NANLITE FS-300C User Manual

Led rgbw spot light
Hide thumbs

Advertisement

Quick Links

Download this manual
FS-300C
LED RGBW Spot Light
USER MANUAL
Guangdong Nanguang Photo&Video Systems Co., Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FS-300C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NANLITE FS-300C

Summary of Contents for NANLITE FS-300C

  • Page 1 FS-300C LED RGBW Spot Light USER MANUAL Guangdong Nanguang Photo&Video Systems Co., Ltd.
  • Page 2 Thank you for purchasing Nanlite product -- the FS-300C! The FS-300C is a LED RGBW full-color spot light with a rated power of 300W. Featuring all-in-one design, it allows for operation of CCT, HSI, and special effects modes directly on-board. It offers color temperatures from 2700K to 7500K, ±150 green and magenta adjustment, 36000 colors, and 15 customizable special effects.
  • Page 3 9. Please do not cover the vents when using the fixture to avoid affecting heat dissipation, which may result in damage. Please pay attention to the risk of burns when using the fixture for an extended period, as the surface temperature may become high. WWW.NANLITE.COM...

  • Page 4: Product Diagram

    LED RGBW Spot Light Product Diagram Technical Data Rated Power: 300W Input: AC 100-240V 50/60Hz Color Temperature: 2700K-7500K(GM±150) CRI: Average 95 TLCI: Average 94 FS-300C is built with a Bowens mount, enabling it to be compatible with modifiers/accessories with Bowens mount. WWW.NANLITE.COM...

  • Page 5: Product Details

    5. Display Screen 6. Handle 2. Umbrella Mount 7. USB Port 8. Right Knob 9. MODE Button 3. Reflector 10. Power Switch 11. Fuse Base 12. Left Knob 13. Power Socket 14. Yoke 15. Bracket Fixing Knob 4. Angle Fixing Knob WWW.NANLITE.COM...

  • Page 6: Detailed Description

    13. Power Socket: AC power input socket. 14. Yoke: Enabling the fixture to be mounted on the light stand and allowing for the tilting of the fixture. 15. Bracket Fixing Knob: For securing the fixture on the light stand. WWW.NANLITE.COM...
  • Page 7 Includes COB Protective FS-300C × 1 Power Cable × 1 Reflector × 1 User Manual × 1 Cap × 1 FS-300C LED RGBW Spot Light USER MANUAL Guangdong Nanguang Photo&Video Systems Co., Ltd. Usage 1. Installation and Detachment of Reflector...

  • Page 8: Remote Control

    Tighten the angle fixing knob to umbrella mount. lock the umbrella. Remote Control The FS-300C is built with 2.4G and Bluetooth module, enabling it to be controlled by the 2.4G remote controller, by NANLINK APP directly or via the WS-TB-1 transmitter box. ① Note: 2.4G remote controller is sold separately.
  • Page 9 2. Wireless Protocol Setting MEMU MEMU WIRELESS PR: V1.0 CH: 512 FAN: SMART RESET Rotate the right knob to WIRELESS PROTOCOL. MEMU MEMU WIRELESS PR: V1.0 WIRELESS PR: V2.0 FAN: SMART FAN: SMART Rotate the left knob to select V1.0 or V2.0. WWW.NANLITE.COM...
  • Page 10 MEMU BT RESET CH: 512 BACK RESET RESET Rotate the left knob to enter the interface of BLUETOOTH RESET. BT RESET BACK RESET Rotate the right knob to select RESET, and press the right knob to confirm the reset. WWW.NANLITE.COM...
  • Page 11 1. Ensure that the power switch of the fixture is off. Remove the COB protective cap, connect the fixture to the power outlet via the power cable. Turn on the fixture, and the screen will display "FS-300C". 2. CCT Mode Setting Press the MODE button to CCT mode, rotate the right knob to select the DIM (range: 000%…100%),...
  • Page 12 CCT: 5600K G/M: 100 HUE: 000 SAT: 100 Press the MODE button to HSI mode. CH: 512 CH: 512 DIM: DIM: 100% HUE: 000 SAT: 100 HUE: SAT: 100 Rotate the right knob to select DIM, HUE or SAT. WWW.NANLITE.COM...
  • Page 13 Note: In other modes, the adjusting ranges of DIM, HUE and SAT are the same as in HSI mode. 4. EFFECT Mode Setting FS-300C has built-in effects including: HUE Loop, CCT Loop, INT Loop, Flash (CCT Flash and HUE Flash), Pulse (CCT Pulse and HUE Pulse), Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion and Welding.
  • Page 14 CCT LOOP setting, rotate the right knob to select DIM, CCT or SPEED (range: 02s-30s), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 CCT LOOP FX: CCT LOOP DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT or SPEED. WWW.NANLITE.COM...
  • Page 15 DIM: 000%-100% DIM: 000%-100% Rotate the right knob to select DIM, SPEED or COLOR. EFFECT CH: 512 EFFECT CH: 512 FX: INT LOOP FX: INT LOOP DIM: 000%-100% DIM: 001%-100% Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 16 HUE FLASH setting, rotate the right knob to select DIM, HUE, SAT or INTERVALS (range: 0.1s-10.0s), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 HUE FLASH FX: HUE FLASH DIM: 100% DIM: 100% Rotate the right knob to select DIM, HUE, SAT or INTERVALS. WWW.NANLITE.COM...
  • Page 17 DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT, G/M or PULSES/MIN. EFFECT CH: 512 EFFECT CH: 512 FX: CCT PULSE FX: CCT PULSE DIM: 100% DIM: 099% Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 18 STORM setting, rotate the right knob to select DIM, CCT or INTERVALS (range: 01s-60s), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 STORM FX: STORM DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT or INTERVALS. WWW.NANLITE.COM...
  • Page 19 DIM: 100% DIM: 100% Rotate the right knob to select DIM, COLOR or SPEED. EFFECT CH: 512 EFFECT CH: 512 FX: POLICE CAR FX: POLICE CAR DIM: 100% DIM: 099% Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 20 PAPARAZZI setting, rotate the right knob to select DIM, CCT, G/M or SPEED (range: 1-100), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 FX: PAPARAZZI PAPARAZZI DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT, G/M or SPEED. WWW.NANLITE.COM...
  • Page 21 FX: CANDLE/FIRE DIM: 000%-100% DIM: 000%-100% Rotate the right knob to select DIM, CCT, G/M or SPEED. EFFECT CH: 512 EFFECT CH: 512 FX: CANDLE/FIRE FX: CANDLE/FIRE DIM: 000%-100% DIM: 001%-100% Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 22 BAD BULB setting, rotate the right knob to select DIM, CCT, G/M or SPEED (range: 001-100), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 BAD BULB FX: BAD BULB DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT, G/M or SPEED. WWW.NANLITE.COM...
  • Page 23 FIREWORK DIM: 100% DIM: 100% Rotate the right knob to select DIM, COLOR, SPEED or DECAY. EFFECT CH: 512 EFFECT CH: 512 FX: FIREWORK FX: FIREWORK DIM: 100% DIM: 099% Rotate the left knob to set the corresponding parameters. WWW.NANLITE.COM...
  • Page 24 WELDING setting, rotate the right knob to select DIM, CCT, G/M, SPEED (range: 001-100) or PAUSE (OFF/ON), and rotate the left knob to set the corresponding parameters. EFFECT CH: 512 EFFECT CH: 512 WELDING FX: WELDING DIM: 100% DIM: 100% Rotate the right knob to select DIM, CCT, G/M, SPEED or PAUSE. WWW.NANLITE.COM...
  • Page 25 FX: WELDING DIM: 100% DIM: 099% Rotate the left knob to set the corresponding parameters. ▲Some special effect functions may be updated with firmware upgrades. Please refer to the latest firmware function description at www.nanlite.com. 5. MENU Setting MEMU MODE RESET Press the MODE button to enter the MENU.

  • Page 26: Bluetooth Reset

    Note: When the fan is in SMART or FULL state, the maximum power output of the fixture is 100%. When the fan is in LOW state, the maximum power output of the fixture is 50%. When the fan is off, the interior fan will stop working, and the maximum power output of the fixture is 15%. WWW.NANLITE.COM...

  • Page 27: Firmware Update

    _V1.03.01 _V1.03.01 BACK UPDATE BACK UPDATE Rotate the right knob to select UPDATE. FOUND FIRMWARE _V1.03.01 FIRMWARE UPDATED BACK UPDATE Press the right knob to confirm the update, it will show "FIRMWARE UPDATED" after the firmware update is completed. WWW.NANLITE.COM...
  • Page 28 菜单 FW UPDATE: UPDATE 固件更新：更新 LANGUAGE: ENGLISH 语言：中文 Rotate the left knob to select ENGLISH or 中文. 5.7. VERSION MEMU MEMU FW UPDATE: UPDATE VERSION: V1.03.01 LANGUAGE: ENGLISH Rotate the right knob to VERSION to check the firmware version. WWW.NANLITE.COM...
  • Page 29 EFFECT CH: 512 EFFECT CH: 512 HUE LOOP HUE LOOP DIM: 100% DIM: 100% Long press the right knob again to unlock. 7. When the fixture is not in use, please turn off the power switch. WWW.NANLITE.COM...
  • Page 30 "The fixture is overheated, please check the fixture", The fan doesn't work. then please contact the place of purchase or manufacturer. The above issues may not necessarily be caused by a malfunction. Please check again before contacting the place of purchase or manufacturer. WWW.NANLITE.COM...
  • Page 31 Nanlite Website Nanlink App This manual has been compiled according to the rigorous testing for Nanlite products. Product designs are subject to change without prior notice. The latest version of the manual for this product is downloadable at www.nanlite.com. WWW.NANLITE.COM...
  • Page 32 Certification Made in China WWW.NANLITE.COM...
  • Page 33 WWW.NANLITE.COM +86-754-85751187 info@nanlite.com +86-754-85300887 Dongli Section, Highway 324, Chenghai, Shantou City, Guangdong Province, China...
