- Page 1 Assembly Instructions max. 320 kg ~ 45 Min. 51 kg L 158 | W 72 | H 99 TFPTT0218.01.02 Art. No. TF-PTT0218 Taurus Elite Abdominal Trainer...
- Page 2 Ab Trainer...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List... - Page 4 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 5 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 6: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions: Packaging dimensions (L x W x H) and weight approx.: Box 1: 127 cm x 46 cm x 67 cm 44.7 kg Box 2: 150 cm x 17 cm x 41 cm 9 kg Article weight (net, excl. -
Page 7: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 8: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 9: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 10: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 11: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the Body Frame and Bottom Frame Mount the body frame (1) to the bottom frame (6) with two screws (24), two spring washers (31) and... - Page 12 Step 2: Assembly of the Leg Pads Loosen the round knob (46) of the body frame (1). Insert the foot pad supporting frame (5) into the respective opening of the body frame (1). Lock the foot pad supporting frame (5) in place by tightening the round knob (46) in one of the pre-drilled holes of the foot pad supporting frame (5).
- Page 13 Step 3: Assembly of the Head Pad and Back Pad Mount the head pad (51) onto the body frame (1) with two screws (49), two spring washers (30) and two plain washers (33). Mount the back pad (52) onto the body frame (1) with two screws (50), two spring washers (30) and two plain washers (33).
-
Page 14: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 15: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 16: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Cushions Legend: C = clean;... -
Page 17: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes. -
Page 18: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / weight bench Model Name: Elite Abdominal Trainer | Workout Bench Article Number: TF-PTT0218 Ab Trainer... -
Page 19: Parts List
Parts List Name Specification Qty. Body frame Cushion frame Cushion supporting frame Cushion adjusting frame Foot pad supporting frame Bottom frame Adjusting column Stpring Muscle metallurgy set Double head bolt Bottom foot cover Through hole grip Knob Pipe plug Buffer pad Stop Screw Pot head End cover... - Page 20 Plain washer Φ16*Φ8.4*1.6 Plain washer Φ20*Φ10.5*2 Nylon Insert Lock Nut Aluminum baffle ring Aluminum ring Plastic ring Aluminum end cover hexagon socket set screw with cone point M5*5 Hex Socket Head Cap screw M6*25 Hex Socket Head Cap screw M8*50 Description Specifications Nylon Insert Lock Nut...
-
Page 21: Exploded Drawing
Exploded View Exploded Drawing... -
Page 22: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 23 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 24: Contact
