BODYMAX B15 Assembly And Operating Instructions Manual

BODYMAX B15 Assembly And Operating Instructions Manual

Indoor cycle

Advertisement

Assembly and Operating Instructions
max. 125 kg
~ 60 Min.
47 kg
L 120 | W 55 | H 120
CVEB2409.CVEB2712 01.01
SKU Code: CVEB2409 / CVEB2712
BodyMax
B15 Indoor Cycle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BODYMAX B15

  • Page 1 Assembly and Operating Instructions max. 125 kg ~ 60 Min. 47 kg L 120 | W 55 | H 120 CVEB2409.CVEB2712 01.01 SKU Code: CVEB2409 / CVEB2712 BodyMax B15 Indoor Cycle...
  • Page 2 Indoor Cycle B15...
  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Heart Rate Controlled Programmes STORAGE AND TRANSPORT General Instructions Transportation Wheels Folding Mechanism 4.3.1 Folding Up the Treadmill 4.3.2 Unfolding the Treadmill TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis...
  • Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT Indoor Cycle B15...
  • Page 5 With BodyMax® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. Indoor Cycle B15...
  • Page 7: General Information

    GENERAL INFORMATION Technical Data LED - Display of Time in min Speed in km/h Distance in m Calories in kcal Pulse Brake system: Magnet manual brake system Flywheel mass: 20 kg Weight and dimensions Article weight (gross, including packaging): 49.5 kg Article weight (net, without packaging): 46.5 kg Packaging dimensions (L x W x H):...
  • Page 8: Personal Safety

    Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. Indoor Cycle B15...
  • Page 9: Electrical Safety

    Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...
  • Page 10: Set-Up Place

    (over 70%) like swimming pools. A floor protective mat/equipment underlay can help to protect high-quality floor coverings (parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. Indoor Cycle B15...
  • Page 11: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.
  • Page 12: Assembly

    (7). Mount the seat (13) to the seat post (12). Insert the vertical seat post (10) into the main frame (16) and line up the holes. Secure the desired seat position with an adjustment knob (7). Indoor Cycle B15...
  • Page 13 Step 3: Assembly of the Handlebar Post, the Handlebar and the Computer Slide the handlebar post (17) into the handlebar post housing on the main frame (16). Loosen the L shaped knob (19) and pull it back. Select the desired height. Release the L shaped knob (19) and retighten the knurled portion.
  • Page 14 Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment. Rotate them counterclockwise in order to lower the equipment. Indoor Cycle B15...
  • Page 15 2.2.1 Adjusting the Tension To increase the resistance, turn the emergency brake & tension control knob (30) to the right. To decrease the resistance, turn the emergency brake & tension control knob (30) to the left. 2.2.2 Using the Emergency Brake Function WARNING ⚠...
  • Page 16: Operating Instructions

    Press this button to confirm settings. MODE / RESET Press and hold this button for 2 seconds to reset all functions. Press this button to set values for TIME, DISTANCE, CALORIES and PULSE. Hold this button to increase values faster. Indoor Cycle B15...
  • Page 17 Insertion of Battery and Switching on the Device Open up the battery compartment on the back side of the console. Insert one CR2032 3V battery in the battery compartment with the positive pole turning upwards and the negative pole turning downwards. Put the battery cover back on.
  • Page 18: Storage And Transport

    After that, you easily can move the equipment to a new position. For long transport distances the equipment should be disassembled and safely packed. Select the new location by following the instructions in the section 1.4 of this manual. Indoor Cycle B15...
  • Page 19: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.
  • Page 20: Error Codes And Troubleshooting

    Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. Please contact Powerhouse Fitness for technical support. Indoor Cycle B15...
  • Page 21: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Display console Plastic covers Screws and cable connections Legend: C = clean;...
  • Page 22: Recommended Accessories

    Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels Indoor Cycle B15...
  • Page 23: Ordering Spare Parts

    Enter the serial number in the appropriate field. Serial number: Brand / Category: BodyMax / indoor cycle Model Name: B15 Black Indoor Cycle Exercise Bike Article Number: SKU CVEB2409 / CVEB2712...
  • Page 24: Parts List

    GB/T 95-2002 12 PLASTIC SLEEVE 2 38*38*1.5 SENSOR SR-202 FLAT WASHER 1 φ45*φ10.5*4 END CAP 3 38*38*2.0 END CAP1 φ14*14 WASHER 1 BOLT GB/T 70.2-2000 M8*16 FIXING NUT 1 GB/T 6177.2-2000 M10*1.25 CRANK END CAP φ23*7.5 KNOB φ60*113 Indoor Cycle B15...
  • Page 25 LOCK NUT GB/T 889.1-2000 M8 Twist The Fixings φ20.5*34 LEFT CRANK 170*27 CRANK COVER φ56*28 BEARING 6004ZZ RIGHT CRANK 170*27 GB/T 41-2000 FIXING NUT 2 GB/T 802-1988 M12X1.25 FIXING BOLT M6*58 GB/T 889.1-2000 M6 SCREW 1 GB/T 845-1985 ST4.2*19 SCREW 2 GB/T 15856.1-2002 ST4.2X19 SCREW 3 GB/845-85 ST4.8X13...
  • Page 26 CHAIN WHEEL A7K-16 1/2"*1/8" 16T(1.37"( B0TTLE φ73*215 BOLT 1 GB/T77-2007 M6*6 SPRING WASHER 1 GB/T 859-1987 PLASTIC SLEEVE 70*30*1.5 SCREW5 GB/845-85 ST4.8X13 PLASTIC RING φ20*φ9*3 SCREW 3 GB/845-85 ST4.8X19 END CAP1 φ22*1.5 SPRING WASHER 2 GB/T 859-1987 Indoor Cycle B15...
  • Page 27: Exploded Drawing

    Exploded Drawing...
  • Page 28: Warranty

    WARRANTY Training equipment from BodyMax® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 29 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
  • Page 30: Contact

    Mo - Fr 08:00 - 18:00 09:00 - 18:00 09:00 - 18:00 Please find a detailed overview including address and opening hours for all stores of the Sport-Tiedje Group in Germany and abroad on the following website: www.sport-tiedje.com/en/stores Indoor Cycle B15...
  • Page 31 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
  • Page 32 Notes Indoor Cycle B15...
  • Page 34 BodyMax B15 Indoor Cycle...
