System capabilities
» Communication via home Wi-Fi network;
» Remote access to devices via the Polish F&F cloud;
» Integration with Google and Google Home voice assistant;
» Ability to work autonomously, without a Wi-Fi connection;
» Advanced programmable timers based on online calendars
and enhanced with astronomical functions;
» Free mobile applications for Android and iOS.
www.fif.com.pl/fox/singleswitch-d
Single Switch-D
Wi-R1S1-D
1-channel
Wi-Fi relay
for DIN rail
- 1 -
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for F&F Fox Single Switch-D
Summary of Contents for F&F Fox Single Switch-D
- Page 1 Single Switch-D Wi-R1S1-D 1-channel Wi-Fi relay for DIN rail www.fif.com.pl/fox/singleswitch-d F&F Filipowski L.P.; Konstantynowska 79/81, 95-200 Pabianice, PL www.fif.com.pl; e-mail: biuro@fif.com.pl System capabilities » Communication via home Wi-Fi network; » Remote access to devices via the Polish F&F cloud; » Integration with Google and Google Home voice assistant; »...
- Page 2 Properties » Separated relay output with changeover contact, rated up to 16 A; » Possibility of connecting an external push button for local con- trol of the unit; » Receiver control via mobile app and time programmers; » Built-in RTC clock with power supply backup and local copy of settings guarantees correct operation of the programmer even in the event of lack of Wi-Fi connection;...
- Page 3 Configuration For the initial configuration of the Fox module, it is necessary to download and run the free Fox application available for mobile devices running the system: » Android, version 8.0 or higher; » iOS, version 14 or higher. You can download the app directly from the stores: or via the website: www.fif.com.pl/fox On the above page, you can also find detailed information on...
-
Page 4: Wiring Diagram
Wiring diagram - 4 -... - Page 5 Description of terminals power suply – phase wire power supply – neutral wire local control button input COM – common contact for internal relay NC – normally closed contact for internal relay NO – normally open contact for internal relay It is recommended to use monostable (momentary) buttons.
- Page 6 First launch Once you have connected your new device to the power supply, it is advisable to carry out personalisation, i.e. linking it to your phone and user account. To do this, launch the Fox app, select the settings icon , then the Add new device command. If you are running the application on your phone for the first time, follow the programme’s instructions to register a user account or log in to an existing account,...
- Page 7 Once the search process is complete, the new Fox devices will be displayed. The Single Switch-D module will appear in the list as follows: - 7 -...
- Page 8 To add a new device, you must first connect to it (press the Con- nect button) and, once it has been established (figure below), press the Configure button and continue following the instruc- tions of the application. - 8 -...
- Page 9 LED signalling The status of the module can be directly assessed by the STATUS light located on the front of the device. The grey color actually corresponds to the green LED and the black color to the red LED. Controller in factory mode Connecting to a Wi-Fi network...
-
Page 10: Restore Factory Settings
Restore factory settings If you are unable to access the controller, we recommend that you restore the controller to factory settings and reconfigure it using the Fox app. To restore the factory settings, proceed as follows 1. While the controller is operating, press and hold the PROG button on the front of the controller. - Page 11 Technical data power supply 165÷265 V AC control input type digital galvanic separation brak control voltage 165÷265 V AC control pulse current <2 mA outputs type relay contact NO/NC galvanic separation maximum load current* resistive load 16 A contact voltage 250 V AC 24 V DC power consumption standby <1.2 W operation (output on) <2 W...
-
Page 12: Warranty
terminal 2.5 mm² screw terminals (cord) 4.0 mm² screw terminals (wire) tightening torque 0.5 Nm working temperature 0÷45°C humidity <90% (no condensation of steam and aggressive gases) dimensions 1 module (18 mm) mounting on TH-35 rail ingress protection IP20 Warranty F&F products are covered by a 24-month warranty from the date of purchase.
