- Page 1 MULTIBOARD Quick Start Guide 2019...
-
Page 3: Table Of Contents
Contents 1. Safety information ....................1 2. Preparing for operation ………………………………………………………………………………………….. 3 3. The stand kit …………………………………………………………………………………………………………… 4 4. Control Panel ......................5 Prepare to install ………………………….……………………………………………………………....5 Terminal Interface ……...................... 5 Remote Control ....................... 7 5. Connection and Setting ..................10 6. -
Page 4: Safety Information
User manual Prestigio Multiboard 1. Safety information Safety Warning • Before operating, please read this manual thoroughly, and keep it for future reference. • Image shown in this manual is indicative only. There may be differences between the pictures and the actual product, please prevail in kind. - Page 5 User manual. Prestigio hereby states that this panel complies to basic requirements and another relevant regulations given by the EU CE directives 2014/30/EU. Full version of the www.prestigio.com...
-
Page 6: Preparing For Operation
You can fix the device to the wall using the wall mounting kit. • This MultiBoard multimedia panel can only be attached to the wall using the wall mounting kit recommended by Prestigio. Use of other wall mounting equipment may lead to unstable installation and risk causing serious injury. -
Page 7: The Stand Kit
User manual Prestigio Multiboard 3. The stand kit • Prestigio MultiBoard multimedia panel • Remote control* • 4 writing pens* • 1 interactive pen* • Power cord • 2 pens for simultaneous writing* • VGA cable • USB cable • Audio cable •... -
Page 8: Control Panel
User manual Prestigio Multiboard 4. Control panel Prepare to install Number Items Function description Magnetic zone Area for placing the absorptive magnetic pen Tap to enter energy-saving, press at least 2 seconds to enter standby mode Remote control Receive the remote signal. - Page 9 User manual Prestigio Multiboard Number Items Function description External computer image input AUDIO IN External computer audio input SPDIF Carry multichannel sound via optical signals. RS232 Serial interface, used for mutual transfer of data between devices AUDIO OUT Audio output to the external speaker Connect RJ45 terminals USB 2.0,connect USB devices such as mobile hard disk, U disk, USB...
-
Page 10: Remote Control
User manual Prestigio Multiboard Remote control Remote control button instruction EN - 7... - Page 11 User manual Prestigio Multiboard Detailed Function Description Number Items Function description Power on/off Enter or exit mute mode. Start PC's Windows key Space PC's Space key Alt+Tab PC's Alt+Tab key Alt+F4 PC's Alt+F4 key Numeric keys Numeric input keys Display...
- Page 12 User manual Prestigio Multiboard Remote Control Instruction Install Batteries 1) Open back cover of battery component on the back of remote control. 2) Install AAA type battery according to the corresponding electrode, make sure battery positive and negative pole are correct ("+"to"+", "-" to "-"), please do not mix using old and new batteries.
-
Page 13: Connection And Setting
User manual Prestigio Multiboard 5. Connection and setting For the safety of you and the machine, please do not connect any power plug before connection. 1. External Computer and Touch Connection 1) Use VGA cable to connect to VGA output port of external computer, and meanwhile use headphone audio cable to connect to external computer audio output interface. - Page 14 User manual Prestigio Multiboard 2. Audio and Video Equipment 1) Use HDMI cable to connect audio and video equipment with HDMI output. 2) After cable connection, plug in power cord, and switch power on. 3) Press to turn equipment on.
- Page 15 User manual Prestigio Multiboard 6. USB Connection EN - 12...
-
Page 16: Menu Operation
User manual Prestigio Multiboard 6. Menu operation Touch Menu Operation Call up Method Take middle point position on the bottom of display screen as starting point, Use touch pen to drag towards screen center position to call up touch menu, as shown below. - Page 17 User manual Prestigio Multiboard Setting Menu General Setting • Press INPUT button on remote control or via touch A method to call up General Setting menu. • Press button on remote control to select the channel you need. • Press the Enter button on remote control or directly click with touch pen to confirmselected input channel.
- Page 18 User manual Prestigio Multiboard Detail Setting Menu Press Menu on remote control or click the icon on General Setting menu with touch pen to call up detail setting menu. Detail setting menu includes Audio, Screen, Display and Adjust. Audio • Press button on remote control to select Audio setting menu.
- Page 19 User manual Prestigio Multiboard Screen • Press button on remote control to select Screen setting menu. • Press on remote control or directly click with touch pen to select the option. • Press Enter on remote control or directly click with touch pen to enter the selected mode.
- Page 20 User manual Prestigio Multiboard Display • Press button on remote control to select Display setting menu. • Press button on remote control or directly click with touch pen to select the option. • Press Enter on remote control to enter adjustment mode, and press button or directly click with touch pen to adjust each option.
- Page 21 User manual Prestigio Multiboard Adjust • Press button on remote control to select Adjust setting menu. • Press button on remote control or directly click with touch pen to select the option. • Press Enter on remote control to enter adjustment mode, and press button or directly click with touch pen to adjust each option.
-
Page 22: Simple Troubleshooting
User manual Prestigio Multiboard 7. Simple troubleshooting Machine Fails to Work Normally Remote control failure Check whether there are other objects between remote control and equipment control receiving window, thus leading to failure of remote control. Check whether the battery electrode in the remote control is correct. - Page 23 User manual Prestigio Multiboard Video Function Can’t Work Normally No picture and no Check whether the machine is started state. sound Check whether signal wire is well plugged, whether INPUT is corresponding to it. If in internal computer mode, check whether internal computer is started.
-
Page 24: Maintenance
User manual Prestigio Multiboard 8. Maintenance Proper maintenance can avoid many early faults and regular careful cleaning can make machine brand new. Please unplug power plug before cleaning and maintenance, to prevent electric shock. Clean Screen Please mix and stir even a little fabric softener or tableware detergent with alcohol. -
Page 25: Technical Specifications
User manual Prestigio Multiboard 9. Technical specifications PMB432D435/ PMB528L552/ PMB528L652/ PMB728L655/ PMB528L701/ PMB728L752/ PMB728L862/ PMB751G983/ ARTICLE PMB000D435* PMB000L550* PMB000L650* PMB000L655* PMB000L700* PMB000L750* PMB000L860* PMB000G980* Screen size, inch 43" (UHD) 55" (UHD) 65" (UHD) 65" (UHD) 70" (UHD) 75" (UHD) 86" (UHD) 98"... -
Page 26: Protection Of Trademarks And Intellectual Property
"Prestigio" is a registered trademark belonging to the Prestigio company. Applicable law: this document is drawn up in accordance with the law of Cyprus. Any questions concerning this document should be addressed to the company at: Prestigio Plaza Ltd, Cyprus, Zinas Kanther&Origenous, P.C. 3035 Limassol.
