Installation Instructions
Bored Lock
Attention Installer:
Please read these instructions carefully to prevent missing important steps.
Improper installations may result in damage to the lock and void the factory warranty.
The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For specific security information, please contact your local ASSA ABLOY
Door Security Solutions sales consultant or call 800-810-WIRE.
Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Sargent Manufacturing
Company is prohibited.
Patent pending and/or patent - www.assaabloydss.com/patents.
HID, iCLASS, and Edge are trademarks or registered trademarks of HID Global Corporation.
IN
Series
IN120 Wi-Fi
IN220 PoE
10X Line
A8356A 02/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the SARGENT IN 10X Line Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Assa Abloy SARGENT IN 10X Line Series

Summary of Contents for Assa Abloy SARGENT IN 10X Line Series

  • Page 1 For specific security information, please contact your local ASSA ABLOY Door Security Solutions sales consultant or call 800-810-WIRE. Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    IN120 / IN220 10X Line Bored Lock Table of Contents Warning ................3 Regulatory & Power Specifications ......4 Parts Breakdown ............. 5 IN220 (PoE) Wiring and Installation ......7 Lock Installation ............11 Operational Check ............23 A8356A • www.sargentlock.com • 1-800-810-WIRE...

  • Page 3: Warning

    IN120 / IN220 10X Line Bored Lock Warning Changes or modifications to this device not expressly approved by ASSA ABLOY could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Regulatory & Power Specifications

    IN120 / IN220 10X Line Bored Lock Regulatory and Power Specifications Electronic Authentication Specifications (Mobile Credentials) For Mobile Credential-Enabled versions of this electronic lock (Indicated by the credential code in the product order string): • Mobile Credentials are transmitted to the lock via Bluetooth Smart or NFC ISO/IEC14443 and must use a mobile device enabled with these technologies.

  • Page 5: Parts Breakdown

    IN120 / IN220 10X Line Bored Lock Parts Breakdown Tools Required: • #2 Phillips screwdriver • Flat head screwdriver • 1/8" Security hex key 3a 3b* ITEM DESCRIPTION Outside Escutcheon Assembly Inside Mounting Plate Assembly (includes Gasket) PoE Controller Assembly Wi-Fi Controller Assembly* (batteries included) Inside Escutcheon Assembly with Privacy Button AA alkaline batteries (6)
  • Page 6 IN120 / IN220 10X Line Bored Lock Parts Breakdown (Continued) *Adapter Plate/Spacer is only shipped with orders that specify 1-3/8” doors. ITEM DESCRIPTION REQ’D Outside Lever (Reference Catalog for Available Styles) Push Pin Cylinder Assembly (Reference Catalog for Available Cylinders) Rose (Reference Catalog for Avalable Styles) Outside Rose Spring Assembly Lockbody Assembly 10XG77...

  • Page 7: In220 (Poe) Wiring And Installation

    IN120 / IN220 10X Line Bored Lock Installation Wiring for IN220 Power over Ethernet (PoE) Installation Wiring Overview IMPORTANT: If you are installing IN220 (PoE) please read this section before installing the IN220 (PoE) bored lock. SARGENT IN220 PoE Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af)
  • Page 8 IN120 / IN220 10X Line Bored Lock IN220 (PoE) Installation Wiring (Continued) Supplied by CI Certified Integrator (CI) supplies and terminates Supplied by End User the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable Crimp Connector...
  • Page 9 IN120 / IN220 10X Line Bored Lock IN220 (PoE) Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: B-Splice TIA/EIA 568-B Standard Wiring Crimp Connector Wire Pair Num- White/Orange...
  • Page 10 IN120 / IN220 10X Line Bored Lock IN220 (PoE) Installation Wiring (Continued) PoE Door Harness Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: •...

  • Page 11: Lock Installation

    IN120 / IN220 10X Line Bored Lock Lock Installation 1 Prepare Door A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right Reverse Bevel...

  • Page 12: Install Strike

    IN120 / IN220 10X Line Bored Lock 2 Install Strike Install strike in the door frame (Fig. 2). Attaching Screws #12 -24 x 3/4" Optional Strike Fig. 2 3 Install Latchbolt 1. Install latch with beveled bolt facing the strike. Inside of 2.
  • Page 13 IN120 / IN220 10X Line Bored Lock 5 Lock Adjustments A. Lock Preset: • Lockbody holes: 12 and 6 o’clock (Fig. 5). The lock is shipped “preset” and does not require adjustment for 1-3/4" thick doors*. Outside of Door Door thickness: 1-3/4”...
  • Page 14 IN120 / IN220 10X Line Bored Lock 6 Door Thickness Adjustment (If Required) Lock Preset to: • Door thickness– 1-3/4" thick- see below for other door conditions Trim Assembly Adjustment for different door thickness: Lock is factory preset for 1-3/4" (44mm) doors unless specified. To adjust lock to door thickness if other than 1-3/4"...

  • Page 15: Install Lock

    IN120 / IN220 10X Line Bored Lock 7 Install Lock 1. From outside of door feed lockbody harness into the lockbody hole (Fig. 7A). For metal door: For metal door: Feed harness through inside of door (not shown). 2. Continue to feed harness into raceway (towards top of door), exiting raceway hole on inside of door (Fig.
  • Page 16 IN120 / IN220 10X Line Bored Lock 8 Secure Lock To Door 1. Feed wire and connector: Inside of Door • For wood door, feed connectors and wires through the door and up the wire run channel (Fig. 8). • For metal door (not shown), feed connectors and wires into the lockbody hole and out the controller hole.
  • Page 17 IN120 / IN220 10X Line Bored Lock 10 Install IN120 / IN220 Outside Reader 1. Orient the reader (keypad) so the LED lens is at the top. 2. Feed the reader harness through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes.
  • Page 18 IN120 / IN220 10X Line Bored Lock 11 Install Inside Mounting Plate Assembly 1. Next feed the cables/connectors through the inside mounting assembly and gasket. 2. Secure the mounting assembly while ensuring proper alignment of outside reader and partially tighten the (2) through-bolts on the inside of the door to secure the reader (Fig.

  • Page 19: Installation Of Connectors

    IN120 / IN220 10X Line Bored Lock 12 Preparation of Connectors Important Note: Before you secure the connectors CAUTION - Do not touch or allow debris to enter connector contacts. (grease)* Ensure connectors are covered with silicone dielectric compound SILICONE DIELECTRIC APPLY COMPOUND FILL...

  • Page 20: Installing The Controller

    IN120 / IN220 10X Line Bored Lock 13 Installation of Connectors (Continued) Important Note: If you are installing IN220 (PoE)*: E. Pull 5 1/2 inches of Ethernet cable from hole. Strip cable jacket back 3 1/2 inches. F. Separate (untwist) and straighten (8) Ethernet wires before care- fully feeding through ferrite bead (Fig.
  • Page 21 IN120 / IN220 10X Line Bored Lock 14 Installing the Controller (Continued) 1. Insert bottom tab of controller (ensure a clear path) into slot on mounting plate (Fig. 14D, E). 2. Ensure proper alignment of board-to-board connectors (Fig. 14E) while pivoting controller toward door until two tabs on top click securely into place on mounting plate (Fig.
  • Page 22 IN120 / IN220 10X Line Bored Lock B. IN120 (WIFI) 1. Once controller is securely in place, place (6) “AA” alkaline batteries in the compartment, being careful to align polarity properly. 2. After batteries are installed, there is a slight delay; then an audible “beep”...

  • Page 23: Operational Check

    IN120 / IN220 10X Line Bored Lock Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside lever retracts latch. • To test cylinder, the following checks apply: Insert key into cylinder and rotate: a.
  • Page 24 New Haven, CT 06511 USA 800-727-5477 • www.sargentlock.com Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
