Forza 60 $
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd

Advertisement

loading

Related Manuals for NANLITE Forza 60 II

Summary of Contents for NANLITE Forza 60 II

  • Page 1 Forza 60 $ USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...

  • Page 2: Product Diagram

    Forza 60 $ LED Spot Light Product Diagram Technical Data Rated power: 72W Input Voltage/Current: DC15V/6A Max AC100-240V 50/60Hz Color Temperature: 5600K CRI: 95 TLCI: 98...

  • Page 3: Product Details

    Product Details 1. Angle Fixing Knob 4. Lock Catch 11. Right 6. LCD Display Knob 7. Left Knob 12. MODE Button 8. DC Power Socket 9. Power Switch 2. L Shaped Bracket 10. DMX In/Out 5. Reflector 3. Bracket Fixing Knob 13.

  • Page 4: Detailed Description

    Detailed Description 1. Angle Fixing Knob: Allows for vertical adjustments and fixing of the light fixture. 2. L Shaped Bracket: Designed for connecting the light to the light stand and adjusting the direction of light. 3. Bracket Fixing Knob: For locking the light fixture and stand, and adjusting the horizontal direction of light. 4.
  • Page 5 Usage 1. Installation of the Reflector ① When installing the reflector, ensure its mounting points align with the slots on the light fixture. When the mounting points and slots are aligned push the reflector in place and rotate it in the direction shown on the light until it click into place.
  • Page 6 2. Installation of Bowens Mount Adapter ① ② Adjust the L shaped bracket to the top position When installing the adapter, ensure its mounting before installation. points align with the slots on the light fixture, rotate it according to the direction shown on the light until the adapter is put into place.
  • Page 7 ⑤ ⑥ When removing the accessory, push and hold the When removing the adapter, push and hold the release button and rotate according to the direction release button and rotate according to the direction shown on the adapter until the accessory is free to shown on the light until the adapter is free to be be removed from the adapter.

  • Page 8: Remote Control

    Remote Control · Forza 60 II supports DMX/RDM control, 2.4G remote control, and there is built-in bluetooth module. ▲ Address code need to be pre-set for DMX/RDM control and 2.4G remote control. 1. Channel/DMX mode setting, including CH, DMX MODE, DMX REDUCED CH, DMX DIM CURVE and DMX SMOOTHING setting.
  • Page 9 ② DMX Mode Setting MENU MODE BT: RESET Press the MODE button to enter the menu. MENU MENU MODE：ULTIMATE BT: RESET DMX REDUCED：ON Rotate the right knob to DMX MODE. MENU MENU MODE：ULTIMATE MODE：DAYLIGHT DMX REDUCED：ON DMX REDUCED：ON Rotate the left knob to select desired DMX mode.
  • Page 10 ③ DMX REDUCED CH MENU MODE BT: RESET Press MODE button to enter the menu. MENU MENU DMX MODE：DAYLIGHT BT: RESET REDUCED：ON Rotate "right knob" to DMX REDUCED CH. MENU MENU DMX MODE：DAYLIGHT DMX MODE：DAYLIGHT REDUCED：ON REDUCED：OFF Rotate "left knob" to select ON or OFF.
  • Page 11 ④ DMX DIM CURVE MENU MODE BT: RESET Press MODE button to enter the menu. MENU MENU DMX DIM: LINEAR BT: RESET DMX SMOOTHING: OFF Rotate "right knob" to DMX DIM CURVE. MENU MENU DMX DIM: LINEAR DMX DIM: EXPONENT DMX SMOOTHING: OFF DMX SMOOTHING: OFF Rotate "left knob"...
  • Page 12 ⑤ DMX SMOOTHING MENU MODE BT: RESET Press MODE button to enter the menu. MENU MENU DMX DIM: LINEAR BT: RESET DMX SMOOTHING: Rotate "right knob" to DMX SMOOTHING. MENU MENU DMX DIM: LINEAR DMX DIM: LINEAR DMX SMOOTHING: DMX SMOOTHING: Rotate "left knob"...
  • Page 13 2. DMX Control ① Connection between the light and DMX/RDM console with DMX connector cable as below: DMX IN DMX OUT GND 1 1 GND DATA- 2 2 DATA- DATA+ 3 3 DATA+ ② DMX Terminator ln DMX control mode, the DMX output of the last fixture should be connected with a DMX terminator (Not included).
  • Page 14 Control the fixture via a console with RDM function, (For specific operation methods. please refer to the RDM console operation manual.)Note: The UID format of the fixture is as follows: 0008 XXXX XXXX serial number 0208: Forza 60 II Manufacturer: NANGUANG...
  • Page 15 4. 2.4G and Bluetooth Remote Control Forza II 60 is able to be controlled by 2.4G remote controller, or by NANLINK APP via the WS-TB-1 transmitter box · or via Bluetooth directly. ① Note: 2.4G remote controller and WS-TB-1 transmitter box are sold separately. ②...
  • Page 16 Operating Instructions 1. Connection between fixture and power adapter. ① First ensure that the power switch of the fixture is in the "off " position. Now turn on the light, the LCD screen will display all the relevant information for the fixture. DAYLIGHT CH: 512 100%...
  • Page 17 ② Daylight Mode Setting Press the MODE button, switch to the daylight mode, rotate the "left knob" clockwise to increase the brightness and rotate counterclockwise to decrease the brightness. The brightness percentage is displayed on the screen, and the brightness adjustment range is from 000% to 100%. MENU DAYLIGHT CH: 512...
  • Page 18 ③ FX setting: There are a range of built-in effects for Forza 60 II including INT LOOP, FLASH, PULSE, STORM, TV, PAPARAZZI, CANDLE/FIRE, BAD BULB, FIREWORK, EXPLOSION and WELDING. DAYLIGHT CH: 512 EFFECT CH: 512 100% INT LOOP MODE DIM: 000% - 100% Press the MODE button to switch to the special effect interface.
  • Page 19 (2) FLASH EFFECT To set the flash effect, rotate the "right knob" to select DIM and INTVL (interval range: 0.1s to 10.0s). Then rotate the "left knob" to set the corresponding parameters as required. EFFECT CH: 512 EFFECT CH: 512 FLASH FX: FLASH DIM: 100%...
  • Page 20 EFFECT CH: 512 EFFECT CH: 512 FX: PULSE FX: PULSE DIM: 100% DIM: 099% Rotate the "left knob" to set the corresponding parameters. (4) STORM To set the storm effect, rotate the "right knob" to select DIM and INTVL (INTVL range: 01s to 60s), and then rotate the "left knob"...
  • Page 21 (5) TV To set TV special effects, rotate the "right knob" to select DIM and SPD (speed range: 001 to 100), and then rotate the "left knob" to set the corresponding parameters as required. EFFECT CH: 512 EFFECT CH: 512 FX: TV DIM: 000% - 100% DIM: 000% - 100%...
  • Page 22 EFFECT CH: 512 EFFECT CH: 512 FX: PAPARAZZI FX: PAPARAZZI DIM: 100% DIM: 099% Rotate the "left knob" to set the corresponding parameters as required. (7) CANDLE / FIRE To set the candle/fire effect, rotate the "right knob" to select DIM and SPD (speed range: 001 to 100), and then rotate the "left knob"...
  • Page 23 (8) BAD BULB To set the bad bulb effect, rotate the "right knob" to select DIM, INT (INT range: 001 to 100) and SPD (speed range: 001 to 100), and then rotate the "left knob" to set the corresponding parameters as required. EFFECT CH: 512 EFFECT...
  • Page 24 EFFECT CH: 512 EFFECT CH: 512 FX: FIREWORK FX: FIREWORK DIM: 100% DIM: 099% Rotate the "left knob" to set the corresponding parameters as required. (10) EXPLOSION To set the explosion effect, rotate the "right knob" to select DIM, SPD (speed range: 001 to 100) and DECAY (decay range: 001 to 100), and then rotate the "left knob"...
  • Page 25 (11) WELDING To set the welding effect, rotate the "right knob" to select DIM, SPD(speed range: 001 to 100) and PAUSE (on and off), and then rotate the "left knob" to set the corresponding parameters as required. When pause is on, the light is dim.
  • Page 26 (1) For channel setting, please refer to P7 to set the address code. (2) Bluetooth Reset MENU MENU CH: 512 BT: RESET RESET Rotate the "right knob" to BT. MENU BT RESET CH: 512 BACK RESET RESET Press the "right knob" to enter the reset interface. BT RESET BT RESET BACK...
  • Page 27 (3) For DMX MODE setting, please refer to P8 for detailed operations. (4) For DMX REDUCED CH setting, please refer to P9 for detailed operations. (5) For DMX DIM CURVE setting, please refer to P10 for detailed operations. (6) For DMX SMOOTHING setting, please refer to P11 for detailed operations. (7) For WIRELESS PROTOCOL setting, please refer to P14 for detailed operations.
  • Page 28 (9) Firmware Update Insert the USB flash drive with new firmware into the USB port of the fixture. MENU MENU FW UPDATE: UPDATE BT: RESET LANGUAGE: ENGLISH In the menu, rotate "right knob" to FW UPDATE. MENU FOUND FIRMWARE _V1.02.08 FW UPDATE: UPDATE BACK...
  • Page 29 (10) Language Setting MENU MENU FW UPDATE: UPDATE BT: RESET LANGUAGE: ENGLISH Rotate the "right knob" to LANGUAGE. MENU 菜单 FW UPDATE: UPDATE 固件更新：更新 LANGUAGE: ENGLISH 语言：中文 Rotate the "left knob" to select Chinese or English. (11) Version MENU MENU VERSION: V1.02.08 BT: RESET...
  • Page 30 ⑤ Lock or Unlock Settings: long press the "right knob" to lock the light status. The current light status cannot be changed by pressing the button or rotating the knobs. Long press the "right knob" again to unlock. EFFECT CH: 512 EFFECT CH: 512 FLASH...

  • Page 31: Safety Precautions

    Safety Precautions 1. Please open the package to check for damage caused in transit. Please do not use if there is damaged and contact with the dealer or manufacturer as soon as possible. 2. Do not use a power cord with damaged insulation. Do not unplug hard or drag the power cord directly. 3.
  • Page 32 What's in th box? Please kindly check. Forza 60 II ×1 Power Adapter ×1 Power Cable 3M ×1 User Manual × 1 Forza 60 $ USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd Carrying Bag ×1 Bowens mount adapter ×1 COB Protective Cap ×1 DMX Reference Guide ×1...
  • Page 33 General Fault Detection and Diagnosis Diagnosis Fault Detection 1. Please check whether there is loose connection between the power adapter and the power cable or the power adapter and the outlet. 2. Please check whether the voltage of power adapter is within designated The light won't start up.
  • Page 34 Version: V3 2022-07-29 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...
