Dual VESA Sleeve for Dell
Model 101-2110
Full product specifications: www.humancentric.com/101-2110
Need help? Contact support: support@humancentric.com
To reduce the risk of injury to persons, read all important precautions and warnings listed below. HumanCentric
assumes no responsibility for personal injury or property damage sustained by or through the use of this product:
1.
Read all instructions carefully.
Incorrect installation may lead to damages or serious injury. Ensure the product is secured before use.
2.
Make sure the monitor mount that this product will be mounted to can support the combined weight of the
3.
monitor, computer, and adapter.
PARTS INCLUDED
A (x1)
Dual VESA Adapter
G (x4)
Spacer - 18mm
ADDITIONAL TOOLS REQUIRED
Pencil
Phillips Screw Driver
Drill
5/16" Drill bit
1/8" Drill Bit
© 2023 HumanCentric Ventures LLC
OptiPlex
TM
TM
WARNING
B (x2)
Straps
D (x4)
M4 x 30mm Screw
H (x4)
Drywall Anchor
M4 x 12mm Screw
E (x4)
M4 x 19mm Wood Screw
Note: Optional metal power supply holder sold separately
www.humancentric.com/patents
C (x8)
F (x4)
M4 x 30mm Wood Screw
I (x2)
Thumb Screw
www.humancentric.com
