored Lock Lock Installation continued 2. Install strike in door frame. (Fig. 3) 3. Install latchbolt. (Fig. 4) a. Install latch with beveled bolt facing strike. (Fig. 5) b. Attach with two (2) screws but DO NOT tighten completely at this time.
  • Page 9 IN100 10X Line Bored Lock Lock Installation continued 5. Adjust lock. Outside a. Lockbody holes are at 12 and 6 o’clock. (Fig. 7) of Door NOTE: • Lock is shipped “preset” and does not require adjustment for 1-3/4" thick doors •...
  • Page 10 IN100 10X Line Bored Lock Lock Installation continued For metal door: For metal door: Feed harness through inside of door (not shown). b. Continue to feed harness into raceway (towards top of door), exiting raceway hole on inside of door. (Fig. 12) c.
  • Page 11 IN100 10X Line Bored Lock Lock Installation continued 8. Secure lock to door. a. Slide inside rose assembly over lockbody. Inside of Door b. Secure rose assembly with two (2) #10-32 x 1-1/4" through-bolts. (Fig 14) c. Secure latch by fully tightening two (2) #8 x 3/4" self-tapping screws (refer to step 3.
  • Page 12 IN100 10X Line Bored Lock Lock Installation continued 10. Install outside reader. NOTE: Cable lengths exaggerated for illustrative purposes. a. Orient reader so LED lens is at top. (Fig. 16) b. Feed cable/connector through door from Outside outside to inside. of Door c.
  • Page 13 IN100 10X Line Bored Lock Lock Installation continued h. Secure the following connectors to their *Optional 12-24VDC Power respective terminals (Fig. 19): Remote Power Harness Wire Terminations CAUTION: Do not touch or allow debris to 2-pin Black PS (-) Return Connector enter connector contacts.
  • Page 14 IN100 10X Line Bored Lock Lock Installation continued Install inside component assembly (controller). a. Insert bottom tab of controller (make sure path is Controller clear into slot on mounting plate. (Fig. 22) b. Ensure proper alignment of board-to-board connectors while pivoting controller toward door until two tabs on top click securely into place on mounting plate.

  • Page 15: Operational Check

    IN100 10X Line Bored Lock Lock Installation continued Install inside cover. (Fig. 25) a. Assemble cover by hooking top edge on inside mounting plate. b. Carefully press bottom of cover toward door without pinching or Inside damaging wires. Cover c. Secure cover utilizing a 1/8" security hex key.

  • Page 16: Communication Hub Led Indications

    IN100 10X Line Bored Lock Communication Hub LED Indications Communication hub has a single LED. It supports an optical scheme of red, green and yellow. Indication scheme is described by figures below: Communication Hub NORMAL OPERATION LED indication 2 sec. Online Green Aperio...

  • Page 17: Lock Led Indications

    IN100 10X Line Bored Lock Lock LED Indications Lock has three (3) LEDs. They support an optical scheme with red, yellow and green. Indication scheme described by figures below: Lock NORMAL OPERATION LED indication EAC response time Enter PIN One yellow flash after card, two flashes Card + PIN access (configurable) before PIN (.125 second) Card access (configurable)

  • Page 18: Lock Self-Test Led Indications

    IN100 10X Line Bored Lock Lock Self-Test LED Indications After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by figures below: Battery Not Fully Charged Error in lock is an indication -10 quick (125ms) red blinks, that either new batteries are not at right voltage or a backward battery has been installed;...

  • Page 19: Lock Busy Led Indications

    IN100 10X Line Bored Lock Lock Busy LED Indications Lock BUSY indicates lock is processing a card (such as a key configuration card for online SE processor or offline void list card with many entries). Card should be kept in close proximity to reader until end of process. Lock BUSY indi- cation does not cancel or overwrite any other indications.
  • Page 20 New Haven, CT 06511 USA 800-727-5477 • www.sargentlock.com Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
