Installation Instructions
IN100
EK1 Exit Device Retrofit Kit
A8277-3 06/2024
1-800-810-9473 • www.sargentlock.com
Copyright © 2021-2022, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express
written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SARGENT IN100 and is the answer not in the manual?

Questions and answers

Related Manuals for Assa Abloy SARGENT IN100

Summary of Contents for Assa Abloy SARGENT IN100

  • Page 1 Installation Instructions IN100 EK1 Exit Device Retrofit Kit A8277-3 06/2024 1-800-810-9473 • www.sargentlock.com Copyright © 2021-2022, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
  • Page 2 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Table of Contents Warning ..................3 General Description.
  • Page 3 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Warning Changes or modifications to this unit not approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference interference in a residential installation.
  • Page 4 Installation Instructions General Description The EK Exit Device Retrofit Kit is designed to link the SARGENT IN100 Series product line with non-SARGENT rim exit devices. The EK Retrofit Kit is designed specifically to link to the Von Duprin 98/99 Series rim exit device. Refer to Von Duprin Retrofit Chart (page 9) for replaceable Von Duprin ®...
  • Page 5 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Installation Instructions *For mechanical (dummy) trim installation, refer to Steps 4, 5, and 7 only. Major Component Assembly Breakdown Item Description Existing Hardware ⊕ Outside Escutcheon Assembly Outside Trim Assembly ⊕ Replacement EK Retrofit Kit P/N IN120-777-5-EK1 or IN220-777-5-EK1 *Replacement for Mechanical...
  • Page 6 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Remove All Von Duprin 98/99 Exit Hardware from Door ® See diagram and part description on page 4 showing existing assemblies to be removed. Inside Door Preparation Verify Hand and Bevel of Door Left Hand Right Hand Reverse...
  • Page 7 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Install Door Position Switch (DPS) 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig. 2C). NOTE: For metal doors, use DPS Collar. 2. Push DPS firmly into place by hand. Inside of Door IMPORTANT: DO NOT TAP SWITCH WITH ANY TOOL.
  • Page 8 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Von Duprin 98/99 Series Rim Exit Hardware Preparation ® Installing and Wiring the Request to Exit - RX Switch (not included) The RX kit must be installed in order for the product to operate as intended. The RX kit can be ordered from an authorized distributor.
  • Page 9 SARGENT Standard, 6 pin 1.37 # 12-24 97-0351 SCHLAGE Standard, 6 pin 1.13 # 12-24 97-0351 ASSA ABLOY ACCENTRA Standard, 6 pin 1.09 # 10-24 97-0352 For other brands with similar dimensions, use appropriate cylinder and collar. A8277-3 06/2024 1-800-810-9473 • www.sargentlock.com Copyright ©...
  • Page 10 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Install Gasket - Required for Exterior Applications For exterior non-fire rated door applications, a gasket must be installed as a weatherseal between the escutcheon and the outside door surface. Attach gasket to the outside escutcheon (Fig. 5). Fig.
  • Page 11 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Mounting the EK Route wires and cables as shown in Fig. 7. Grounding Exit Trim Cable Cable Door Position Switch (DPS) Blue Fig. 7 Wire Nut Yellow Green 1. Connect Exit Device Retrofit Kit (EK) Blue wire to NO (normally open) wire of RX chassis wire. 2.
  • Page 12 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Mount the Outside Reader 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes. Hold the reader flush against door while ensuring proper alignment.
  • Page 13 IN100 EK1 Exit Device Retrofit Kit Installation Instructions 10. Install Outside Reader and Mounting Plate Assembly 1. Route cables/connectors through the inside mounting assembly (and gasket if required*). 2. Insert and partially tighten (2) through-bolts prior to installation of connectors. NOTES: Cable lengths exaggerated for illustrative purpose.
  • Page 14 IN100 EK1 Exit Device Retrofit Kit Installation Instructions 11. Mount the Outside Reader *Optional 12-24VDC Power Remote Power Harness Wire Terminations 1. Secure the following connectors to their respective terminals (Figure 10A): 2-pin Black PS (-) Return CAUTION: Do not touch or allow debris to enter connector contacts. Connector PS (+) 12-24VDC •...
  • Page 15 IN100 EK1 Exit Device Retrofit Kit Installation Instructions 12. Installing the Controller 1. Install inside component assembly (controller). Controller Insert bottom tab of controller (make sure path is clear) into slot on mounting plate. (Figure 11A) Ensure proper alignment of board-to-board connectors while pivoting controller toward door until two tabs on top snap securely into place on mounting plate.
  • Page 16 IN100 EK1 Exit Device Retrofit Kit Installation Instructions 13. Inside Cover Installation 1. Install inside cover. (Figure 12) 1. Assemble cover by hooking top edge on inside mounting plate. 2. Carefully press bottom of cover toward door without pinching or damaging wires. 3.
  • Page 17 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside exit bar retracts latch. • To test cylinder, the following checks apply: Insert key into cylinder and rotate: There should be no friction against lock case, wire harness, or any other obstructions.
  • Page 18 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Communication Hub LED Indications Communication hub has a single LED. It supports an optical scheme of red, green and yellow. Indication scheme is described by figures below: Communication Hub NORMAL OPERATION LED indication 2 sec.
  • Page 19 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Lock LED Lock has three (3) LEDs. They support an optical scheme with red, yellow and green. Indication scheme described by figures below: Lock NORMAL OPERATION LED indication EAC response time Enter PIN One yellow flash after card, two flashes Card + PIN access (configurable) before PIN (.125 second)
  • Page 20 IN100 EK1 Exit Device Retrofit Kit Installation Instructions Lock Self-Test LED Indications After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by figures below: Battery Not Fully Charged Error in lock is an indication -10 quick (125ms) red blinks, that either new batteries are not at right voltage or a backward battery has been installed;...
  • Page 21 IN100 EK1 Exit Device Retrofit Kit Installation Instructions 10. Lock Busy LED Indications Lock BUSY indicates lock is processing a card (such as a key configuration card for online SE processor or offline void list card with many entries). Card should be kept in close proximity to reader until end of process. Lock BUSY indi- cation does not cancel or overwrite any other indications.
  • Page 22 IN100 EK1 Exit Device Retrofit Kit Installation Instructions A8277-3 06/2024 1-800-810-9473 • www.sargentlock.com Copyright © 2021-2022, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
  • Page 23 IN100 EK1 Exit Device Retrofit Kit Installation Instructions A8277-3 06/2024 1-800-810-9473 • www.sargentlock.com Copyright © 2021-2022, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
  • Page 24 1-800-810-9473 • www.sargentlock.com Copyright © 2021-2022, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents. A8277-3 06/2024...
