9-7-2. Sensor parameters setting procedure

Setting procedures of the sensor parameter is indicated below.
(1) Select "Device view->Device overview".
(2) Right-click "Parameter Access Point", and click "Properties".
(3) Set the sensor parameter.
Set the parameter when displaying "Module Parameters".
(3)
(2)
(2)
43
(1)
(3) 1-axis sensor parameter
(3) 2-axis sensor parameter
