Claypaky SHARPY PLUS Instruction Manual

Hide thumbs Also See for SHARPY PLUS:

Advertisement

Quick Links

Download this manual
GOAT 470+
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHARPY PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Claypaky SHARPY PLUS

Summary of Contents for Claypaky SHARPY PLUS

  • Page 1 GOAT 470+ INSTRUCTION MANUAL...

  • Page 2: Unpacking And Preparation

    1. UNPACKING AND PREPARATION Packing contents - Fig. 1 LOCKED UNLOCKED UNLOCKED LOCKED PAN Mechanism Lock and Release (every 90°) - Fig. 2 TILT Mechanism Lock and Release (every 45°) - Fig. 3 SHARPY PLUS...

  • Page 3: Installation And Start-Up

    (Cod. 105041/003 WARNING: available on request). This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base. SHARPY PLUS...
  • Page 4 2.2 Connecting to manis supply Connecting and disconnecting power cable - Fig. 5 SHARPY PLUS...
  • Page 5 120Ohm (minimum 1/4 W) between terminals 2 and 3. IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing itself must be connected to the shield braid and to pin 1 of the connectors. SHARPY PLUS...

  • Page 6: Maintenance

    3. MAINTENANCE 3.1 Opening the covers Locking and releasing Pan and Tilt movements - Refer to the instructions in the UNPACKING AND PREPARATION section. Opening the head covers - Fig. 10. Closing the head covers - Fig. 11. ➔ SHARPY PLUS...
  • Page 7 3.2 Periodical cleaning Upper Side Lower Side SHARPY PLUS...
  • Page 8 • General cleaning of internal parts. • Restoring lubrication of all parts subject to friction, using lubricants specifically supplied by Claypaky. • General visual check of the internal components, cabling, mechanical parts, etc.
  • Page 9 3.3 Effects module removal Lower side SHARPY PLUS...
  • Page 10 Fig. 13, 14 and 15 in reverse order. NOTE: - Do not disconnect wiring harnesses when the fixtures is switched-on, to avoid to damage electronic boards. - Do not switch-on the fixtures with wiring harness disconnected. Continue ➔ SHARPY PLUS...
  • Page 11 Take the new lamp out of its package and insert in the fitting. do not touch the lamp’s envelope with bare hands. Should this happen, clean the bulb with a cloth soaked WARNING: in alcohol and dry it with a clean, dry cloth. Lamp regulation SHARPY PLUS...
  • Page 12 - After a successful starting, attempt to keep the lamp burning for at least 15 minutes in order to complete the chemical cycle of the lamp to secure the lifetime. - After switching-off the lamp wait at least 2 minutes before switching-on it again. Continue ➔ SHARPY PLUS...
  • Page 13 4.5 - Rotating gobos Bearing group replacement - Fig. 16 COATED GLASS GOBOS Grey/Black side away from lamp Reflective side towards the lamp Gobo orientation - Fig. 17 The pictures shown the correct gobos orientation. ROTATING GOBO INDEX SHARPY PLUS...
  • Page 14 - The original gobos have a special coating designed specifically to resist to the high temperatures; - The rotating gobo wheel only use dichroic glass gobos (it is not possible to use metal gobos); - For more information contact US SHARPY PLUS...

  • Page 15: Specifications

    16 bit Focus Cooling system monitoring Resolution 16 bit Gobo Resolution 16 bit Dimmer Resolution 16 bit DMX signal connection 5 pole XLR input and output Ethernet Input Firmware update Software upload through Ethernet input SHARPY PLUS...

  • Page 16: Dmx Channels

    Sharpy Plus 03/2 DMX Channels Numbe Functio CYAN MAGENTA YELLOW COLOUR WHEEL 1 COLOUR WHEEL 2 COLOUR WHEEL 3 STOPPER / STROBE DIMMER DIMMER FINE STATIC GOBO CHANGE ANIMATION DISK INSERTION ANIMATION DISK ROTATION ROTATING GOBO SELECT GOBO ROTATION GOBO ROTATION FINE...
  • Page 17 Sharpy Plus 03/2 DMX Channels Number Function Value parameter CYAN 000 - 255 Linear Cyan movement MAGENTA 000 - 255 Linear Magenta movement YELLOW 000 - 255 Linear Yellow movement COLOUR WHEEL 1 000 - 023 Empty position 024 - 046...
  • Page 18 Sharpy Plus 03/2 DMX Channels Number Function Value parameter COLOUR WHEEL 3 000 - 023 Empty position 024 - 046 Empty + Light Green 047 - 069 Light Green 070 - 092 Light Green + Pink 093 - 115 Pink...

  • Page 19: Function Parameter

    Sharpy Plus 03/2 DMX Channels Number Function Value parameter STATIC GOBO CHANGE 000 - 003 Empty position 004 - 007 Gobo 1 008 - 011 Gobo 2 012 - 014 Gobo 3 015 - 018 Gobo 4 019 - 022...
  • Page 20 Sharpy Plus 03/2 DMX Channels to fast 128 - 132 Stop rotation 133 - 255 Continuous CW rotation at linearly variable speed from slow to fast...
  • Page 21 Sharpy Plus 03/2 DMX Channels Number Function Value parameter ROTATING GOBO SELECT 000 - 007 Empty position 008 - 015 Gobo 1 016 - 023 Gobo 2 024 - 031 Gobo 3 032 - 039 Gobo 4 040 - 047...
  • Page 22 Sharpy Plus 03/2 DMX Channels 232 - 243 Gobo 7 shakes at variable speed from slow to fast 244 - 255 Gobo 8 shakes at variable speed from slow to fast...
  • Page 23 Sharpy Plus 03/2 DMX Channels Number Function Value parameter GOBO ROTATION 000 - 021 Gobo indexing CW: 0° to 90° range 021 - 042 Gobo indexing CW: 90° to 180° range 042 - 063 Gobo indexing CW: 180° to 270° range 063 - 084 Gobo indexing CW: 270°...
  • Page 24 Sharpy Plus 03/2 DMX Channels 000 - 255 Zoom linearly moves from narrow to wide beam FOCUS 000 - 255 Focus moves linearly from far to near position FOCUS FINE 000 - 255 Fine Focus positioning...

  • Page 25: Important Notes

    026 - 100 Lamp OFF staying in this range for 3 seconds Lamp ON staying in this range for 3 seconds IMPORTANT: SHARPY PLUS is not provided with hot re-strike 101 - 255 igniter After switching-off the lamp wait at least 2 minutes...
  • Page 26 Sharpy Plus 03/2 DMX Channels...

This manual is also suitable for:

Goat 470+
