Assa Abloy Sargent Aperio IN100 Installation Instructions Manual

With technology, mortise lock
Hide thumbs Also See for Sargent Aperio IN100:

Advertisement

Quick Links

A8190B
07/16
Copyright 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
IN100
with Aperio
Technology
Mortise Lock
Installation Instructions
™

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sargent Aperio IN100 and is the answer not in the manual?

Questions and answers

Related Manuals for Assa Abloy Sargent Aperio IN100

Summary of Contents for Assa Abloy Sargent Aperio IN100

  • Page 1 Aperio ™ Technology Mortise Lock Installation Instructions A8190B 07/16 Copyright 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 3: Table Of Contents

    Operational Check ..............19 Lock LED Indications .............20 Warning Changes or modifications to this device not expressly approved by ASSA ABLOY could void the user’s authority to operate the equipment. FCC: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 4: Warning

    • MIFARE Classic • DESfire EV1 *For specific security information, please contact • Low Frequency (125 kHz): your local ASSA ABLOY Door Security Solutions ® • HID Prox sales consultant or call 800-810-WIRE. • NFC-enabled Mobile Phones To comply with “Fire Listed” doors, the batteries must be replaced with alkaline batteries only.

  • Page 5: Parts Breakdown

    IN100 Mortise Lock Parts Breakdown ITEM PART NUMBER/ORDER STRING DESCRIPTION COLOR/TRIM IN-100-EM01[locktype]*-IP-B HID iCLASS , HID iCLASS SE (SIO-enabled), HID iCLASS Seos™, HID MIFARE Black ® ® ® ® SE, HID DESfire ® EV1 SE, HID Prox ® IN-100-EM01[locktype]*-IP-W HID iCLASS , HID iCLASS SE (SIO-enabled), HID iCLASS Seos™, HID MIFARE...
  • Page 6 IN100 Mortise Lock Parts Breakdown (Continued) PART NO/ORDER DESCRIPTION ITEM STRING Consult Factory #41 Mortise cylinder 13-2131 97 Ring IN-100-7976-hand-finish Lock body with deadbolt with cylinder IN-100-7977-hand-finish Lock body with deadbolt without cylinder IN-100-7978-hand-finish Lock body without deadbolt with cylinder IN-100-7979-hand-finish Lock body without deadbolt without cylinder 77-4081...

  • Page 7: Lock Installation

    IN100 Mortise Lock Lock Installation 1 Prepare Door A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Fig. 1A LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right Reverse Bevel Open Inward...
  • Page 8 IN100 Mortise Lock 2 How to Change Hand of Lock body A. Reverse Lock Hand 1. Position lock body so the red surface of the locking piece is visible. 2. Insert blade type screwdriver into locking piece slot to rotate locking piece.
  • Page 9 IN100 Mortise Lock 4 Install Door Position Switch (DPS) 1. Insert DPS into the raceway on the latch edge of the door. 2. Push wires through raceway toward lock prep. 3. Push DPS firmly into place by hand. Door Position Note: DO NOT TAP SWITCH WITH ANY TOOL.
  • Page 10 IN100 Mortise Lock 6 Outside Cylinder Installation 1. Slide the spring and the rosette onto the cylinder. 2. Rotate the cylinder into cylinder hole with fingers. 3. Insert key 75% of the way and utilize the key to rotate the cylinder into the rest of the cylinder hole.
  • Page 11 IN100 Mortise Lock 7 Assemble Outside Trim 1. With outside lever horizontal (and handle pointing toward door hinge), insert the mounting posts through outside of door and lock body. Make certain the lever spindle is properly engaged inside the lock body (Fig 7A). 2.
  • Page 12 IN100 Mortise Lock 8 Install Inside Rose and Inside Lever Assembly 1. Place inside rose flush against door surface and rotate first counter-clockwise to seat the threads, then clockwise to securely tighten. 2. Slide lever onto spindle until fully seated. Be sure handle is horizontal and facing the hinge side of the door.
  • Page 13 IN100 Mortise Lock 9 Install Thumb Turn 1. Insert thumb turn into preparation hole and engage slot in lock body. 2. Orient mounting plate so screw hole is vertical (aligned with preparation holes). 3. Secure plate with Phillips screw provided. 4.
  • Page 14 IN100 Mortise Lock 11 Outside Reader Installation 1. Orient the reader so the LED lens is at the top. 2. Feed the cable/connector through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes. Hold the reader flush against door while ensuring proper alignment.
  • Page 15 IN100 Mortise Lock 11 Outside Reader Installation (Continued) 4. Feed the reader harness and DPS connectors through the inside mounting assembly (and gasket if required*). See Figure 11B. IMPORTANT: Do not run wires through bottom flange hole in plate (Fig. 11B, C) - it will damage wires and the controller connector.
  • Page 16 IN100 Mortise Lock 11 Outside Reader Installation (Continued) Installation of Connectors 9-24VDC DPS (4-pin) CAUTION - Do not touch or allow debris to enter connector contacts. Power* Secure the following connectors to their respective terminals (Fig. 11D): A. Secure the 4-pin DPS connector. B.
  • Page 17 IN100 Mortise Lock 12 Installation of Inside Component Assembly 1. Insert top tabs of controller into slots on mounting plate (Fig. 12). 2. Ensure proper alignment of board-to-board connectors while pivoting bottom of controller toward door until tab on bottom snaps securely into place on mounting plate. CAUTION: To avoid possible damage to board-to-board connectors, care should be taken when securing controller to mounting plate.
  • Page 18 IN100 Mortise Lock 13 Battery Installation 1. Place (6) “AA” alkaline batteries in the compartment, being careful to align polarity properly (Fig. 13). 2. After batteries are installed, there is a slight delay; then red and green flash, audible “beep” and lock motor will cycle. *See Section 8 - LED Indications for more information AA Batteries (6) Fig.

  • Page 19: Operational Check

    IN100 Mortise Lock Operational Check For 7976- and 7978-function mortise locks with cylinders: 1. Insert key into cylinder and rotate. There should be no friction against lock case, wire harness or any other obstructions. 2. Check that the key retracts the latch: the key should rotate freely.
  • Page 20 IN100 Mortise Lock LED Indications The communication hub has a single LED. It supports an optical scheme with red, green and yellow. The indication scheme is described by the figures below: Communication Hub LED indications Figure 1. Communication hub normal operation LED indication 2 sec.

  • Page 21: Lock Led Indications

    IN100 Mortise Lock Lock LED indications The lock has three LEDs. They support an optical scheme of red, yellow and green. The indication scheme is described by the figures below: Figure 4. Lock normal operation LED indication Enter PIN EAC response Card + PIN access time One yellow flash after card, two...
  • Page 22 IN100 Mortise Lock Lock Self-Test LED indication After replacing batteries, a Power on Self Test (POST) is performed. The result is indicated using a series of red and green LED flashes as described by the figures below. LED indication after power up/replacement of the battery 8.3.1 Battery not fully charged Error in lock is an indication -10 quick (125ms) red blinks, that either new batteries are not at the...
  • Page 24 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
