IB series
1 - 15 HP
@ 1750 & 3500 RPM
barmesapumps
IMPORTANT! - Read all instructions in this manual before operating or servicing
a pump.
North America: 866 777 6060
Int'l: +1 267 404 2910
Installation, Operation &
Maintenance Manual
End Suction Centrifugal Pumps
Springer Pumps
Springer Parts
Last update: 12/06/2022
www.springerpumps.com
www.springerparts.com
Advertisement
Table of Contents
Related Manuals for Barmesa Pumps IB Series
Summary of Contents for Barmesa Pumps IB Series
- Page 1 Installation, Operation & Maintenance Manual End Suction Centrifugal Pumps IB series 1 - 15 HP @ 1750 & 3500 RPM barmesapumps IMPORTANT! - Read all instructions in this manual before operating or servicing a pump. Last update: 12/06/2022 North America: 866 777 6060 Springer Pumps www.springerpumps.com...
-
Page 2: General Safety Information
(flammable, caustic, etc.) or use these pumps in Model Number: _____________________ IMPORTANT! - Barmesa Pumps is not water over 160 °F. Do not exceed responsible for losses, injury or m a n u f a c t u r e r s r e c o m m e n d e d... -
Page 3: Specifications And Dimensions
Specifications & Dimensions SUCTION: 2" - 3" NPT. DISCHARGE: 1½" - 2½" NPT. LIQUID TEMPERATURE: 160 °F (71 °C) max. VOLUTE: Cast iron ASTM A-48 class 30. INTERMEDIATE COUPLING: Cast iron ASTM A-48 class 30. IMPELLER: Closed, dynamically balanced. Stainless steel 304. SEAL: Mechanical, type 01. - Page 4 Recommendations & Warnings 4Receiving inspection 4Service Stations 4Suction pipe hose reinforced Upon receiving the pump, it should To find the nearest Barmesa Pumps inspected damage authorized service shop, please sufficiently robust prevent collapsing by the difference in shortages. If damage has occurred, directly contact your distributor or atmospheric pressure.
-
Page 5: Installation
Installation Figure 2 Wrong installation. A valve in the suction pipe is not recommended Air leaks pocket Long piping Concentric reducer Too much height "D" Piping elbow immediately installed after the suction Vortex Less than 4 "D" Without strainer barmesapumps Figure 3 Inclination. - Page 6 Installation & Operation Figure 6 Discharge piping. Correct Incorrect Expansive joint Safety shutoff valve Service valve Expansive joint Swing check valve could cause a "water hammer" barmesapumps Retarded action Service valve check valve In order to determine the optimal 2. Check Pump Rotation - Improper 4. Priming - Every centrifugal pump size of the piping, compare the total motor rotation can result in poor...
-
Page 7: Operation And Maintenance
Operation & Maintenance 4Starting Step 1: Install the intermediate Mechanical Seal - To inspect or When starting for the first time your coupling previously replace the shaft seal, remove the equipment check that the discharge body and impeller. If any part shows removed. -
Page 8: Maintenance
Maintenance Figure 7 Mechanical seal - Assembly. Intermediate Impeller coupling Shaft Impeller Seal lockwasher rotating member Shaft sleeve Hex. Lockwasher Spring screw Seal stationary barmesapumps Figure 8 Mechanical Seal - Sectional View. 1 - Ceramic seat 2 - Seal seat Buna-N 3 - Inox. - Page 9 Installation Table 1 Friction in meters x 100 m of piping. PIPING DIAMETER LITERS GALLONS 1" 1¼" 1½" 2" 2 ½" 3" 4" 5" 6" 8" 10" MINUTE MINUTE 4.54 6.86 1.77 9.62 2.48 16.2 1.53 20.6 5.22 2.42 25.1 6.34 2.94 38.7...
- Page 10 Installation Table 1 Equivalent length in meters of straight pipe and valve connections for calculating friction. DIAMETER PART DESCRIPTION 1" 1¼" 1½" 2" 2 ½" 3" 4" 5" 6" STANDARD 90° 0.84 1.07 1.22 1.68 1.98 2.44 3.35 4.12 4.88 ELBOW MEDIUM RADIUS 0.69 0.92 1.07 1.37 1.68 2.14 2.75 3.51 4.27...
-
Page 11: Parts List
Parts List barmesapumps 4Model IB1½ ITEM PART No. DESCRIPTION QTY. 03090050 Volute case 03140100 Impeller Ø4.375" (1.5 HP, 3600 RPM) 03140100B Impeller Ø4.625" (2 HP, 3600 RPM) 03140100C Impeller Ø5.063" (3 HP, 3600 RPM) 03140100D Impeller Ø5.875" (5 HP, 3600 RPM) Impeller Ø6.250"... - Page 12 Parts List 4Model IB2 ITEM PART No. DESCRIPTION QTY. 03090051 Volute case 03140101 Impeller Ø4.125" (2 HP, 3600 RPM) 03140101B Impeller Ø4.750" (3 HP, 3600 RPM) 03140101C Impeller Ø5.375" (5 HP, 3600 RPM) 03140101D Impeller Ø6.062" (7.5 HP, 3600 RPM) Impeller Ø6.250"...
-
Page 13: Troubleshooting Chart
- That the motor is suitable for the pump. NOTE: Barmesa Pumps assumes no responsibility for damage or injury due to disassembly in the field. Disassembly of the pumps or supplied accessories other than at Barmesa Pumps or its authorized service centers, automatically voids warranty. - Page 14 BARMESA PUMPS FACTORY WARRANTY Barmesa Pumps warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for 18 months from date of manufacture or 12 months from installation date whichever occurs first. This warranty gives you specific legal rights, which vary from state to state.
