Summary of Contents for Taurus TF-M805
- Page 1 Assembly and Operating Instructions ~ 30 Min. 15 kg L 92 | B 45 | H 41 FSTFM805.01.01 Sissy Squat TF-M805...
- Page 2 Sissy Squat...
-
Page 3: Table Of Contents
CONTENTS GENERAL INFORMATION 1.1 Techical data 1.2 Personal safety 1.3 Set-up place ASSEMBLY INSTRUCTIONS; MAINTENANCE AND CARE 2.1 General instructions 2.2 Errors and error diagnosis 2.3 Maintenance and service calendar ASSEMBLY WARRANTY INFORMATION DISPOSAL ORDERING ACCESSORIES ORDERING SPARE PARTS 7.1 Service hotline 7.2 Serial number and model name 7.3 Parts list 7.4 Exploded drawing... - Page 4 Sissy Squat...
- Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
-
Page 6: About This Manual
ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance. - Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
GENERAL INFORMATIONEN Technical data Weight and dimensions: Article weight (gross, including packaging): 20kg Article weight (net, without packaging): 15kg Package dimensions (L x W x H): 90 cm x 35 cm x 18 cm Set-up dimensions (L x W x H): 91.8 cm x 45.3 cm x 41 cm Maximum user weight: 150 kg... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 11: General Instructions
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Faults And Troubleshooting
Faults and troubleshooting The equipment runs through regular quality controls during production. Nevertheless, errors or malfunctions on the equipment may occur. Individual parts are often the cause of faults and replacement is usually suffi cient. Please use the following overview to see the most common errors and how to repair them. -
Page 13: Assembly
ASSEMBLY Note: We recommend you to not fully tighten the screws and bolts until the assembly is completed. Step 1 Assemble the two wheels (19) on the front base frame (2) using two hexagon bolts (12), four big washers (14) and two lock nuts (15). Now attach the four plastic covers (18). No. - Page 14 Step 2 Assemble the front base frame (2) on the main frame (1) using two hexagon bolts (11), four big washers (13), two lock nuts (16) and one reinforcing plate (20). Now attach the four plastic covers (18). Description Specifi cation Qty.
- Page 15 Step 3 Assemble the back base frame (4) on the main frame (1) using two hexagon bolts (11), four big washers (13), two lock nuts (16) and one reinforcing plate (20). Now attach the four plastic covers (18) Description Specifi cation Qty.
- Page 16 Step 4 Assemble the two footplates (7) on the main frame (1) using two hexagon bolts (11), four big washers (13) and two lock nuts (16). Now attach the four plastic covers (18). Description Specifi cation Qty. footplate hexagon bolt M10x70 big washer Φ10...
- Page 17 Step 5 Insert the adjustment tube (3) into the main frame (1) and assemble it using the locking spring knob (17). Description Specifi cation Qty. adjustment tube locking spring knob M18x1.5...
- Page 18 Step 6 Assemble the leg cushion support tube (5) on the leg cushion (6) using two hexagon socket button head bolts (9), two hexagon socket button head bolts (10) and four big washers (8). Now insert the leg cushion support tube into the main frame (1) and assemble it using the locking spring knob (17).
-
Page 19: Ordering Spare Parts
The serial number of your equipment is unique. It’s located on a white sticker. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Taurus / multi gym Model Name: Taurus Sissy Squat Article Number: TF-M805... -
Page 20: Warranty
WARRANTY Products from TAURUS® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 21 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 22: Ordering Accessories
DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols. -
Page 23: Parts List
Parts list Description Specifi cation Qty. main frame front base frame adjustment tube back base frame leg cushion support tube leg cushion footplate big washer Φ25xΦ8.2x1.5 hexagon socket button head bolt M8x20 hexagon socket button head bolt M8x40 hexagon bolt M10x70 hexagon bolt M8x45... -
Page 24: Exploded Drawing
Exploded drawing Sissy Squat... - Page 25 CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��...
- Page 26 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
- Page 28 Sissy Squat...
