Summary of Contents for Aiper Scuba N1
- Page 1 ROBOTIC POOL CLEANER User Manual Aiper Scuba N1...
- Page 2 1. This equipment complies with IC radiation exposure limits set forth for an uncon- trolled environment. 2. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Importer. Aiper Intelligent, LLC. Address: 13851 Ramona Ave, Chino, CA 91710, USA. US Toll-Free: 1-866-850-0666 AU Toll-Free: +61(180)049-7023...
- Page 3 Thank you for choosing Aiper. You’ve now joined a family of millions who have already put their trust in Aiper to take care of their pools and are enjoying the convenience of a pristinely clean pool. This user manual will help you maintain your Aiper pool cleaner and ensure it performs at its maximum e ciency for years to come.
-
Page 4: Table Of Contents
CONTENTS Important Safety Precautions ----------------- 1. Structure ------------------------------------- 2. Specifications & Working Conditions -------- 3. Charging ------------------------------------ 4. Using Your Aiper Pool Cleaner --------------- 5. Operating Your Device ----------------------- 6. Disassembly and Cleaning ------------------ 7. Maintenance --------------------------------- 8. Storage -------------------------------------- 9. -
Page 5: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS Read this manual carefully and use your device in accordance with the instructions. Aiper is not liable for any damages or injuries caused by improper use. For your safety and optimal performance of this device, please read and follow the following suggestions. - Page 6 16. WARNING – To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. 17. Ensure that children do not attempt to access cleaner while it is operating. 18. CAUTION a.
-
Page 7: Structure
Please read this user manual carefully before operating the device. 1. Structure Top Shell Filter Basket Switch LED light Handle Roller Brush Retrieval Hook Charger... -
Page 8: Specifications & Working Conditions
2. Specifications & Working Conditions 1. Pool Size: 1600 Sq.ft/150m 2. Charger Input: 100-240V, 60/50Hz, Max 1.5A 3. Charger Output: 16.8V/2.6A 4. Charging Time: 4 Hours 5. Battery Life: Up to 150 Minutes 6. IP Grade: IPX8 Waterproof 7. Water Depth: 1.6-10ft(0.5-3m) 8. -
Page 9: Charging
3. Charging CAUTION: Do not charge the device in direct sunlight. a. Fully charge the device before using it to clean the pool. b. Before charging, remove the charging port cover to check if there is any residual water in the charging port. If so, wipe dry the charging port first. -
Page 10: Using Your Aiper Pool Cleaner
4. Using Your Aiper Pool Cleaner a. This machine is suitable for cleaning floors, walls and water lines in areas up to 1600sq. Ft./150m . 1600sq. Ft./150m 5. Operating Your Device a. Press and hold the Power button for 2s to turn on/o the device. - Page 11 b. Auto mode is the default mode for this device once turned on. Press the button to switch between Auto, Pool Floor, Pool Wall and Eco. 1) Auto Mode: The device will clean the pool floors and walls, while intel- ligently planning its cleaning route based on its battery level.
- Page 12 3) Pool Wall Mode: The device will clean the pool wall in an N-shaped route, without cleaning floors. When the battery level is low, the device will automatically stop cleaning and dock. Wall Wall Cleaning Mode 4) Eco Mode: The device will clean the pool floor for 45 min once every 他\临时暂放文件\Leif\1.
- Page 13 c. After the device is turned on for 30 s, it will turn the water pump briefly every 10 s to check whether it has entered the water for 3 times. If it detects that it has not entered the water 3 times, it will shut down;...
-
Page 14: Disassembly And Cleaning
f. Hook the device's handle g. Hold the handle and allow and lift the device out of t h e d ev i c e to d ra i n a ny the water. stored water. 6. Disassembly and Cleaning a. - Page 15 c. Press the top shells latch of the filter basket and at the same time pull up on the top cover handle to open the filter basket. d. Empty the filter basket, rinse, and replace the filter basket back into the device.
-
Page 16: Maintenance
7. Maintenance 7.1 Replacing the tracks. a. Remove the side cover plate from the device. b. Remove the screws and the guide sleeves from the wheels. - Page 17 c. Pull the wheels and the track together to remove them. d. Align the gears on the new tracks with the gears on both wheels, then install the rear wheels and tracks together back onto the shaft sleeves.
- Page 18 e. Re-install the white guide sleeves by aligning their D-shaped openings with that of the shaft sleeves. f. Tighten the screws and re-install the side cover plate.
- Page 19 7.2 Replacing the roller brush belt. a. Find the side that looks di erent from the other roller brush belts, and pull down the silicone buckles that are stuck in the fixed slot. b. After all the silicone buckles are pulled out, replace the roller brush belt with a new one.
-
Page 20: Storage
How should I store my Aiper device during the o -season? In your pool's o -season, such as winter months or long vacations when your Aiper device won't be used, there are a few steps to take to protect your device and keep it in the best condition possible. -
Page 21: Led Indicator
9. LED Indicator Light Status Device Status Description Blue light always on: 100% The LED colors indicate the Blue: > 50% Charging Light is battery level of the Pulsing device. Yellow: 50-15% Red: < 15% Blue: > 50% The LED colors Light indicate the Operating... -
Page 22: Packing List
10. Packing List Name Model QTY(pc) Cleaner Aiper Scuba N1 Charger Retrieval Hook User Manual Extra PVC Brushes 11. Warranty This product has passed quality control and safety test conducted by our technicians. 1. This product comes with a 24-month warranty that covers your item’s battery and motor from the date of purchase. - Page 23 Merci d'avoir choisi Aiper. Vous avez maintenant rejoint une famille de millions de personnes qui ont déjà fait confiance à Aiper pour prendre soin de leur piscine et qui profitent de la commodité d'une piscine parfaitement propre. Le présent manuel de l'utilisateur vous aidera à entretenir votre nettoy- eur de piscine Aiper et à...
- Page 24 www.aiper.com...
