HPCIE-RPL-Q670
Half-size PICMG 1.3 CPU Card
Quick Installation Guide
Version 1.00
Features
LGA1700 socket supports 12th/13th/14th Gen Intel® Core™ i9/i7/i5/i3,
Pentium®/Celeron® processor up to 65W (formerly Alder Lake-S) with Intel®
Q670E/Q670 chipset
Two 262-pin 5200 MHz DDR5 dual-channel SO-DIMM slot (system max. 64GB)
Dual independent display through DisplayPort and HDMI™
Support two 2.5GbE ports via Intel® I226V
M.2 M key with NVMe support; one PCIe Gen3 x16 and four PCIe Gen3 x1 via
golden finger
Packing List
1 x HPCIE-RPL-Q670 CPU card
1 x SATA cable
1 x Mini jumper pack
1 x QIG (Quick Installation Guide)
June 3, 2024
Advertisement
Related Manuals for IEI Technology HPCIE-RPL-Q670
Summary of Contents for IEI Technology HPCIE-RPL-Q670
- Page 1 Support two 2.5GbE ports via Intel® I226V M.2 M key with NVMe support; one PCIe Gen3 x16 and four PCIe Gen3 x1 via golden finger Packing List 1 x HPCIE-RPL-Q670 CPU card 1 x SATA cable 1 x Mini jumper pack ...
- Page 2 ME_FLASH1: Flash descriptor security override jumper Status Description Open Disable (default) Short Enable F_PANEL1: Front panel connector Description Description PWR_LED+ SPKR+ SPKR PWR_LED- PWR_BTN+ SPKR- PWR_BTN- HDD_LED+ Reset+ RESET HDD_LED- Reset- Get more information: HPCIE-RPL-Q670 IEI Resource Download Center 1 ...
- Page 3 Dimensions (Unit: mm) 2 ...
