Problem
GRID – Green LED
does not blink

Maintenance

Cleaning and sanitizing

It is advised to regularly clean the casing of the charge point using a simple damp cloth. Also, make sure no
plants are growing on or against the charge point.
Do not use high pressure water hose to clean the product.
ƒ
Do not use aggressive cleaning agents to clean the product.
ƒ
Do not clean the inside of the product.
ƒ
Periodic maintenance
Annual check:
Inspect for visible cracks or physical damage on the casing, grommets, mounting structure, and/or tethered
ƒ
cable (when applicable) as well as for evidence of water leaks. In case of any of these, suspend use of the
charge point, switch off the protection device in which the charge point is installed and contact Shell
Recharge Solutions.
if all the screws and connectors are securely tightened on the components in the consumer unit. Check the
ƒ
connectors of the MCB, RCD, RCBO, Dynamic Power Management module, etc.
if all the screws are securely tightened on the components in the charge point. Check the connectors of the
ƒ
terminal blocks, power meter, contactor, etc.
if there are no bugs or plants inside the charge point. If this is the case, use a smaller grommet for the power
ƒ
cable or check if there is another possible way that the bugs have entered the charge point.
Disposal
Before disposing of the different materials, separate them into recyclables, normal waste and special waste.
User manual – Advanced View 2.3 - 075SRUSR01EN
Possible cause
ƒ There is a power outage on the house
ƒ The household is consuming too little
energy for the current sensor to
measure consumption.
ƒ The wires of the current sensors are
not connected properly
ƒ The current sensor or the Dynamic
Power Management module is broken
Solution
Fix the power outage and proceed
Increase the energy consumption of the house
Measure the household current by applying your current
clamp to each phase of the household connection. If your
current clamp indeed measures a current consumption,
please proceed.
Use the Installer App to check if the current sensors are
measuring energy.
If the Installer App shows that the current sensors are
measuring, there is no problem.
If there is no consumption measured:
Compare the measurements of the Installer App with a
current clamp by connecting your current clamp to each
phase of the household connection.
If the measurements between the Installer App and
your current clamp are different, please proceed.
Check if the current sensors are connected as
explained in figure .
Use a screwdriver to tighten the screws.
Please contact your local Shell Recharge Installation
desk.
