KI Grazi Repair & Replacement Instructions

Repair & Replacement Instructions
Doni , Grazi , Intellect Wave
® ®
Figure 1
hoof
nippers
steel
glide
chair leg
Figure 2
mallet
replacement
steel glide
chair leg
Figure 4
, Ruckus™, Strive & Versa
® ®
4-Leg Stack Chair Glide Replacement
tabletop
chair
mallet
cold chisle
steel glide
retainer
chair leg
Figure 3
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Seating
®
March 2019
Steel Glide Replacement
1. Place chair upside down onto a
soft, protective surface or with the
seat portion sitting on a table as
illustrated (Figure 1).
2. Using a hoof nippers, cut/break the
glide portion off. Throw un-used
glide end away (Figure 2).
3. Next, using a mallet and cold chisel,
knock the glide retainer deeper into
the leg so that there is enough room
to insert a new glide (Figure 3).
4. With retainer out of the way, insert
new glide and press into the leg. The
glide may need to be lightly tapped
in using a rubber mallet (Figure 4).
