Installation Instructions
REV 7 10/15/23
Hardware
Torque Aluminum Torque Steel to Steel
M6 Bolt
3 ft-lbs.
M8 Bolt
7 ft-lbs.
M10 Bolt
16 ft-lbs.
M12 Bolt
28 ft-lbs.
Attention: Please make sure that you have the latest instructions
from Romik.com
Part No.
Product: Running Boards
Application:
Level of Difficulty: 1 2 3
Installation Time: 120 Min.
ATTENTION: Use correct torque settings to avoid
14 ft-lbs.
damaging the running boards and or mounting
35 ft-lbs.
brackets. Failure to do so will void your warranty. If
64 ft-lbs.
you have any questions, please contact our technical
112 ft-lbs.
team at 1-866-717-6645
1619
RAM ProMaster 2014 – Present
136 & 159 models only.
4
5
QR Scan
Advertisement
Related Manuals for Romik ROB-C
Summary of Contents for Romik ROB-C
- Page 1 Failure to do so will void your warranty. If M10 Bolt 16 ft-lbs. 64 ft-lbs. you have any questions, please contact our technical M12 Bolt 28 ft-lbs. 112 ft-lbs. team at 1-866-717-6645 Attention: Please make sure that you have the latest instructions from Romik.com QR Scan...
- Page 3 Installation Instructions 1619 Bracket Kit Important Install Tip: When installing Romik HTC inserts. Test by tugging on it before installing braket. Blue loctite is highly recommended. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it.
- Page 4 Installation Instructions 1619 Bracket Kit Passenger Side note bracket positioning (Long wheel base shown) Step 4: Locate and remove rubber plugs from the first mounting location approx. 37 inches from the front mudflap area. Install provided HTC 325 as shown Figure 6. Figure 6 Step 3: Install bracket #4 and support bracket #6 as shown on Figure 7 snug but do not tighten.
- Page 5 Installation Instructions 1619 Bracket Kit 159 Inch wheelbase bracket position shown for 136 WB reverse rear bracket and middle bracket Step 4: Locate and remove rubber plugs from the second mounting location approx. 59 inches from the front mudflap area. Install provided HTC 325 as shown Figure 8. Figure 8 Step 5: Install main bracket #4 and support bracket #5 as shown on Figure 9 snug but do not tighten.
- Page 6 14 ft. lbs. Recheck hardware after 1,000 miles of use. Step 8: Once all the brackets are installed proceed and assemble the Romik “connect” running boards. See next page for detailed instructions. Place the boards on the brackets and tighten them to our torque specs.
- Page 8 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
