Eneo IED-FMH1 Quick Installation Manual

[ Figure 8 : Exploded Assembly ]
ITEM PART NAME
1 ASS'Y TRIM RING
2 BASE BRACKET
3 GUIDE BRACKET
4 DOME RING
5 LEVER CLAMP
6 SCREW SPECIAL
7 SCREW MACHINE
8 E-RING
9 HEX SUPPORT
10 SUPPORT RING
ITEM PART NAME
1 SCREW MACHINE M6 x 12L / HEAD 8.55
2 SAFETY RING CABLE
3 SCREW TAPPING(1) M4, L=12
4
SCREW TAPPING(2) M4, L=8
