- Page 1 SPRAY GUN SETUP & ADJUSTMENTS a good start is halfway to success.
- Page 2 01. UNPACK 03. DIGITAL PRESSURE GAUGE DISPLAY INFO Unpack the spray gun and make sure that the product has not been damaged during transportation and that all the contents are included the packaging. The digital pressure gauge display is available in 3 differents pressure forms: Pressure gauge display information: *Clean the fluid passages of the gun before the first use to remove any residue of oil.
- Page 3 IMPORTANT! During all fases of setup and operation procedures, always wear proper body and re- spiratory protection such as: ANEST IWATA safety glasses, mask and gloves. Check the correct viscosity of the paint as Fit the paint filter in the gravity cup.
- Page 4 08. FLUID OUTPUT ADJUST Use the fluid output adjustment to fine-tune fluid delivery, affecting trigger travel. Pour paint into the gravity cup by filtering it by an appropriate strainer to eliminate For standard use, fully open the adjustment until the trigger contacts the gun body. all impurities.
- Page 5 10. TEST & SPRAY TO AVOID A SPLIT FAN PATTERN When working with a flat & thin fan pattern you can use the fan pattern adjustment to finetune it. 100 ~ 250 mm Set the spray distance from the gun to the Test spray (proceed as recomended by the Turn the pattern adjustment knob clockwise.
