Installation of this device should be carried out by a qualified installer after re-
ading this manual. Dismantling the casing of the device will automatically void
the warranty. Before starting the assembly, make sure that the connecting
wires are not live. Conditions of storage, transport and use affect the proper
operation of the device.
Features of the module
Single bistable relay;
Cooperation with remote control transmitters of the F&Wave system;
The ability to control from up to 8 transmitters;
Local control - the ability to directly control the relay using any monostable button
(for example: bell button);
Separated output contact NO with load capacity of 16 A (AC-1);
Compact enclosure - takes only 1 field in the switchboard;
Retransmission of commands from the transmitter - the ability to increase the
range of the remote control;
Low power consumption - low operating cost;
Built-in electronic thermal protection to prevent damage in case of excessive load
of the relay.
Description of the device
- 2 -
