- Page 1 MANUAL CLEANING PROCEDURE...
- Page 2 Detach the DPG-1 - digital pressure gauge - from the spray gun handle before cleaning to prevent damage. Use the protective pin cap to ANEST IWATA offers effective cleaning tools in its kits, featuring safeguard the pressure reading port from cleaner entry.
- Page 3 03. HVC-D DETACHING BEFORE CLEANING The HVC-D, a removable digital pressure gauge on our standard spray guns, must be detached from the gun handle before cleaning to prevent permanent damage. Pull out the fluid needle. Remove the fluid nozzle using the included Spanner.
- Page 4 06. CLEANING OF THE ATOMIZING PARTS Dry the threads of the nozzle with the Clean the fluid needle using a big brush. Blow Gun AG-6. Clean the lateral holes in the nozzle Clean the central hole of the nozzle using the Tiny Twisted Brush (ø 3 mm). using the Tiny Twisted Brush (ø...
- Page 5 07. PREPARATION FOR 08. DIGITAL PRESSURE AUTOMATIC GUN WASHER GAUGE REASSEMBLY Before putting the spray gun into the gun washer, fit the TRIGGER LOCKING CLIP to close the pressure reading port. Once you installed the clip properly follow the steps given by the Instruction manual of your gun washing machine.
- Page 6 Get help with Anest Iwata support. www.anest-iwata-coating.com/support/...
