Wall Mount for Sonos Playbar
Model 101-2031
www.humancentric.com/patents
PARTS INCLUDED
Mounting bracket A
Mounting bracket B
ADDITIONAL TOOLS REQUIRED
Philips Head Screwdriver
Power drill with 17/64" (6.75mm) bit
Level
Marking Pencil
Edge-finding stud locator (for stud wall mounting)
COMPATIBLE WITH MODELS
Fits Sonos Playbar
© 2018 HumanCentric Ventures LLC
Stud mounting screws (4)
Rubber washer (4)
Thumb nuts (4)
Drywall Anchors (4)
Drywall screws (4)
www.humancentric.com
1
