HumanCentric 101-2078 Quick Installation Manual

Component wall mount

Component Wall Mount

Model 101-2078

Full product speciﬁcations: www.humancentric.com/101-2078

Need help? Contact support: support@humancentric.com

To reduce the risk of injury to persons, read all important precautions and warnings listed below.

HumanCentric assumes no responsibility for personal injury or property damage sustained by or through

the use of this product:

1. Read all instructions carefully.

2. Incorrect installation may lead to damage or serious injury. Ensure the product is secured before use.

3. When mounting this product on a wall, make sure it can support the combined weight of the device

and adapter.

Phillips head screwdriver

17/64 inch diameter drill bit

Power drill

Hammer

A (x1)

WARNING

B(x4)

C(x4)

www.humancentric.com/patents

D(x2)

E(x2)

www.humancentric.com

Table of Contents

Do you have a question about the 101-2078 and is the answer not in the manual?

Page 1 WARNING To reduce the risk of injury to persons, read all important precautions and warnings listed below. HumanCentric assumes no responsibility for personal injury or property damage sustained by or through the use of this product: 1. Read all instructions carefully.
Page 2 1. MOUNT ON DRYWALL USE 17/64” DRILL BIT 2. SELECT AND INSERT STRAPS 3. MOUNT DEVICE D or E Velcro Side Non-Velcro Side © 2019 HumanCentric Ventures LLC www.humancentric.com...
