- Page 1 SKU: MI-303B Scan this QR code for product information, videos, and assembly assistance. Heavy-Duty Tilt TV Wall Mount (855)- 925-5668...
- Page 2 please contact us (Mount-It!) for assistance. COMPATIBLE VESA SIZES FITS MOST TVS UP TO WEIGHT RATING 200x200/300x300 M I -3 0 3 B 400x200/400x400 80kg (176lbs) 600x400 please contact us (Mount-It!) for a replacement. WARNING: This installation manual is intended to provide guidance on how to install the TV mount and the TV on a suitable wall. Please contact a qualified professional if you are unsure of the steps described in the manual or have doubts about the safety of the installation.
- Page 3 Install the Tilt Adjustment Knob INSTALLATION OPTION 1: Wood Stud Installation TOOLS REQUIRED With a stud finder locate the stud and center the mount on the stud at the desired height. Using a bubble level to ensure Install the Tilt Adjustment Knob (#B) and washer into the Left and Right VESA Brackets (#B, C) in the orientation shown here.
- Page 4 Installing the TV to the mount INSTALLATION OPTION 2: Concrete/Brick Wall Installation TOOLS REQUIRED TOOLS REQUIRED M-A M-B/M-C M-J/M-K/M-L M-D M-E/M-F M-J/M-K/M-L M-H/M-I Lay your TV down on a flat surface and align VESA Arms (#B, #C) over the VESA holes as shown, with Left VESA Bracket (#B) on the left, and Right VESA Bracket (#C) on the right.
