NSD ABSOCODER NCW-3DHPNV1R Specifications & Instruction Manual page 56

Offset Address
(Byte) Data type
+16 UDINT
+20 UDINT
+24 WORD
+26 WORD
Name
Axis-2 Position Axis-2 Position data
Shows the Axis-2 Position data.
Reserved Reserved
Axis-2 Status Axis-2 Status
Bit
0
1-4
5
6
7
8-15
Axis-2 Control Axis-2 Control Flag Answerback
Answerback
Bit
0-5
6
7
8-15
48
Data Format
Description
Description
SE (Sensor Error)
Indicates that a SSE/SPF/DE occurred.
0: No error
1: Error
Reserved
SSE (Disconnected Sensor Error)
Indicates that a sensor is disconnected.
0: Connected
1: Disconnected (Error)
SPF (Sensor Circuit Power Error)
Indicates that the internal power supply of NCW-3DHPN is
malfunction.
0: Normal
1: Error
DE (Sensor Data Error)
Indicates that position data has an error.
0: No error
1: Error
Reserved
Description
Reserved
ERRCLR (Error Clear) Answerback
0: "ERRCLR" failed.
1: "ERRCLR" succeeded
PRESET Answerback
0: "PRESET" failed
1: "PRESET" succeeded.
Reserved
