- Page 1 USER MANUAL PavoTube 15C RGBWW Tube Light Guangdong NanGuang Photo&Video Systems Co., Ltd...
-
Page 2: Technical Data
PavoTube 15C RGBWW Tube Light Product Show Technical Data Color Temperature: 2700K-6500K CRI(Ra): 98 LED Quantity: 400PCS LED Power: 16W x 5 DC Input Power: 15V DC-3A ta=40° Lithium Battery: 14.8V/2200mAh, 32.5Wh... -
Page 3: Product Detail
Product Detail Detailed description 1. Power Switch: Turn on/off the fixture. 2. Clip: For fixing the tube light. 3. Display: For showing the related data. 4. ENTER Key: For releasing the selected option. 5. RGB Key: For entering the interface of RGB color cycle and switching different cycle modes. 6. - Page 4 9. HSI Key: For entering the HSI interface to set the hue, saturation and brightness intensity. 10. Dimmer Knob: For adjusting the brightness intensity, saturation and hue, etc. 11. Function Knob: For function selection and color temperature adjustment. 12. IN: Synchronous input interface. 13.
- Page 5 3. 2.4G Wireless Remote Control The PavoTube 15C is designed to work with a 2.4G remote controller or Nanguang WIFI-APP via WIFI transfer device to control the light remotely.
- Page 6 Operating Instructions 1. Please make sure that the power switch on the fixture is in the "off" position, then connect the fixture to the adapter with the power cable. When turned on, the screen will light up, that means the power is active. 2.
- Page 7 ▼ Main Menu ▼ Second Level Menu ▼ Third Level Menu Candle Light: Menu: Special Effect: <-- 1.CCT 1.OFF 1.DIM: 020 2.HSI 2.Storm *2.SPD: 085 *3.Special Effect *3.Cop Car 3.Mode: Warmer 4.Cycle 4.Candle Light 5.Address 5.250ms 6.Combine Control 6.1000ms User Define 7.Battery 7.SOS <--...
- Page 8 TC-2700K ①CCT option: The function knob is used to adjust the color temperature and the dimmer knob is used Dim:100% to adjust the brightness. (Note: The "038" shows in the figure above means the address code of the fixture, "S" means slave mode. These two modes can be adjusted when entering the interface of "Adress"...
- Page 9 (Note: The function knob is used to select the option and the dimmer knob to adjust the brightness.) (4)Candle Light: Select Candle Light to enter the option of candle light mode. " <--" means return to previous menu. DIM means the brightness of candle light. SPD means the speed of the candle flicker.
- Page 10 (Note: The dimmer knob is used to adjust the saturation of the light. ) ⑤Adress option ADDR:038 is to set the address code for the fixture's wireless control. (Note: The function knob is used to adjust the address code number from 001 to 100.) * 1.Master ⑥Combine Control option is for setting the master-slave mode.
-
Page 11: Safety Precautions
SPECIAL Key: Press SPECIAL to enter the special effect interface, continue to press it to change the effects. COPCAR MODE FLASH TIME Candle Mode Cop Car Candle 1/4s Flash frequency Single *1.DIM:000 0250ms FLASH TIME FLASH TIME SOS_MODE 1s Flash frequency Custom flicker SOS flashing mode 1000ms... - Page 12 Notice 1. When the light is on, don't look direct at the emitter. 2. Don't place objects on the light emitter or allow liquid to flow inside the fixture or the emitter. 3. Don't place fixture near flammable substances like alcohol or gasoline. 4.
- Page 13 PavoTube 15C×1 Power Adapter×1 Clip×1 User Manual×1 USER MANUAL PavoTube 15C RGBWW Tube Light Guangdong NanGuang Photo&Video Systems Co., Ltd Carrying Bag×1 Power Cable×1 Steel Wire Rope×2 The instruction was written according to the strict production test of our company, if there are...
- Page 14 Version:V3 2019-11-12 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...
