Forza 150B
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd

Advertisement

Table of Contents
loading

Related Manuals for NANLITE Forza 150B

Summary of Contents for NANLITE Forza 150B

  • Page 1 Forza 150B USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...

  • Page 2: Product Diagram

    Forza 150B LED Bi-color Spot Light Product Diagram Technical Data Rated Power: 170W Input voltage/current: DC 24V/7.5A Max AC100-240V 50/60Hz Color Temperature: 2700K-6500K CRI: Average 96 TLCI: Average 98...

  • Page 3: Product Details

    Product Details 8. Right knob 9. Lock catch 1. LCD screen 10. Reflector 2. Left knob 3. MODE button 4. DC power socket 5. USB port 11. Angle fixing knob 6. Power switch 12. L Shaped Bracket 7. DMX In/Out 13.

  • Page 4: Detailed Description

    Detailed Description 1. LCD screen: For displaying various function, operations and data. 2. Left knob: For adjusting the DIM and scrolling through different selections. 3. MODE button: For switching between CCT mode, EFFECT mode and MENU. 4. DC power socket: DC power input socket 5.
  • Page 5 Usage 1. Installation of the Reflector ① When installing the reflector, ensure its mounting points align with the slots on the light fixture. When the mounting points and slots are aligned, push the reflector in place and rotate it in the direction shown on the light until it clicks into place.
  • Page 6 2. Installation of Bowens Mount Adapter ① ② Adjust the L bracket to the overhead position first. When installing the adapter, ensure its mounting points align with the slots on the light fixture, rotate it according to the direction shown on the light until the adapter is put into place.

  • Page 7: Remote Control

    Remote Control Forza 150B supports 2.4G remote control, DMX/RDM control, and includes a built-in Bluetooth module as well. · ▲ Address code need to be pre-set for 2.4G remote control, DMX/RDM control solutions.
  • Page 8 MENU MENU CH: 512 LANGUAGE: LANGUAGE: ENG Rotate "Right knob" to CH. MENU MENU LANGUAGE: ENG LANGUAGE: ENG Rotate "Left knob" to select address code. ② DMX Mode Setting MENU MODE LANGUAGE: ENG Press the MODE button to enter the menu.
  • Page 9 MENU MENU BT: RESET LANGUAGE: ENG DMX MODE: ULTIMATE Rotate "Right knob" to DMX MODE MENU MENU BT: RESET BT: RESET DMX MODE: ULTIMATE DMX MODE: CCT 8bit Rotate "Left knob" to select the desired DMX mode. 2. DMX Control ①...
  • Page 10 Refer to the DMX reference guide and control the light via DMX/RDM console. (For detailed operation please refer to the DMX/RDM console operation manual.) Note: DMX reference guide "Forza 150B_REFERENCE_GUIDE_EN" is downloadable from www.nanlite.com. Please scan the QR to check and download the latest DMX reference guide.
  • Page 11 Note: The UID format of the fixture is as follows: 0008 XXXX XXXX Serial number 020B：Forza 150B Manufacturer: Nanguang 4. 2.4G Remote Control Set the address of the 2.4G remote controller to be consistent with the light fixture, enabling the fixture to be ·...
  • Page 12 MENU MENU WIRELESS PRO: V1.0 LANGUAGE: ENG FW UPDATE : UPDATE Rotate ''Right knob'' to WIRELESS PROTOCOL. MENU MENU WIRELESS PRO: V1.0 WIRELESS PRO: V2.0 FW UPDATE : UPDATE FW UPDATE : UPDATE Rotate ''Left knob'' to select V1.0 or V2.0. Operating Instructions 1.
  • Page 13 2. CCT Mode setting Press MODE button to CCT mode, rotate "Left knob" to adjust the DIM (DIM range: 000%…100%), roate "Right knob" to adjust the color temperature (CCT range: 2700K…6500K) CH: 512 000% 6500K MODE Press MODE button to CCT mode. CH: 512 CH: 512 000% 6500K...
  • Page 14 3. EFFECT Mode setting Press MODE button to EFFECT mode. The Forza 150B has built-in effects including CCT LOOP, INT LOOP, FLASH, PULSE, STORM, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION and WELDING.
  • Page 15 ① CCT LOOP CCT LOOP setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 02S…30S), then rotate "Left knob" to adjust the value of DIM, CCT and SPD. EFFECT CH: 512 EFFECT CH: 512 CCT LOOP FX: CCT LOOP DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 16 EFFECT CH: 512 EFFECT CH: 512 FX: INT LOOP FX: INT LOOP DIM: 000%-100% DIM: 001%-100% Rotate "Left knob" to adjust the value of DIM, CCT and SPD. ③ FLASH FLASH setting: rotate "Right knob" to select from DIM, CCT and INTERVALS (Range: 0.1S…10S), then rotate "Left knob"...
  • Page 17 ④ PULSE PULSE setting: rotate "Right knob" to select from DIM, CCT and PULSES/MIN (Range: 001…240), then rotate "Left knob" to adjust the value of DIM, CCT and PULSES/MIN. EFFECT CH: 512 EFFECT CH: 512 FULSE FX: FULSE DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 18 EFFECT CH: 512 EFFECT CH: 512 FX: STORM FX: STORM DIM: 100% DIM: 099% Rotate "Left knob" to adjust the value of DIM, CCT and INTVL. ⑥ TV setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100), then rotate "Left knob"...
  • Page 19 ⑦ PAPARAZZI PAPARAZZI setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100), then rotate "Left knob" to adjust the value of DIM, CCT and SPD. EFFECT CH: 512 EFFECT CH: 512 PAPARAZZI FX: PAPARAZZI DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 20 EFFECT CH: 512 EFFECT CH: 512 FX: CANDLE/FIRE FX: CANDLE/FIRE DIM: 000%-100% DIM: 001%-100% Rotate "Left knob" to adjust the value of DIM, CCT and SPD. ⑨ BAD BULB BAD BULB setting: rotate "Right knob" to select from DIM, CCT and SPD (Range: 001…100), then rotate "Left knob"...
  • Page 21 ⑩ FIREWORK RIREWORK setting: rotate "Right knob" to select from DIM ,CCT, SPD (Range: 001…100) and DECAY (Range: 001…100), then rotate "Left knob" to select from DIM ,CCT, SPD and DECAY. EFFECT CH: 512 EFFECT CH: 512 FIREWORK FX: FIREWORK DIM: 100% DIM: 100% Rotate "Right knob"...
  • Page 22 EFFECT CH: 512 EFFECT CH: 512 FX: EXPLOSION FX: EXPLOSION DIM: 100% DIM: 099% Rotate "Left knob" to select from DIM, CCT, SPD and DECAY. ⑫ WELDING WELDING setting: rotate "Right knob" to select from DIM, CCT, SPD (Range: 001…100) and PAUSE (ON/OFF), then rotate "Left knob"...
  • Page 23 4. MENU setting MENU MODE LANGUAGE: ENG Press MODE button to MENU. MENU MENU CH: 512 LANGUAGE: ENG LANGUAGE: Press "Right knob" to select from CHANNEL, LANGUAGE, FAN, OUTPUT MODE, BLUETOOTH, WIRELESS PROTOCOL, FIRMWARE UPDATE and VERSION. ① CHANNEL For channel setting, please refer to P for detailed operations. ②...
  • Page 24 MENU MENU CH: 512 LANGUAGE: ENG LANGUAGE: Rotate "Right knob" to LANGUAGE. MENU 菜单 CH: 512 CH: 512 LANGUAGE: 语言: 中文 Rotate "Left knob" to select Chinese or English. ③ MENU MODE LANGUAGE: ENG Press MODE button to MENU. MENU MENU FAN: LANGUAGE: ENG...

  • Page 25: Output Mode

    MENU MENU FAN: FAN: UTPUT MODE: CONST UTPUT MODE: CONST Rotate "Left knob" to select ON or OFF. Note: (1)When the fan is turned on, the maximum output of the light will be 100%. (2)When the fan is turned off, the maximum output of the light will be 20%. ④...

  • Page 26: Bluetooth Reset

    ⑤ BLUETOOTH RESET MENU MODE LANGUAGE: ENG Press MODE button to switch to the MENU. MENU MENU RESET LANGUAGE: ENG DMX MODE: ULTIMATE Rotate "Right knob" to BT. MENU BT RESET RESET BACK RESET DMX MODE: ULTIMATE Press "Right knob" to the interface of bluetooth reset. BT RESET BT RESET BACK...

  • Page 27: Dmx Mode

    MENU BT RESET BACK RESET LANGUAGE: ENG Press "Right knob" to confirm reset and it will return to the menu after bluetooth reset. ⑥ DMX MODE For DMX mode setting, please refer to P8 for detailed operation. ⑦ WIRELESS PROTOCOL For wireless protocol setting, please refer to P10 for detailed operation.
  • Page 28 FOUND FIRMWARE FOUND FIRMWARE _V1.02.08 _V1.02.08 BACK UPDATE BACK UPDATE Rotate "Right knob" to select UPDATE. FOUND FIRMWARE FIRMWARE _V1.02.08 UPDATED BACK UPDATE Press "Right knob" to start the update, it will show "FIRMWARE UPDATED" after the firmware update is completed.

  • Page 29: Safety Precautions

    5. Lock or Unlock Settings: long press the "Right knob" to lock the light status. The current light status cannot be changed by pressing the button or rotating the knobs. Long press the "Right knob" again to unlock. EFFECT CH: 512 EFFECT CH: 512 CCT LOOP...
  • Page 30 Notice 1. Please remove the COB protective cap before using the light. 2. Please do not look directly at the emitter when the light is on 3. Please do not place any object on the light emitter or allow liquid to flow inside the fixture or the emitter. 4.
  • Page 31 What's in th box? Please kindly check. AS-BA-FMM AS-CAP-FMM RF-FMM-45 Forza 150B×1 Bowens mount adapter ×1 COB Protective Cap ×1 Reflector ×1 Power Adapter 24V/7.5A×1 Power Cable 4.5M ×1 DMX Reference Guide×1 User Manual×1 Forza 150B Forza 150B USER MANUAL DMX REFERENCE GUIDE Guangdong NanGuang Photo&Video Systems Co., Ltd...
  • Page 32 If the failure is not resolved after troubleshooting, please contact place of purchase. This manual and all stats within it were produced under controlled conditions, and are accurate at time of print. Any future changes to design/technical data can be found at www.nanlite.com.
  • Page 33 Version: V1 2022-04-25 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...

  • Page 34: Fcc Warning

    FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
