- Page 1 Assembly and Operating Instructions max. 100 kg ~ 60 Min. 33 kg L 113 | W 55 | H 131 FSUKBMSC30.01.03 SKU: BM-SC30 BodyMax SC30 Indoor Bike...
- Page 2 SC30...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Battery Replacement Adjusting the Tension Using the Emergency Brake Function OPERATING INSTRUCTIONS Console Display Button Functions Turning on the Console Modes 3.4.1 Setting Mode 3.4.2 Exercise Mode 3.4.3 Stop Mode Wireless Connection and Fitness Apps... - Page 4 Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT SC30...
- Page 5 European VAT Number: DE813211547 Disclaimer © BodyMax is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). SC30...
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ࣑...
-
Page 8: General Information
33 kg Packaging dimensions (L x W x H): 93 cm x 73.5 cm x 22 cm Set-up dimensions (L x W x H): 112.6 cm x 54.6 cm x 131.3 cm Maximum user weight: 100 kg Use class: SC30... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Electrical Safety
The software systems on gym equipment with TFT consoles are set up only for the pre- installed apps. Do not install any additional apps. NOTICE The pre-installed apps on TFT consoles are produced and provided by external manufacturers. Fitshop does not take any responsibility for the availability, functionality or contents of these apps. SC30... -
Page 11: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 12: Assembly
To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. SC30... -
Page 13: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... -
Page 14: Assembly
(69). Use the hexagon spanner (9) to tighten the bolts (68). 6 6 8 8 7 7 0 0 6 6 9 9 6 6 8 8 7 7 0 0 6 6 9 9 Fig. 1 SC30... - Page 15 Step 2: Assembly of the Seat Adjustment Rotate the seat cushion adjustment pull pin (21) out of the the car frame (1). Remove the seat cushion adjustment (5) from of the car frame (1). Insert the seat cushion adjustment (5) into the car frame (1) according to the illustration below (fig.
- Page 16 Step 3: Assembly of the Handle Loosen the L-shaped adjustable handle (20). Insert the handle adjustment (5) into the car frame (1). Lock the L-shaped adjustable handle (20) back into place. 2 2 0 0 Fig. 4 SC30...
- Page 17 Step 4: Assembly of the Handlebar Attach the handlebar (6) to the handle adjustment (4) with four bolts (71), four spring washers (70) and four flat washers (69). Use the hexagon spanner (9) to tighten the bolts (68). 7 7 1 1 7 7 0 0 6 6 9 9 Fig.
- Page 18 The seat cushion (54) and handle adjustment (4) are in a vertical position (fig. 7). 5 5 4 4 5 5 4 4 Fig. 7 A A - - A A Fig. 6 A A - - B B A A - - A A A A - - B B SC30...
- Page 19 Step 6: Assembly of the Pedals Attach the IP rack (41) to the handlebar (6). NOTICE The pedals are marked with an “L” and an “R” for left and right. Unscrew the lock nut on the left pedal (49). Attach the left pedal (49) to the left crank leg (22) by turning the pedal (49) counterclockwise onto the crank leg (22).
- Page 20 Fix the computer (57) to the handlebar (6) with the cross head screws (D) and the screw driver (11). Connect the communication line (A) with the communication line (B). 5 5 7 7 1 1 2 2 Fig. 9 SC30...
- Page 21 Step 8: Adjusting the Seat Position Height Adjustment ⚠ CAUTION When adjusting, make sure not to exceed the minimum insertion depth. Turn and pull the pull pin slightly out. Position the seat to your desired height. Retighten the pull pin again. Horizontal Adjustment Turn and pull the pull pin slightly out.
-
Page 22: Battery Replacement
The same knob that allows you to adjust the resistance of the indoor cycle doubles as the emergency brake . To use the emergency brake firmly press down on the emergency brake & tension control knob. SC30... -
Page 23: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Always start your training with low intensity and increase evenly and gently. End your training with a cool-down phase. -
Page 24: Button Functions
Press the UP button to increase the value. Press the DOWN button to lower the value. NOTICE By setting values for DISTANCE or CALORIES you create a countdown. The countdown begins once you enter exercise mode. To clear all parameter values, press the RESET button. SC30... -
Page 25: Exercise Mode
3.4.2 Exercise Mode In exercise mode, the console displays the parameters every 6 seconds. It switches between the following parameters: Speed Watt Calories Pressing the UP or DOWN buttons allows you to pin one parameter on the display. If the parameters DISTANCE or CALORIES have been adjusted previously in setting mode, they will turn into a countdown once you enter excercise mode. -
Page 26: Wireless Connection And Fitness Apps
Just follow the instructions on the screen to perform the update. Please note: The system is set up only for the pre-installed apps. Do not install any additional apps as their proper functionality can not be guaranteed. The installation of other apps might cause technical issues. Example: Kinomap SC30... - Page 27 Example: ThinkFIT NOTICE Once the device connects to the app, the console display will display the word “BLE“. Your device is connected.
-
Page 28: Storage And Transport
After that, you easily can move the equipment to a new position. For long transport distances the equipment should be disassembled and safely packed. Select the new location by following the instructions in the section 1.4 of this manual. SC30... -
Page 29: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 30: Error Codes And Troubleshooting
Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. Please contact the contract partner for technical support. SC30... -
Page 31: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Display console Plastic covers Screws and cable connections Check pedals for tightness... -
Page 32: Recommended Accessories
Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap lubricant floor mat SC30... -
Page 33: Ordering Spare Parts
The serial number of your equipment is unique. It’s located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: BodyMax / indoor cycle Model Name: SC30 SKU: BM-SC30... -
Page 34: Parts List
Seat cushion adjustment pull pin Left crank leg Right crank leg Induction magnet Brake pad fixing seat top cover Seat cushion adjustment plate Deep groove ball bearing 6001-2RS Bearing 6004Z Brake spring Chain cover outer cover Chain cover inner cover SC30... - Page 35 Decorative ring Center hood Flywheel decoration cover Strut sleeve Adjust spacer Brake seat 1 Brake regulating block Brake cover Brake knob IP rack Left brake decoration cover Right brake decoration cover Wool felt Adjustable foot pad Moving wheel Belt pulley Waist round tube flat plug Left pedal Right pedal...
- Page 36 M6*15 Standard spring washer Flat washer Class C Screw 2.9*9.5 Screw 4.2*13 Screw 4.2*12 Screw 4.2*12 Bolt M5*7 Flange nut M10*1.25 Class C hexagon nut Class C hexagon head bolt M8*16 Bolt M4*12 Crank decoration cover Flywheel Flywheel axis SC30...
-
Page 37: Exploded Drawing
Exploded Drawing... -
Page 38: Warranty
WARRANTY Products from BodyMax® are subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 39 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
- Page 40 Godziny otwarcia można znaleźć Öffnungszeiten entnehmen Öffnungszeiten entnehmen na stronie głównej: Sie unserer Homepage: Sie unserer Homepage: https://stg.fit/statit6 https://stg.fit/statitb https://stg.fit/statit9 Please find a detailed overview including address and opening hours for all stores of Fitshop UK on the following website: www.fitshop.co.uk/storelocator SC30...
- Page 41 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Fitshop Group is Europe’s largest specialist for https://www.fitshop.co.uk/ home fitness equipment with currently 70 stores www.fitshop.co.uk/blog/ and one of the world’s most renowned online mail order companies for fitness equipment. Fitshop UK is part of the Fitshop Group. Private www.facebook.com/fitshop.co.uk customers order via the 25 web shops in the respective national language or have their...
- Page 42 Notes SC30...
- Page 44 BodyMax SC30 Indoor Bike...
