Summary of Contents for Kanguru Defender Bio-Elite30
- Page 1 Defender Bio-Elite30 User Manual For Models: • Defender Bio-Elite30 Copyright 2019, All Rights Reserved...
-
Page 2: Notices And Information
Kanguru Solutions will not be held responsible for any illegal use of this product nor any losses incurred while using this product. The user is solely responsible for the copyright laws, and is fully responsible for any illegal actions taken. -
Page 3: Table Of Contents
Table of Contents taBLE of coNtENts introduction ..................4 1.1 Package Contents ................4 1.2 System Requirements ..............4 first time setup ..................5 Logging in ....................9 3.1 Login Through KDMBio (Windows and Mac) ......9 3.2 Login Using Fingerprint Only ............10 3.3 Resetting the Device ...............11 the command console ..............12 4.1 View Encrypted Files..............13 4.2 About This Device ................14... -
Page 4: Introduction
Introduction 1. introduction The Kanguru Defender Bio-Elite30 flash drive is a hardware encrypted, tamper proof USB flash drive with a high-resolution, biometric scanner. The Defender Bio-Elite30 contains two partitions: a virtual DVD-RW partition and a secure, encrypted storage partition. The virtual DVD-RW partition contains the Kanguru Defender Manager Bio application (referred throughout this document as KDMBio) that allows you to configure and manage the device. -
Page 5: First Time Setup
First Time Setup 2. first time setup While the Defender Bio-Elite30 can be configured for use with any operating system, the initial setup requires running the KDMBio application on a Mac or Windows based computer. To configure your Defender Bio-Elite 30 for use: 1. - Page 6 First Time Setup 4. Enter a device name, phone number and primary email address in the appropriate fields and then click on the apply button. After your contact information has been added to your device you will be able to click on the Next button to proceed.
- Page 7 First Time Setup 8. On the fingerprint enrollment screen, click on the circle located over the finger that you are enrolling. A dot will appear within the center of the circle to signal that it is selected. 9. Configure permissions given when logging in with this fingerprint. ○...
- Page 8 First Time Setup You can enroll up to 6 fingerprints, each with their own permission configuration. • A hollow circle above a finger indicates that it has not been registered. • An icon appearing within the circle above a finger indicates that it has been registered. The icon displayed within the circle varies based on the permissions set for that fingerprint: ○...
-
Page 9: Logging In
1. Insert your Defender Bio-Elite30 device into an available USB port. 2. Locate and open the Defender Bio-Elite30 DVD-RW partition in file explorer and run KDMBio. 3. The Login screen appears. You can either scan a registered fingerprint or enter your security password in the ‘Password’... -
Page 10: Login Using Fingerprint Only
To access the secure storage partition using only your fingerprint: 1. Insert your Defender Bio-Elite30 device into an available USB port. 2. Use one of the fingers that you registered during the first time setup to tap the scanner on the back of the Bio-Elite30 device. -
Page 11: Resetting The Device
To delete all personal data and reset your device back to the factory state: 1. Locate and open the Defender Bio-Elite30 DVD-RW partition in file explorer and run KDMBio. 2. The Login screen appears. Click the reset button. 3. Confirm the reset by selecting Yes when asked if you are sure you want to reset the device. -
Page 12: The Command Console
The Command Console 4. the command console If you used KDMBio to log into your Defender Bio-Elite30 device, the Command Console appears. If the Command Console doesn’t automatically appear, you can launch it by clicking the Kanguru icon located in the taskbar area on Windows or the menu bar area on Macs. -
Page 13: View Encrypted Files
The Command Console 4.1 View Encrypted files A key feature of the Defender Bio-Elite30 drive is drag & drop encryption; allowing you to simply drag files that you want encrypt directly onto the drive. The device automatically encrypts these files as they are transferred to the secure storage partition, ensuring that your data stays safe and private. -
Page 14: About This Device
The Command Console 4.2 about this Device Click on about this Device from the menu bar on the left of the Command Console to view basic information about your drive including: details about used/remaining/total storage capacity, firmware version, serial number, release date and whether Antivirus and/or Onboard Browser are enabled. 4.3 contact info Click on contact info from the menu bar on the left of the Command Console to view the contact information saved to this device. -
Page 15: Antivirus
Kanguru, or to apply a license that you have already purchased from Kanguru. Once you have received an AntiVirus license key from Kanguru, copy the license key into the ‘New License Key’ field and then click the apply button. - Page 16 The Command Console the Defender will save your place and continue the download the next time it is connected to a computer with internet access. caution! Do not store any data in the ‘System’ folder in the secure storage partition. Any data saved here that does not pertain to virus definitions will be automatically deleted.
-
Page 17: Onboard Applications
4.5 onboard applications Click on onboard applications from the menu bar on the left of the Command Console to access the applications that can be run securely from the Defender Bio-Elite30. Each Onboard Application has two buttons: • start - Launch the application • Manage - Allows you to:... -
Page 18: Onboard Browser
The Command Console 4.5.1 onboard Browser One of the main features of the Defender Bio-Elite30 is the secure, onboard web browser. The onboard web browser runs Mozilla FireFox completely self-contained within the Defender Bio-Elite30 device. Browsing history, bookmarks, stored passwords and any information saved within the onboard browser is only accessible by first logging into KDMBio. -
Page 19: Settings
The Command Console 4.6 settings Click on settings from the menu bar on the left of the Command Console to manage passwords, fingerprints, KRMC and other settings. 4.6.1 change Password Click on the change Password tab within the Settings menu to manage the password that you use to login to KDMBio. -
Page 20: Krmc
The Command Console 4.6.2 KrMc Click on the KrMc tab within the Settings menu to register your device with a KRMC Cloud account. Note: If the KRMC tab is not visible within the Settings menu then the device is already registered with a KRMC Cloud account. -
Page 21: General
The Command Console 4.6.3 General Click on the General tab within the Settings menu to configure the following settings for your device: • Minimum Password Length - Number of characters a KDMBio login password must contain in order to be valid. • application Language - The language that KDMBio text and menus will be displayed in. -
Page 22: Fingerprints
The Command Console 4.6.4 fingerprints Click on the fingerprints tab within the Settings menu to manage fingerprints registered with your device or to enroll new fingerprints. You can have up to 6 fingerprints registered at any time, each fingerprint with their own permissions configuration. - Page 23 The Command Console To manage fingerprints, click on the circle located over a finger to select a fingerprint to manage. A dot will appear within the center of the circle to signal that it is selected. If you are enrolling a new fingerprint: 1.
-
Page 24: Logout And Removing The Device
Logout and Removing the Device 5. Logout and removing the Device You should always safely unmount the secure storage partition before disconnecting the Bio-Elite30 from the computer. Do not attempt to remove the device while an application is accessing data on the secure storage partition. -
Page 25: Warranty Information
Solutions is not responsible for any damages incurred in the shipping process. Any claims for loss or damage must be made to the carrier directly. Claims for shipping errors should be reported to Kanguru Solutions within three (3) working days or receipt of merchandise. - Page 26 Kanguru Solutions 1360 Main Street Millis, MA 02054 www.kanguru.com 09.26.19 v1.0 © 2019 Kanguru Solutions Legal terms and conditions available at www.kanguru.com. Please review and agree before use. Thank you.
