System capabilities
» Communication via home Wi-Fi network;
» Remote access to devices via the Polish F&F cloud;
» Integration with Google and Google Home voice assistant;
» Ability to work autonomously, without a Wi-Fi connection;
» Advanced programmable timers based on online calendars
and enhanced with astronomical functions;
» Free mobile applications for Android and iOS.
Double Switch-D
Wi-R2S2-D
2-channel
Wi-Fi relay
for DIN rail mounting
- 1 -
Advertisement
Related Manuals for F&F FOX Double Switch-D
Summary of Contents for F&F FOX Double Switch-D
- Page 1 Double Switch-D Wi-R2S2-D 2-channel Wi-Fi relay for DIN rail mounting www.fif.com.pl/fox/doubleswitch-d F&F Filipowski L.P.; Konstantynowska 79/81, 95-200 Pabianice, PL www.fif.com.pl; e-mail: biuro@fif.com.pl System capabilities » Communication via home Wi-Fi network; » Remote access to devices via the Polish F&F cloud; »...
- Page 2 Properties » 2 separated relay outputs with changeover contact, rated up to 16 A; » Possibility of connecting external push buttons for local con- trol of the relays; » Control of receivers via mobile app and time programers; » Built-in RTC clock with power supply backup and local copy of settings guarantees correct operation of the programmer even in the event of lack of Wi-Fi connection;...
- Page 3 Configuration For the initial configuration of the Fox module, it is necessary to download and run the free Fox application available for mobile devices running the system: » Android, version 8.0 or higher; » iOS, version 14 or higher. You can download the app directly from the stores: or via the website: www.fif.com.pl/fox On the above page, you can also find detailed information on...
- Page 4 Wiring diagram Inputs control (level L) - 4 -...
- Page 5 Inputs control (level N) - 5 -...
- Page 6 Description of terminals power supply power supply local push-button input S1 (control of receiver R1) local push-button input S2 (control of receiver R2) COM1 – channel 1 – COM contact – channel 1 – normally closed contact – channel 1 – normally open contact COM2 –...
- Page 7 First launch Once you have connected your new device to the power supply, it is advisable to carry out personalisation, i.e. linking it to your phone and user account. To do this, launch the Fox app, select the settings icon , then the Add new device command. If you are running the application on your phone for the first time, follow the programme’s instructions to register a user account or log in to an existing account,...
- Page 8 Once the search process is complete, the new Fox devices will be displayed. The Double Switch-D module will appear in the list as follows: - 8 -...
- Page 9 To add a new device, you must first connect to it (press the Con- nect button) and, once it has been established (figure below), press the Configure button and continue following the instruc- tions of the application. - 9 -...
- Page 10 LED signalling The status of the module can be directly assessed by the STATUS light located on the front of the device. The grey color actually corresponds to the green LED and the black color to the red LED. Controller in factory mode Connecting to a Wi-Fi network...
- Page 11 Restore factory settings If you are unable to access the controller, we recommend that you restore the controller to factory settings and reconfigure it using the Fox app. To restore the factory settings, proceed as follows 1. While the controller is operating, press and hold the PROG button on the front of the controller.
- Page 12 Technical data power supply 165÷265 V AC control input type digital galvanic separation control voltage 165÷265 V AC control pulse current <2 mA outputs type relay contact 2×NO/NC galvanic separation maximum load current* resistive load 16 A/channel contact voltage 250 V AC 24 V DC power consumption standby <1.2 W operation (output on) <2 W communication...
- Page 13 terminal 2.5 mm² screw terminals (cord) 4.0 mm² screw terminals (wire) tightening torque 0.5 Nm working temperature 0÷45°C humidity <90% (no condensation of steam and aggressive gases) dimensions 2 modules (35 mm) mounting on TH-35 rail ingress protection IP20 Warranty F&F products are covered by a 24-month warranty from the date of purchase.
