KI Intellect Wave Assembly Instructions

Assembly Instructions
Intellect Wave
4-Leg, Tripod, Adjustable-Height & Sit/Stand Height Cantilever Desks
Classroom Furniture
®
June 2022
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Important: Thickness and
composition of the desktop
dictates which screw must be
used for all legs and
accessories. Check to be sure you
were supplied the correct screws
for your desk. Using the incorrect
screw could damage the desktop
and/or cause a safety hazard.
1. See Details A & B to identify the type
of desktop surface you have, and
double-check to be sure you have
the correct hardware to use on that
desktop (Details A & B).
If hardware is not correct, or if you
have any questions, call KI Customer
Service at: 1-800-242-2432.
Adjustable-Height 4-Leg Desk
1. To adjust the height of the leg,
first place desk upside-down on a
soft protective surface. Locate and
remove the height-adjust screw
using a T30 Torx wrench. Move the
leg up or down to desired height and
re-install the height-adjust screw into
appropriate alignment hole
(Figure 1).
2. Repeat the above procedure for the
remaining legs, then carefully turn
the desk to the upright
position.
3. *Adjustable leveling glides
are installed to the back legs,
opposite the user side of the desk.
One or both adjustable glides may
be turned clock-wise to account
for un-level floor conditions. Each
adjustable swivel glide has a
threaded stem which must turn to
adjust the glide (Figure 1).
